Page 1: User Guide
User Guide BlackBerry Power Station... - Page 2 SWD-52504-10062006-001...
-
Page 3: Table Of Contents
Charge your BlackBerry device and an extra battery with the BlackBerry C-Series Battery Charger using your computer ............13 Charge your BlackBerry device and a spare battery with the BlackBerry C-Series Battery Charger using a travel charger ............13 Charge your BlackBerry HS-655 wireless headset ....................................13 Using the BlackBerry C-Series Battery Charger on the road .............................. -
Page 5: Safety Information
To reduce the risk of damage to the cord or the plug, pull by the plug rather than the cord when you disconnect the BlackBerry Power Station from the power outlet or convenience receptacle. - Page 6 • The BlackBerry Power Station exhibits a distinct change in performance. Use the BlackBerry Power Station in accordance with the directions provided in this booklet. Improper use might result in damage and will potentially require extensive work by a qualified technician to restore the BlackBerry Power Station to its normal operation. Do not attempt to disassemble the BlackBerry Power Station.
-
Page 7: About The Blackberry Power Station
The BlackBerry® Power Station is a charging system that is designed to charge your BlackBerry device, your BlackBerry® HS-655 wireless headset, and a C-Series battery. You might have purchased the BlackBerry Power Station as a separate accessory or as part of a larger accessory kit, which might include a BlackBerry® C-Series Battery Charger and a C-Series battery. -
Page 9: Assemble The Blackberry Power Station
5. Slide the tabs downward in to the slots until the charging cradle is firmly in place. 6. Align the slots and the USB port on the BlackBerry® C-Series Battery Charger with the tabs and the USB port on the base of the BlackBerry Power Station. -
Page 10: Change The Charging Cradle
2. Remove your BlackBerry device from the BlackBerry Power Station charging cradle. 3. With one hand, hold the base of the BlackBerry Power Station. 4. With your other hand, grip the sides of the charging cradle and slide it upward to remove it from the base of the BlackBerry Power Station. -
Page 13: Using The Blackberry Power Station At The Office And At Home
Once you have connected the power cable to a power outlet, place your device in the cradle to start the charging process. Charge your BlackBerry device Insert your BlackBerry device into the BlackBerry® Power Station so that the connectors on your device align with the connectors on the charging cradle. -
Page 14: Charge A Battery With The Blackberry C-Series Battery Charger
Charge a battery with the BlackBerry C-Series Battery Charger You can use the BlackBerry® C-Series Battery Charger when it is not attached to the BlackBerry® Power Station. The BlackBerry C-Series Battery Charger is designed to be compatible with BlackBerry charging accessories, including BlackBerry travel chargers and BlackBerry automotive chargers. -
Page 15: Charge Your Blackberry Device And An Extra Battery With The Blackberry C-Series Battery Charger Using Your Computer
2. Connect the smaller end of the first USB cable to your BlackBerry device. 3. Connect the larger end of the first USB cable to the large USB port on the BlackBerry C-Series Battery Charger. 4. Lift the front edge of the battery cover to open the BlackBerry C-Series Battery Charger. - Page 16 1. Place the BlackBerry HS-655 in its charging pocket. 2. Place the charging pocket in the integrated charging receptacle in the BlackBerry Power Station.
-
Page 17: Using The Blackberry C-Series Battery Charger On The Road
2. Lift the front edge of the cover to open the BlackBerry C-Series Battery Charger. 3. Insert the battery so that the connectors on the battery align with the connectors in the BlackBerry C-Series Battery Charger. 4. Close the battery cover. -
Page 19: Led Charging Notification
LED charging notification The LED light appears on the BlackBerry® C-Series Battery Charger in amber, green, or red, depending on the status of the battery or BlackBerry device being charged. LED color Description • No battery is inserted for charging. -
Page 21: Legal Notice
Legal notice ©2006 Research In Motion Limited. All Rights Reserved. The BlackBerry and RIM families of related marks, images, and symbols are the exclusive properties of Research In Motion Limited. RIM, Research In Motion, BlackBerry, "Always On, Always Connected" and the "envelope in motion"... - Page 22 Waterloo, ON N2L 3W8 Canada Research In Motion UK Limited Centrum House, 36 Station Road Egham, Surrey TW20 9LF United Kingdom Published in Canada.
