SMART PXL60 Dot (24V)- Installation Guide
60mm diameter RGB/RGBW LED pixel dot in 24V with high resolution dimming.
Contents
Safety .......................................................................................................................................................................................................................................... 2
Key Electrical Safety ...................................................................................................................................................................................................... 2
Electrical Information .................................................................................................................................................................................................. 2
Installation Safety .......................................................................................................................................................................................................... 3
Protection From Injury During Installation ....................................................................................................................................................... 3
PXL Dot Planning and Specification ..................................................................................................................................................................... 3
Key Safety & Functional Limits ............................................................................................................................................................................... 3
Voltage Drop ........................................................................................................................................................................................................................... 3
Physical Dimensions .......................................................................................................................................................................................................... 4
Cable Core Identification Chart .................................................................................................................................................................................... 5
DC PSU Connection ............................................................................................................................................................................................................. 6
Data Cable Length & Direction ...................................................................................................................................................................................... 6
Control Channels .................................................................................................................................................................................................................. 7
Smart PXL Dot Control Options ..................................................................................................................................................................................... 8
Controlling Smart PXL Dots with ENTTEC's OCTO ........................................................................................................................................... 8
Installation Guidelines ...................................................................................................................................................................................................... 9
Surface Installation of Smart PXL60 Dots & Accessories .......................................................................................................................... 9
Catenary Mounting ...................................................................................................................................................................................................... 10
Marking The Surface ................................................................................................................................................................................................... 10
Servicing, Inspection & Maintenance ...................................................................................................................................................................... 11
Cleaning ............................................................................................................................................................................................................................ 11
Ordering Information ....................................................................................................................................................................................................... 12
1
ID: 5930240
Last Updated: Mar 2025
Smart PXL60 Dot (73050) - 24V
Visit the ENTTEC website for the latest version.
INSTALLATION GUIDE
Advertisement
Table of Contents
Related Manuals for Enttec SMART PXL60 Dot
Summary of Contents for Enttec SMART PXL60 Dot
-
Page 1: Table Of Contents
Data Cable Length & Direction ...................................... 6 Control Channels ..........................................7 Smart PXL Dot Control Options ..................................... 8 Controlling Smart PXL Dots with ENTTEC’s OCTO ............................8 Installation Guidelines ........................................9 Surface Installation of Smart PXL60 Dots & Accessories .......................... 9 Catenary Mounting ........................................ -
Page 2: Safety
Check and respect all directions and warnings given within this installation guide before specifying, installing and operating a Smart PXL Dot installation. If you are unsure or still have any questions about how to install or operate this product safely, please contact your ENTTEC supplier or speak with ENTTEC directly. Key Electrical Safety This product must be installed in accordance with applicable national and local electrical and ▪... -
Page 3: Installation Safety
Before planning or installing your PXL Dot, ensure you are familiarised with all key information within this guide and other relevant ENTTEC documentation. If you are in any doubt about PXL Dot safety, or you plan to install ENTTEC’s Smart PXL Dots in a configuration that is not covered within this guide, contact ENTTEC or your ENTTEC supplier for assistance. -
Page 4: Physical Dimensions
Female 23mm All ENTTEC Smart PXL Dot accessories are fitted with the same Amphenol AT series connectors and industrial grade heat shrink as the Smart PXL Dots to provide additional durability. Each cable accessory has a bend radius – View each accessory’s datasheet for more information. -
Page 5: Cable Core Identification Chart
Pin on Amphenol Connector Black White Data +24V DC Cable Colour Function Pin on Amphenol Connector Black White Data +48V DC ENTTEC recommend the use of cable ferrules when connecting non-tinned cable. INSTALLATION GUIDE ID: 5930240 Last Updated: Mar 2025... -
Page 6: Dc Psu Connection
The Class 2 or LPS PSU’s maximum power rating. ▪ To determine the total power consumption of a chain of ENTTEC Smart PXL Dots, add together the power consumption for all individual Dots by referring to electrical information. If UL compliance is not required for your installation, contact ENTTEC for further assistance. -
Page 7: Control Channels
Smart PXL60 Dot (73050) – 24V Visit the ENTTEC website for the latest version. Control Channels Each RGB Smart PXL Dot consumes the equivalent of 6 DMX channels of data. Each RGBW Smart PXL Dot consumes the equivalent of 8 DMX channels of data. -
Page 8: Smart Pxl Dot Control Options
Visit the ENTTEC website for the latest version. Smart PXL Dot Control Options ENTTEC provides a range of controllers specifically designed to manage Smart PXL Dots, catering to diverse use case scenarios. Application diagrams showcasing the functionality of select ENTTEC controllers are included in the following section. -
Page 9: Installation Guidelines
Cable termination end caps (SKU: 73015) feature a single M5 hole for use with pan head screws and bolts. ENTTEC produces Smart PXL Dot cable accessories for increased convenience on site. All accessories use the same connectors as the Smart PXL Dot’s. Cabling should be restrained with cable clips suited to the surface you are mounting your Smart PXL installation to every 0.5m. -
Page 10: Catenary Mounting
Catenary Mounting ENTTEC recommends UV resistance nylon cable tie, minimum 3.52mm width and 50lbs tensile strength cable ties for 2 wire catenary support of the Smart PXL dots via the mounting holes to eliminate any rotational stress. Do not place cable tie directly to cable leading in/out of Smart PXL dot. -
Page 11: Servicing, Inspection & Maintenance
Do not spray Smart PXL Dots or accessories with a high-pressure water jet. To clean an ENTTEC Smart PXL system, use low-pressure compressed air to remove dust, dirt and loose particles. If deemed necessary, wipe the Smart PXL Dots with a damp microfiber cloth. -
Page 12: Ordering Information
Ordering Information Product Smart PXL60 Dot Refer to DATASHEET Please refer to datasheet or contact ENTTEC team to discuss your customisation and installation requirements. Due to constant innovation, information within this document is subject to change. INSTALLATION GUIDE ID: 5930240...
