MPH BEE III Quick Reference Manual

POP POP
Some of the keys have two colors of text identifying them. The red text is the default function of the key; pressing
the key by itself will cause it to perform this function. The function in blue text is initiated by first pressing the blue
"2ndF" key.
Mov/Sta: Toggles the radar between moving and stationary operating modes.
Stopw: Places the radar into stopwatch mode.
Test: Manually initiates a self-test of the radar.
Pat Bl: Alternately blanks and unblanks a locked patrol speed when the radar is in standby.*
Low/Hi: Allows the operator to specify a city or highway filter to reduce patrol speed combining or shadowing.*
POP
: Turns POP on when pressed, or when used with the Menu key, increases the current Menu setting.
Menu: Used for modes and setting that do not have individual buttons on the remote. See other side of sheet.
POP POP
: Turns POP off when pressed, or when used with the Menu key, decreases the current Menu setting.
2nd F: Causes the radar to select the blue second function of a key instead of the red primary function. "2nd"
appears in the middle window when it is pressed.
Backlt: (Wireless Remote) Turns on the backlight of the remote control for 7 seconds. (Wired remote) On unit
power up, backlight defaults on. After power up, "backlt" toggles remote backlight on/off.
* Note: On some models, Pat Bl and Low/Hi may be switched.
BEE III Quick Reference Guide
The most commonly used keys, those used while driving, are at the
top of the remote. They are raised rubber keys and are contoured so
that the operator's thumb is cradled in the center of a five-key cluster,
allowing easy control of the radar's operating mode while allowing the
operator to keep his eyes on the road. All of these keys are backlit for
use at night.
Front: Places the radar into front antenna mode.
Rear: Places the radar into rear antenna mode.
Standby: Places the radar into Standby.
Opposite: Places the radar into opposite direction mode when
POP
Same: Places the radar into same direction mode when moving
Lock: Causes the radar to lock the Target speed in the Lock window.
Fastest: Toggles fastest vehicle mode on and off.
Embossed flat membrane keys
Raised rubber keys
moving mode is selected.
mode is selected.
Double-clicking the Lock button releases the speed in the Lock
window.
A locked target will automatically be cleared after a pre-set
time limit (see operation manual). If the unit is in standby, a
countdown will be shown in the target window, allowing the
officer time to note the speeds before they are erased.
