VANTAGGIO V60-C-BG-ST-RH Instruction Manual

Cigar humidor
Hide thumbs

Advertisement

Table of Contents

MODEL: V60-C-BG-ST-RH
CIGAR HUMIDOR
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V60-C-BG-ST-RH and is the answer not in the manual?

Questions and answers

Summary of Contents for VANTAGGIO V60-C-BG-ST-RH

  • Page 1 MODEL: V60-C-BG-ST-RH CIGAR HUMIDOR Instruction Manual...
  • Page 2 Thank you for your purchase of the Vantaggio This appliance is intended to be used within Cigar Humidor. Before using the product, secure residential and commercial spaces, please read and follow all safety rules and including examples such as: operating instructions.

  • Page 3: Installation Instructions

    • WARNING - If you do not use the machine for Installation Instructions a long time, please unplug the power cord from the electrical socket or switch off the power • The room for installing the appliance must be at supply to conserve power.

  • Page 4: Grounding Instructions

    Notes: Installing your Cigar Humidor: Unpack and remove all protection and adhesive • V300-BG-ST-RH model is for freestanding strips from the cigar humidor packaging. ONLY Once all the packing materials are removed, • V54-BG-ST-RH/V54-BG-DT-RH/V164-BG-ST- move the cigar humidor to your desired location. RH/V163-BG-DT-RH models are available as It must be positioned so that the plug is both built-in and freestanding units...
  • Page 5 6. The power cord is 2.0m in length and is fixed In hot climate zones, you require an air vent on the right side at the back when looking or grid with a minimum ventilation size of from the front of the cabinet. 200 mm x 40 mm.

  • Page 6: Dimensional Drawings

    INSTALLATION DRAWINGS FOR BUILT IN CIGAR HUMIDOR DIMENSIONAL DRAWINGS:...
  • Page 7 OPEN ANGLE SIZE DRAWINGS...
  • Page 8 RADIATOR SYSTEM DESCRIPTION This model uses side anti-dew tubes and an independent cooling system:...
  • Page 9 Turning on your Cigar Humidor Loading your Cigar Humidor Plug in and switch on the cigar humidor by When you put cigars inside the cabinet, please pressing the power button for a few seconds. keep space at the back and the top. Do not allow the cigar to touch the back and top panels.

  • Page 10: Temperature Settings

    Display and Storage • The design purpose for the cigar humidor is for storing large amounts of cigars in a safe situation. • Put the cigar box on the cigar drawer even- ly. Please keep the cigar box away from the inner shell or bottom of the humidor, and don’t stack the cigar box near the bottom or the top of the humidor.
  • Page 11 Celsius or Fahrenheit. the light to stay on, just turn it on. The door lamp switch will not be controlled.)  Temperature Display Window: Displays setting temperature and actual temperature.  Humidity Display Window: Displays setting humidity and actual humidity. V60-C-BG-ST-RH...
  • Page 12 Important Information Defrosting/ Condensation/ about Temperature Hydrometry/Ventilation The ideal temperature for cigar storage ranges Your cigar humidor is designed with an “auto-cycle” between 16-20 C. The cigar curing process is defrost system. During “auto-cycle” the refrigerated weakened, causing cigar embrittlement and surfaces of the cigar humidor defrost automatically.
  • Page 13 Removing Humidor Drawer Humidification System Description Humidor drawer taking: Humidor drawer taking: As per the following The cigar humidor has an automatic humidifier instructions, press one side of the shelf limit pin function. The system is located on the lowest part j , then extract and remove the shelf from the of the cabinet.

  • Page 14: Reversibility Of The Door

    Humidification System Reversibility Description (Continue) of the Door Warning: To avoid accidents during the process of changing the door, we recommend that you get assistance. The glass door is heavy and may cause injury if dropped. • Depending on the model and the type of han- dle your cigar humidor is equipped with, you may have to rotate the door 180 degrees.
  • Page 15 1. Decorative nail 5. M5 six angle screwdriver 2. Knife 6. Door spindle core 3. Drop-proof device 7. Upper door hinge 4. M5 six angle 8. Lower door hinge...

  • Page 16: Operation Anomalies

    Handle Installation Method Operation Anomalies 1. Take out the handle from cabinet, then take out Ensure that there is power to the electrical supply 2pcs screws from accessory bag. (Note: the plug by connecting another electrical appliance screws of some models have been put on the to it.

  • Page 17: Troubleshooting Guide

    Troubleshooting Guide Common problems are easy to fix, which can save you time and money rather than calling a service technician. Please carefully read the instruction manual and revert to the troubleshooting guide chart. Problem Possible Cause • Not plugged in. Cigar humidor does not operate.
  • Page 18 Compressor operated: R600a • Available in rated voltage/frequency 120V/60Hz • Automatic defrost • Humidity: 65%~75% RH +/-10% RH • Black outer and inner finish • Internal light • Adjustable feet x 4 • Two layers glass door • Full black glass door...
  • Page 19 Before disposing of the appliance. 1. Disconnect the main plug from the main socket. 2. Cut off the main cable and discard it. Correct disposal of this product This symbol on the product, or in its packaging, indicates that this product may not be treated as household waste. Instead, it should be taken to the appropriate waste collection point for the recycling of electrical and electrical equipment.
  • Page 20 Toast to perfection with Vantaggio. 1-888-253-6807 info@vantaggiowinecellars.com...
