STARION 309-004R Instructions For Use

Authorized Representative:
EMDAR BV - IJsselburcht 3, Pob 5486,
6802 EL Arnhem, The Netherlands
Starion Instruments Corporation
20665 Fourth Street, Saratoga, CA 95070 USA
1 800-STARION +1 408-741-8773
www.starioninstruments.com
© Copyright 2003, Starion Instruments Corporation. All rights reserved.
P
F
INSTRUCTIONS FOR USE
The PowerPack Dual Control Footswitch is a non-sterile, reusable unit intended to be used only with Starion
Cautery Instruments and the PowerPack Universal Power Supply. The PowerPack Dual Control Footswitch has
one outlet cable which is connected to the PowerPack Universal Power Supply. The PowerPack Dual Control
Footswitch has two power settings, variable and high. The amount of power delivered in the variable mode
is determined by the knob setting on the power supply. Variable power is activated by depressing the left
footpedal. High power is activated by pressing on the right footpedal (see figure). The PowerPack Dual
Control Footswitch should be placed on the floor or a flat surface (such as a stand) near the surgeon so that
it can be activated by the surgeon's foot.
To use the different heat ranges, the operator must depress the appropriate foot pedal on the PowerPack Footswitch while
activating the safety interlock of the device. Generally, lower heat ranges increase the sealing capabilities and increase
the time required to divide tissue. Higher heating ranges decrease the time to divide and may decrease seal integrity.See
appropriate device Instructions For Use.
The PowerPack Dual Control Footswitch is intended for use only with Starion Cautery Instruments and the PowerPack
Universal Power Supply for the simultaneous cutting and coagulation of soft tissue during surgery.
IFU0025A -01 ECO#0616
P D
™
OWER ACK
OOTSWITCH
For use only with:
Starion Cautery Instruments and
Starion PowerPack™ UPS
Device Description
Intended Use
Symbol Definition
Means: Attention — Read and follow
indicated Instructions For Use,
Precautions, Warnings, etc.
C
UAL ONTROL
309-004R
(Universal Power Supply) (REF 200-003R)
Means: Variable Power.
Means: High Power.
