Page 1 TiCad (EN) User manual (Translation of the original user manual)
Page 3: Table Of Contents
These operating instructions are valid for the following products: TiCad Ten electric trolley from year of manufacture 2024 ▪ The instructions for all accessories used are included in the applicable documents. TABLE OF CONTENTS SAFETY INSTRUCTIONS .................................. 2 YOUR TiCad TEN IN DETAIL ................................. 3 SCOPE OF DELIVERY ..................................
Page 4: Intended Use
TiCad is not liable for damage to golf trolleys and any consequential damage caused by collisions, falls and water damage when using the optional remote control. Do not steer your golf trolley into dangerous situations.
Page 5: Safety Instructions
Means of representation DANGER This warning indicates an imminently hazardous situation which, if not avoided, will result in death or (serious) injury. WARNING This warning indicates a possible medium-risk hazard that could result in death or (serious) injury if not avoided. CAUTION This warning indicates a low-risk hazard that could result in minor or moderate injury if not avoided.
Page 6: Your Ticad Ten In Detail
YOUR TiCad TEN IN DETAIL Twist grip control Plastic handle Single push-button Drawbar Upper pocket support with bag tie Rubber gasket LED illuminated ring Center tube Drive wheel 10 Front wheel Knurled sleeve 12 Down tube 13 Lower pocket support with bag tie...
Page 7: Storage And Transport
 Do not place the battery on heat sources (e.g. heating).  Do not throw the battery into a fire. Do not immerse the battery in water. The TiCad battery is protected against incorrect handling (e.g. short circuit, overload, overcharging, deep discharge) by a sophisticated electronic protection system.
Page 8: Charge Battery
Non-observance and misuse lead to an increased risk of fire and explosion. Range of the standard battery is min. 27 holes (load approx. 18 kg). Charging time of empty Li-ion battery approx. 6 to 8 hours.  Do not leave the battery connected to the golf trolley during transportation and storage. Always disconnect the plug.
Page 9  Do not attempt to open or repair the battery yourself. This may only be carried out by trained specialist personnel. In addition to invalidating the warranty, there is a risk of putting the battery in an unsafe operating state.  Contact TiCad Service.
Page 10: Battery Storage And Maintenance
Standard value (45-50 % charge level, 15 to 20 °C): Storage time approx. 6 months. TiCad prohibits any mechanical or electrical / electronic modifications to the battery. This will result in the immediate loss of warranty, guarantee and goodwill services for the battery and the devices powered by the battery.
Page 11: Battery Guide
 Only transport or ship batteries in suitable containers or packaging. If you wish to return a battery to TiCad, please contact TiCad Service in advance to ensure a smooth process. Deformed (including inflated) or damaged or potentially damaged batteries may not be transported or may only be transported with special conditions and precautions.
Page 12 CAUTION Risk of crushing during assembly / disassembly and unfolding / folding of the golf trolley. There is a risk of hand injuries due to crushing when assembling / disassembling and unfolding / folding the golf trolley.  Proceed with caution when assembling / disassembling and unfolding / folding the golf trolley.
Page 13 Mounting drive wheels  Remove and store the axle guard.  Press the sliding sleeve (1), push the drive wheel (2) onto the axle (3), turn the wheel until the drive pin (4) engages. Dismantling drive wheels  Press the sliding sleeve, pull the drive wheel off the axle. ...
Page 14 CAUTION Risk of injury due to instability of the golf trolley. When securing the golf bag, there is a risk of the golf trolley tipping over when the drawbar is folded up. This can lead to injuries.  Always fold the drawbar down before attaching the golf bag to the golf trolley.
Page 15: Disassembly
Adjusting the drawbar  Turn the drawbar ball (2) three to four turns counterclockwise until the drawbar (1) can be moved without resistance.  Position at the desired height.  Tighten the drawbar ball clockwise. Move the drawbar slightly up and down so that the teeth of the lock engage optimally and are not damaged.
Page 16: Folding Golf Trolley
FOLDING GOLF TROLLEY The golf trolley can be folded without having to disassemble it completely.  Disconnect the battery plug from the golf trolley.  Turn the drawbar ball three to four turns counterclockwise until the drawbar (1) can be moved without resistance.
