- Page 1 Parker Hannifin Corporation 245 Township Line Road Hatfield, PA 19440 USA Office 215-723-4000 Mobile “E” Cylinder Stand (E-Stand) Instructions for Use and Installation Guide FM-916 Rev. N www.porterinstrument.com 15JAN2025...
- Page 2 Representation Parker Hannifin Corporation Precision Fluidics Division Legal Manufacturer 245 Township Line Road Hatfield, PA 19440 USA Office: (215) 723-4000 European EMERGO Europe Communities Westervoortsedijk 60 Authorized 6827 AT Arnhem, The Netherlands Representative Tel: +31 70 345 8570 Compliance with conformity assessment on Conformité...
-
Page 3: Table Of Contents
1.11.Specifications ............................. 7 ......................8 Installation Instructions 2.1. Assemble E-Stand ............................. 8 2.2. Connecting Supply Lines ........................... 8 2.3. Mounting a Flowmeter to the E-Stand ..................... 10 ......................10 Instructions for Use 3.1. Setup and Prechecks ..........................10 ........................11 Maintenance 4.1. -
Page 4: Device Information
1. Device Information 1.1. Intended Use/Intended Purpose The is E-Stand is intended for use with a continuous or demand flow conscious sedation system to hold a gas mixing device and connect, regulate, and supply oxygen and nitrous oxide medical gas to the system. -
Page 5: General Description/Principles Of Operation
The E-Stand is equipped with various safety features, which are described in Section 1.7. 1.5. Use of the Device The E-Stand is to be used by a healthcare professional trained in the use and administration of O and O gases. The device is designed for use in a gas delivery and scavenging system for pain management and / or minimal conscious sedation, which is ideal for short, minimally invasive procedures to alleviate patient anxiety or minor pain and discomfort. -
Page 6: Safety Features
Brake on Casters: The E-Stand is equipped with brakes on the caster to prevent it from rolling freely during use. Check Valves: The E-stand is equipped with check valves, which prevent the gas from traveling from a full cylinder to an empty cylinder or into the room. -
Page 7: Safe Combination Of Devices
1.10. Safe Combination of devices The E-Stand is designed to be used within a nitrous oxide/oxygen conscious sedation delivery and scavenging system to deliver an accurate mixture of nitrous oxide and oxygen gases to a conscious, spontaneously breathing patient. The device system is also used to remove exhaled waste analgesic gas through a vacuum control system. -
Page 8: Installation Instructions
It is important that the user verify by their own test that all gas pipelines are connected properly prior to using the system. 2.1. Assemble E-Stand Assemble Stand Place E-Block and Telescoping Post subassembly onto... - Page 9 Mount the “E” cylinders of N O and O to the E-Stand Block by sliding the cylinder into place and by lining up the pins and pin holes on the cylinder valve. Push the cylinder into place. Properly placed, the cylinder should hang on the pins.
-
Page 10: Mounting A Flowmeter To The E-Stand
If connecting to a wall supply, connect the supply lines to the appropriate outlet connections (2). Supply pressure is preset by the manufacturer on the E-Stand. When using a wall supply, refer to your flowmeter instructions for correct supply pressure. -
Page 11: Maintenance
If connecting to a wall supply, disconnect the supply lines to the outlet connections. 4. Maintenance The E-Stand has an expected service lifetime of 20 years. The device requires proper maintenance, pre-checks, and servicing. Once the device reaches an age of 20 years, a failed pre-check will indicate that the device has reached the end of its useful life. -
Page 12: E"-Block Cylinder Pressure Gauge Replacement
4.2. “E”-Block Cylinder Pressure Gauge Replacement Warning: High pressure up to 2400 psi (16.54 MPa). When replacing the pressure gauge, wear gloves to prevent debris from entering gas pathway. Note: Turn OFF all cylinder valves / supply pressure. Switch flowmeter on/off switch to the “on”... -
Page 13: Cleaning
4.4. Cleaning The E-Stand must be cleaned between each use in order to prevent the spread of infections. Cleaning the device has been validated with Super Sani-Cloth Germicidal wipes. WARNING: The following warning applies to the device and any device’s components and accessories: •... - Page 14 Symbol Title of Symbol Description of Symbol Indicates the manufacturer’s catalog number of the device and is used for identification of the device. Catalog Number [EN ISO 15223-1:2021, clause 5.1.6] Indicates the manufacturer’s serial number of the device and is used for identification of the specific Serial Number device.
-
Page 15: Warranty
Parker Hannifin Corporation. Parker Hannifin Corporation shall not be liable for any damage, injury or loss arising out of the use of the product, whether as a result of a defect in the product or otherwise, if, prior to such damage, injury or loss, the product was (1) damaged or misused;...
