MENEGOTTI TECHNICAL MANUAL
TAMPING RAMMER
RAM 70H
QR-Code:
Point your mobile phone camera to
access the updated online version of
Technical Manuals and Parts Catalogs,
or click on the link below to access the
website.
www.sites.google.com/view/menegotti-engenharia-docs
Attention:
Before operate Menegotti equipament, read this
technical manual, itself will inform and instruct the
operator about the operation.
By the way, you avoid possible working accidents
and early maintenance on at the equipment.
Advertisement
Table of Contents
Summary of Contents for MENEGOTTI RAM 70H
- Page 1 Attention: Before operate Menegotti equipament, read this technical manual, itself will inform and instruct the operator about the operation. By the way, you avoid possible working accidents and early maintenance on at the equipment.
-
Page 2: Table Of Contents
Hints on How to Guide the Machine Product Warranty Menegotti is preparaded to offer you all technical assistance, and attend Warranty Term all your needs about replacement parts. Welcome, you are part of the huge Menegotti “customers family”. -
Page 3: Menegotti Group
Menegotti Group Menegotti is reference in the development of solutions in machines and tools for the Construction machinery, Handling and Lawn | Garden Segments. A Brazilian company, present in more than 40 countries, has its headquarters in Jaraguá do Sul, Santa Catarina, units in Brazil and in the United States. -
Page 4: General Care
ALWAYS FOLLOW THE INSTRUCTIONS OF THE TECHNICAL OR ENGINEER IN THE WORK FIELD. USE OBLIGATORY PROTECTIVE EQUIPMENT General Care • It is not recommended to use this machine in rainy conditions or flooded terrain; • Do not use the machine on “over” compacted terrain, soils and floors; •... -
Page 5: General Vision Of The Equipment
General Vision of The Equipment Number Part Accelerator Throttle Engine Filter Engine Protection Bellow Transport Shoulder Strap 2 Shoe Tamping System Crank Case Transport Roller 4 Cycle Air Filter Cable Guide Bar Emergency Button Transport Shoulder Strap 1 Gas Tank... -
Page 6: Technical Info
Technical Info World Metric US Metric Info Weight Shoe Size LxC (cm) 28x32 LxC (Inches) 11x12,6 Fuel Type Petrol Type Petrol Fuel Consumption Liters/hours Gallons/hour 0,26 Gas Tank Capacity Liters Gallons 0,79 Engine Brand Honda GXR120 Honda GXR120 Power Forward Speed Meters/minute Miles/minute 52,5... - Page 7 1.2. Set the Choker • In the cold start, move the choke lever in the direction indicated in the figure from “opened” to the “close” position. When starting with the hot engine, pull the lever back to “open” position. 1.3. Position the Throttle Lever •...
- Page 8 1.4. Starting the Engine • Slowly pull the recoil starter lever until you notice a resistance and then pull it a little harder and quickly for about 5 times. This will make the fuel low to the carburetor; • Pull it the recoil starter until the engine starts. After the engine starts, put the choker back to the “open” position; *Allow the engine to heat up for a few minutes before starting your work with the equipment.
-
Page 9: Turning Off The Equipment
Turning Off The Equipment 3. TURNING OFF THE EQUIPMENT 3.1. Instruction on how to Turn off the machine • To stop the machine, slow down by pulling the accelerator/throttle back to the minimum POSITION; • Close the fuel tank tap; Float carburetor Diafraghm carburetor •... - Page 10 • Never carry the machine laid over the engine filter side or on the recoil robe. Always make the transport over the transport roller. This prevents the return of engine oil to the fuel filter producing short term damage to the filter and carburetor; * Always close the FUEL TAP when transporting the rammer; WARNING: The RAM 70H compactors with float carburetor can only be transported vertically.
-
Page 11: Drain Plug
5.1 OIL LEVEL CHECK • Remove the oil level indicator and measure; • The oil level must be between the minimum and maximum marks as showed in the following image. 5.2. ENGINE OIL EXCHANGE OIL WITHDRAWAL • Place a container (plastic jar) below the oildrainer of the machine; •... - Page 12 6. AIR FILTER CLEANING 6.1. Primary Air Filter • Turn the knob (BUTTERFLY SCREW) and open the primary air filter cover; SPONGE TYPE • Remove the SPONGE TYPE Filter Element and wash it with soap and water; • Remove the PAPER TYPE filter element and insert a compressed air jet from THE INSIDE OUT. PAPER TYPE * WARNING DO NOT WASH THE PAPER FILTER ELEMENT.
-
Page 13: Maintenance Table
Maintenance Table MAINTENANCE PERIOD PART TASK Every Use Engine Check the Oil Level Every Use Primary and Secondary Air Filter Daily Cleaning in Dusty Places Every Use Shoe Tightening Screws After The First 10 and Engine Oil Exchange Every 50 Hours of Use Every 50 Hours of Use Engine Fuel Filter... -
Page 14: Hints On How To Guide The Machine
Hints on How to Guide the Machine When in danger, push the emmergency button. USE OBLIGATORY PROTECTIVE EQUIPMENT BE AWARE OF OBJECTS, SLOPES AND PEOPLE. DON’T PUSH TOO HARD THE MACHINE. When guiding the machine don’t PUSH its forward jumping movement. -
Page 15: Product Warranty
Menegotti. The product freight charges, including the technical assistant or in environments for which it was not designed, incorrect voltages and factory, are borne by the consumer. - Page 16 Solid values, sustainable future. Unit • Unidad Menmaq Unit • Unidad Mentec Unit • Unidad Menfer Unit • Unidad MNA United States...
