Summary of Contents for CTR Electronics CANrange
- Page 1 CANrange User’s Guide www.ctr-electronics.com 11/25/2024 CANrange User’s Guide Revision 1.4 Cross The Road Electronics www.ctr-electronics.com Cross The Road Electronics Page 1 11/25/2024...
-
Page 2: Table Of Contents
2. Installation ....................................7 2.1. Wiring the CANrange ................................7 2.2. Reflective Surfaces ................................7 3. FAQ ....................................... 8 3.1 How sensitive is the CANrange to sunlight? ........................... 8 4. Software Information..................................8 4. Mechanical Drawings ..................................9 5. Revision History ..................................10... - Page 3 It is our intention to provide our valued customers with the best documentation possible to ensure successful use of your CTR Electronics products. To this end, we will continue to improve our publications, examples, and support to better suit your needs.
-
Page 4: Device Description
Users can utilize the CANrange to determine distance to a target or utilize it as a beam break sensor to determine when an object has entered a provided range. -
Page 5: Features
CANrange User’s Guide www.ctr-electronics.com 11/25/2024 1.2. Features • Small form factor • Reverse polarity protection • Factory calibrated distance measurements • Enclosed housing • 3M detectable distance in long range mode • 100Hz maximum sensor update rate • Can be used as a remote limit switch with CAN-enabled Phoenix motor controllers 1.3. -
Page 6: Led States
1.5. LED States The CANrange has 2 LEDs located on the front of the CANrange. These LEDs indicate various state about the device, and is useful for diagnostics. The table below can be used to look up what corresponding LED color codes mean. -
Page 7: Installation
The CANrange has 4 Weidmueller push-in connectors for CAN and power inputs. Users should first wire CAN L (green wire) and CAN H (yellow wire) into the CANrange. Ensure that no more than 3/8” strip length is not exceeded and that the input wire AWG is no larger than 14 AWG. -
Page 8: Faq
Time-of-Flight sensors are generally sensitive to ambient light. The brighter the ambient light, the more interference there will be. This results in an impact to accuracy of the detected distance, or the maximum detection range of the CANrange. Users should profile the CANrange in their application in expected ambient lighting conditions to determine how it performs in their use-case. -
Page 9: Mechanical Drawings
CANrange User’s Guide www.ctr-electronics.com 11/25/2024 4. Mechanical Drawings Cross The Road Electronics Page 9 11/25/2024... -
Page 10: Revision History
CANrange User’s Guide www.ctr-electronics.com 11/25/2024 5. Revision History Revision Date Description 26-Nov-2024 Initial Creation. Cross The Road Electronics Page 10 11/25/2024...
