Summary of Contents for Topex TX221
- Page 1 SKU:TXCC20V221 TX221 OWNER'S MANUAL 20V MAX CORDLESS CHAINSAW Thank you for buying this 20V MAX CORDLESS CHAINSAW! Please read this manual carefully before using the product.
-
Page 2: Description Of Symbols
DESCRIPTION OF SYMBOLS WARNING Volts Hertz Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in Alternating current Watts electric shock,fire and/or serious injury. Direct current Diameter Milliamperes No load speed Save all warnings and instructions for future Revolutions or reference.The term “power tool’’... - Page 3 3. PERSONAL SAFETY d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power a. Stay alert, watch what you are doing and use tool or these instructions to operate the power tool. common sense when operating a power tool.
-
Page 4: Chainsaw Safety Warnings
ADDITIONAL GENERAL SAFETY WARNINGS CHAINSAW SAFETY WARNINGS ■ Keep all parts of the body away from the saw chain ■ Some regions have regulations that restrict the use of when the chainsaw is operating. Before you start the the product. Check with your local authority for advice. chainsaw, make sure the saw chain is not ■... - Page 5 ■ Do not attempt to fell a tree until you have an ADDITONAL CHAINSAW SAFETY WARNINGS understanding of the risks and how to avoid them. Serious injury could occur to the operator or bystanders ■ It is recommended to practise cutting logs on a while felling a tree.
-
Page 6: Battery & Charger Safety Warnings
– before installing or removing attachments 4. Do not keep battery pack in places where temperatures are liable to reach over 50°C, such as in a – before checking, performing maintenance, or working car, metal shed or similar that is in direct sunlight. on the product 5. -
Page 7: Charger Warnings
22. Do not use damaged battery chargers. 23. Do not use the supplied battery charger to charge other cordless tools. Only charge TOPEX rechargeable batteries with an TOPEX Charger. 24. The battery pack may become warm during use. -
Page 8: Product Specifications
GETTING STARTED PRODUCT SPECIFICATIONS Cordless chainsaw Model TX221 MAX voltage 20 V d.c. No-load speed 10 m/s Guide bar length 254 mm Cutting length 230 mm Chain pitch 9.53mm (0.375 in.) Chain guage 1.1 mm (0.043 in.) Drive links quantity... - Page 9 Install the saw chain on the bar. Insert the chain drive Adjust the chain tension until the gap between the drive links into the bar groove. Position the saw chain so that teeth and the bar is between 4–5.5 mm.Turn the chain there is a loop at the back of the bar.The saw chain tensioner adjustment ring clockwise to increase the should face in the direction of chain rotation.
-
Page 10: Inserting & Removing Battery
INSERTING & REMOVING BATTERY Installing a Battery into the Chainsaw 1. Align the ribs of the battery with the recess below the handle Remove the lubricant cap. Add chain and bar oil into the product. Install the lubricant cap. 2. Slide the battery in so that it clicks into place. Removing a Battery from the Chainsaw 1. -
Page 11: Switching On/Off
2. Slide the battery out. WARNING: Always hold the product with the right hand at the rear handle and with the left hand at the front handle. Grip both handles with the thumbs and fingers encircling the handles. SWITCHING ON/OFF Switching ON 1. -
Page 12: Chain Brake
4. The chain will now be running, ready to make a cut. Release the lock-off switch. BRAKE ON BRAKE OFF STOP The chain brake can be operated manually by pushing it forward or automatically as a result of kickback. Kickback occurs if the chain catches on the wood being cut and the chainsaw recoils back suddenly. -
Page 13: Battery And Charging
3. If you cannot cut the timber in a single stroke, apply light pressure to the front handle and continue sawing, draw the chainsaw back a little then apply the bucking spikes a little lower and finish the cut by raising the rear handle. - Page 14 4 The charger LED will illuminate red signifying that the Low state of charge, requires charging soon. battery is charging. Mid state of charge Full state of charge. 5 The charger LED will illuminate green once the battery is fully charged. Battery pack is too hot or too cold (charging will begin automatically when battery reaches correct charging temperature).
-
Page 15: Maintenance
Maintaining the guide bar MAINTENANCE 1. Remove any sawdust from the guide bar, including WARNING: Before cleaning your chainsaw or the groove.Oil and sawdust combine and emit a burning carrying out any maintenance procedure, make sure smell during operation if the blade is not regularly the battery removed to prevent accidental starting. -
Page 16: Troubleshooting
TROUBLESHOOTING CARING FOR THE ENVIRONMENT Cleaning and storing Power tools that are no longer usable • Keep the handles free of grease so that you can should not be disposed of with household maintain a firm grip. waste but in an environmentally friendly way. Please recycle where facilities exist.
