Summary of Contents for Thermasol ThermaScent 15-LUXAROMA
- Page 1 Installation Manual ThermaScent System 15-LUXAROMA...
- Page 2 CLIENTS SHOULD NOT USE THIS PRODUCT UNLESS YOU HAVE CONSULTED WITH YOUR DOCTOR AND RECEIVED WRITTEN PERMISSION TO DO SO. DO NOT USE THERMASOL AROMATHERAPY OILS, SKIN CARE PRODUCTS OR ANY PRODUCT ASSOCIATED WITH YOUR THERMASCENT SYSTEM WITHOUT CONSULTING WITH YOUR ALLERGIST OR DOCTOR BEFORE USE. THESE PRODUCTS MAY BE HAZARDOUS TO YOUR HEALTH.
-
Page 3: Tools And Materials
1" Tile hole saw Contact Information: If any point before or during installation you may have a question please feel free to contact us at the following: Technical Support 1-877-222-9129 option # 2 THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17... -
Page 4: Electrical Requirements
The Maximum install distance (Cartridge to shower scent head) is 50 feet. Electrical Requirements A standard NEMA 5-15 duplex outlet is required to power the Lux Aroma system. Refer to the Lux Aroma mounting template for locating the outlet. THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17... -
Page 5: Mounting Bracket
If mounting to wood or concrete use an appropriate anchor and screw combination (not supplied). IMPORTANT: If you are installing a two room version you MUST center the ThermaScent unit between the two rooms so you have roughly the same distance of tubing to each room. THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17... -
Page 6: Installing The Power Cord
F. The end of the power supply will need to be plugged into the power within the recessed panel as shown in image G. Make sure the power switch is off, plug the power supply into the wall, we will power up the system at the end of the installation. Image F Image E POWER Image G THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17... - Page 7 Use the below image as a reference. • Make sure the power cord is not pinched between the ThermaScent and the wall mount Key Hole Slots Recessed mount seats THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
- Page 8 Carefully insert the screwdriver into the holes the driver will be traveling through the plenum of the Lux Aroma system. Once the screw heads are found tighten until the machine is secure. Anchor holes THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
- Page 9 Drill the three marked locations with a 1/4" drill bit. You can unscrew the head from the adapter now, the final mounting of the dispenser will be done later in the instruction. Dispenser opening 1" hole for tubing Mounting Holes THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
- Page 10 J below. • Make sure the Cartridges remain in the upright position, fragrance will leak from the cartridge if not upright. Remove Rubber Plugs Image I Image J THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
- Page 11 On the neck of the cartridge you will find a collar at a 90 degree angle from the cartridge insert that into the air fittings and press firmly, the cartridge will lock into place. Do this with both supplied cartridges. See image L. Air Fittings Image K Image L THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
- Page 12 IMPORTANT: when running the tubing do not allow low spots, or pinch the tubing. This may cause the unit to not operate or operate poorly. To 1" hole in shower area Press tubing over barb fitting THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
- Page 13 Tighten the dispenser to the wall, clean up any residue silicon ensure all drill holes are sealed with silicone. Slip the escutcheon over the adapter, then tighten the dispenser head to the adapter. Repeat these step if you are installing two rooms. Mounting hardware 1" Center hole Dispenser head Dispenser adapter Escutcheon Tubing from ThermaScent THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17...
-
Page 14: Powering Up The System
Now that the installation is completed, turn the power switch on inside the unit. The Lux Aroma display will light up. Refer to the quick start guide for iOS or Android to program and operate your ThermaScent. enclosed in the shipment THERMASOL.COM - 1.800.776.0711 PN: 81211_NC 12/17... - Page 15 1958 STEAM WAY ROUND ROCK, TX 78665 PHONE: 800.776.0711 | FAX: 800.556.5257 | WWW.THERMASOL .COM 81189_C 12/17...
