Instructions
®
Pulse
Monitor (TLM)
Measures the distance between the device and the surface of the fluid beneath it to
determine the volume of fluid within a tank. Use with a Pulse operating system only.
Intended fluids: oil, waste oil, automatic transmission fluid (ATF), anti-freeze, windshield
washer solution, and waste water. For professional use only. Not suitable for tank overfill
protection.
Not approved for use in European explosive atmosphere locations.
Part No. 2007428
Important Safety Instructions
Read all warnings and instructions in this manual
before using the equipment. Save these
instructions.
NOTICE
Do not over tighten TLM into tank
bung! Over tightening can cause per-
manent damage and result in inaccu-
rate readings.
Do not use thread sealant or adhe-
sive! Many of these products are
chemically incompatible with the ABS
plastic. PTFE tape is acceptable.
Contains IC: 1846A-XBEE3
Contains FCC ID MCQ-XBEE3. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause
undesired operation.
Tank Level
3A9522A
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pulse and is the answer not in the manual?

Questions and answers

Summary of Contents for Graco Pulse

  • Page 1 Measures the distance between the device and the surface of the fluid beneath it to determine the volume of fluid within a tank. Use with a Pulse operating system only. Intended fluids: oil, waste oil, automatic transmission fluid (ATF), anti-freeze, windshield washer solution, and waste water.
  • Page 2: Table Of Contents

    Graco Information ........
  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings.
  • Page 4 Warnings WARNING EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alco- hol. • Do not exceed the maximum working pressure or temperature rating of the low- est rated system component.
  • Page 5: Set Up

    3. To register the TLM: NOTICE On the Pulse web portal set the Hub, or the remote extender that the TLM Do not over tighten TLM into tank bung! communicates with, to DISCOVERY Over tightening can cause permanent mode.
  • Page 6: Configure The Tlm

    CONFIG OK displays, as shown in F 4, page 6, after the TLM is configured with the new profile. If the TLM does not configure with a new profile by the Pulse software, the error message CONFIG E8 displays (Step 5, TLM Display . 4).
  • Page 7 SENSOR E7 Registration error SENSOR E8 Profile error RF communication error (no SENSOR E9 acknowledge or no signal) Internal error (report to Graco tech SENSOR E10 support) SENSOR E12 Sensor communication error SENSOR E13 Sensor communication error SENSOR E14 Sensor communication error...
  • Page 8: Installation

    TLM is mounted less than 5 in. (127 mm) Many of these products are chemically from the maximum possible fill height of incompatible with the PULSE/ABS plastic. the fluid being measured. PTFE tape is acceptable. The TLM will not read properly if: Do not locate TLM next to the tank wall.
  • Page 9: Installation Examples

    Installation Installation Examples 3A9522A...
  • Page 10: Operation

    Operation Operation View Data Take Measurement The TLM can be configured with the Pulse software to take a reading at predefined times. Press and release the display button (A). Data appears on the display (B) (F . 7); each screen lasting a few seconds before going on to the next.
  • Page 11: Take Measurement - New Profile

    Daylight Savings Time (DST) Change The Pulse software automatically adjusts the time when daylight savings time changes occur (Spring and Fall). NOTE: The first TLM reading will be one hour earlier or later (depending on the season, Spring or Fall time change).
  • Page 12: Troubleshooting

    Monitor is not reporting sched- Out of RF range. Add Graco Extender to Pulse uled readings System. Order Graco Part No. RF obstruction. 17F885 - US/Canada; 17F886 - EU;...
  • Page 13 TLM has not been updated with Manually push DISPLAY button latest adjustments made within on TLM. The profile ID on the Pulse sys- tem. Fluid surface is moving while Ensure the pump is not operat- reading is being taken.
  • Page 14: Service

    Service Service Carefully pull the battery holder (8) just far enough out of the TLM to install the batteries (F . 10). After installation of the TLM, the only additional maintenance or service needed is NOTICE to change the batteries. Do not attempt to separate the battery Replace the Batteries holder from the TLM.
  • Page 15 Press the Display button to synchronize the TLM internal clock with the Pulse software clock. If this is not done, the TLM will not report at the correct scheduled times.
  • Page 16: Parts

    Parts Parts Part No. Description HOUSING COVER ★ SEAL, cover ★ HOLDER, battery BATTERY, alkaline AA 131260 SCREW, mach, pnh, torx ★ Kit 25P682 includes 3, 7 3A9522A...
  • Page 17 Parts 3A9522A...
  • Page 18: Tlm Dimensions

    Parts TLM Dimensions . 13 3A9522A...
  • Page 19: Tank Specifications And Tlm Offset

    Tank Specifications and TLM Offset Tank Specifications and TLM Offset Vertical Tank: • Maximum Volume = 999,999 gal- lons or liters. • Tank walls must be uniformly verti- cal from empty level to full (F . 14 and F . 15). NOTE: *TLM offset is the distance from the maximum height to the shoulder above the threads on TLM.
  • Page 20: Horizontal Cylindrical Tank

    Tank Specifications and TLM Offset Horizontal Cylindrical Tank: Obround Tank: • Maximum Volume = 999,999 gal- • Maximum Volume = 999,999 gal- lons or liters. lons or liters. • Tank end walls must be flat; they • Tank end walls must be flat; they cannot be any other shape, includ- cannot be any other shape includ- ing belled (F...
  • Page 21: Non-Standard Tanks

    Non-Standard Tanks: • Maximum Volume = 999,999 gallons or liters. • The volume at various distances from the TLM can be entered into the Pulse software. • A maximum of 30 points can be inputted into the Pulse software. •...
  • Page 22: Technical Specifications

    Technical Specifications Technical Specifications Tank Level Monitor (TLM) Metric Compatible Fluids oil, waste oil, automatic transmission fluid (ATF), anti-freeze, windshield washer solution, and waste water Ultrasonic Tank Depth Measurement 5 in. to 13 ft. 12.7 cm to 3.96 m range Fluid Level Measurement Accuracy +/- 1.8 in.
  • Page 23: California Proposition 65

    California Proposition 65 California Proposition 65 CALIFORNIA RESIDENTS WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov. 3A9522A...
  • Page 24: Graco Extended Tank Level Monitor Warranty

    Any action for breach of warranty must be brought within two (2) years of the date of sale Graco makes no warranty, and disclaims all implied warranties of merchantability and fitness for a particular purpose in connection with accessories, equipment, materials or components sold but not manufactured by Graco.
