Modecom VOLCANO Manual

System requirements

PC Compatible with Windows operating system Available USB port

Package contents

Mechanical keyboard
User's manual

Specification

Interface: USB
Type: Mechanical
Keys: 87
Dimensions: 358×138×38 mm
Weight: ok. 710 g

Installation

This is PnP (Plug-n-Play) device and compatible with Windows 2000 and later editions To install this device please follow the below steps:

1. Find available USB port
2. Connect keyboard to the com-puter
3. Keyboard should be automati-cally detected and installed by the operating system
4. Keyboard is ready to be used

Multimedia keys

FN+F1 – media
FN+F2 – Volume +
FN+F3 – Volume
FN+F4 – Mutes the media playback
FN+F5 – Stop
FN+F6 – Previous
FN+F7 – Play / Pause
FN+F8 – Next

Software keys

FN+F9 – Email
FN+F10 – Home
FN+F11 – My computer
FN+F12 – Calculator

Backlight Effects

FN+INS (INSERT) – LED running (waving, breathing, spreading)
FN+HM (HOME) – LED spreading
FN+PU (PGUP) – LED waving, press again, constant LED
FN+DEL – LED breathing
FN+END – Customization LED mode, 10 groups customization LED for 10 different games. Press FN+1, then press FN +END, enter customization mode, LED indicator is flashing. Then set any key LED on as you want. Press FN+ END again, setting finish. Users could set 10 groups customization LED modes with FN+1~0.
FN+PGDN (PD) – single key LED on
FN+PS (PRNTSC) – Lock FN functional key (lock/unlock FN, when FN locked, no combination function)
FN+SL (SCROLL) – 6 keys/87keys anti-ghosting function switch, default is 87 keys anti-ghosting FN+PB (PAUSE BREAK) – LED running, light running between lines with crossing cycle

LED settings

FN+<<arrow up>> – light up
FN+<<arrow down>> – light down
FN+arrow left – LED spreading / breathing speed down
FN+arrow right – LED spreading / breathing speed up

Another settings

FN+ESC – Factory reset(press for 3 seconds)