Page 17: Operation
OPERATION Always observe the following precautions and instructions to avoid injury and damage to property. DANGER Lightning strike during a thunderstorm. When playing golf during a thunderstorm, there is a risk of being struck by lightning.  Do not play golf during a thunderstorm. ...
Page 18 CAUTION Risk of injury due to golf trolley rolling away. Golf trolleys can roll away on sloping terrain and injure people and animals.  Park the golf trolley on sloping terrain at right angles to the slope. Golf trolley in battery mode ...
Page 19 LED illuminated ring The LED light ring (1) is active as soon as the battery is plugged into the golf trolley. Color LED illuminated ring Meaning green - slowly pulsating Freewheel Golf trolley idling, battery plugged in, brake open, motor off green - luminous Driving mode Golf trolley in operation (moving), engine switched on...
Page 20: Using The Memory Function
Start & Faster  Turn the rotary handle (1) slightly to the right in the direction of the arrow. Golf trolley starts to move.  Turning the rotary handle further to the right increases the speed. Slow down & stop ...
Page 21 Using the electromagnetic parking brake NOTE Use the electromagnetic parking brake. The golf trolley can roll away and tip over on sloping terrain and be damaged as a result.  Activate the electromagnetic parking brake when the golf trolley is parked. ...
Page 22 Use advance function The fast forward function only works if no remote control is activated (default setting). CAUTION Risk of injury to people and animals due to uncontrolled speed of the golf trolley.  Only use the golf trolley when it is loaded. ...
Page 23 Programming the advance function Deactivate advance function Deactivate the forward function:  Disconnect the battery plug from the golf trolley and wait 30 seconds.  Press and hold the single button. Insert the battery plug while doing so. After 3 seconds, the LED illuminated ring lights up blue continuously. After 30 seconds, the LED illuminated ring flashes blue rapidly.
Page 24: Cleaning, Care And Maintenance
 Clean the golf trolley with water and a mild detergent (washing-up liquid). Maintenance is recommended every 5 years at the latest, or sooner depending on the intensity of use. Please contact your specialist dealer or TiCad Service for this.
Page 25: Troubleshooting
 Reconnect the battery to the charger and then connect the charger to the mains.  Contact TiCad Service. If there is a problem with your golf trolley or accessories that you cannot resolve yourself, please contact your specialist dealer or TiCad Service.
Page 26: Disposal
Lithium-ion batteries do not belong in household waste. Have used batteries disposed of by a certified waste disposal company. TiCad will be happy to take care of the professional recycling of your golf trolley, battery and charger. Please contact TiCad Service.
Page 27: Technical Data
TECHNICAL DATA Model TiCad TEN Trolley type Electric trolley Handling Folding principle Handle Plastic handle, I-shape Weight frame + wheels 5,7 kg / 12 lbs Standard battery 1,2 kg / 2.7 lbs Battery weight Sports battery 1,6 kg / 3.5 lbs Transport bag weight 1,9 kg / 4.1 lbs...
Page 28: Statutory Warranty And Manufacturer'sguarantee
STATUTORY WARRANTY AND MANUFACTURER'S GUARANTEE Your TiCad products have been carefully designed and manufactured. Should you notice any irregularities, please contact your specialist dealer or TiCad Service directly. Statutory warranty in accordance with the legal regulations of the country in which the product was purchased from TiCad or the authorized specialist retailer.
Page 29 Operation with non-original TiCad components will invalidate the manufacturer's warranty and liability. Repairs and adjustments to your golf trolley or TiCad accessories may only be carried out by TiCad or partners authorized by TiCad. Unauthorized tampering voids the warranty / guarantee.
Page 30: Service
SERVICE Should a problem occur with your TiCad golf trolley or accessories, please always contact your specialist dealer or TiCad Service in Altenstadt, Germany, directly before initiating a shipment. This applies in particular to devices that are located outside Germany.
Page 31: Imprint
These operating instructions may not be copied or used in any other way without the consent of TiCad GmbH & Co. KG - this applies to both the entire document and extracts from it. Keep your operating instructions in a safe place.
Page 32 509672_02_EN (2024)
