Vented Gas Log Set

Models:

OD-STSP18-N

OD-STSP18-P

OD-STSP24-N

OD-STSP24-P

• Outdoor Lifestyles by Hearth & Home Technologies Burner/Hearth Kits • 4004-905 Rev B •03/25

Installation Manual

Installation and Appliance Setup

WARNING:

FIRE OR EXPLOSION HAZARD

Failure to follow safety warnings exactly

could result in serious injury, death, or

property damage.

• DO NOT store or use gasoline or other flam-

mable vapors and liquids in the vicinity of this

or any other appliance.

• What to do if you smell gas

- DO NOT try to light any appliance.

- DO NOT touch any electrical switch. DO

NOT use any phone in your building.

- Leave the building immediately.

- Immediately call your gas supplier from a

neighbor's phone. Follow the gas supplier's

instructions.

- If you cannot reach your gas supplier, call

the fire department.

• Installation and service must be performed

by a qualified installer, service agency, or the

gas supplier.

In the Commonwealth of Massachusetts

installation must be performed by a licensed

plumber or gas fitter.

See appliance installation manual for

additional Commonwealth of Massachusetts

requirements.

Table of Contents

Need help?

Do you have a question about the outdoor lifestyles OD-STSP18-N and is the answer not in the manual?

Questions and answers

Summary of Contents for Hearth Technologies outdoor lifestyles OD-STSP18-N

Page 1 Installation Manual Installation and Appliance Setup INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT discard this manual! WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
Page 2 Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...
Page 3: Installation Standard Work Checklist
Installation Standard Work Checklist ATTENTION INSTALLER: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: Date Installed: Lot/Address: Location of Fireplace: Installer: Model (circle one): Dealer/Distributor Phone #:...
Page 4 Welcome A. Congratulations Congratulations on selecting a Hearth & Home Technologies The information contained in this owner’s manual, unless gas log set—an elegant and clean alternative to burning noted otherwise, applies to all models and gas control wood. The Hearth & Home Technologies gas log set you systems.
Page 5: Limited Lifetime Warranty
B. Limited Lifetime Warranty Hearth & Home Technologies LLC LIMITED WARRANTY Hearth & Home Technologies LLC (“HHT”) extends the following warranty for HHT gas, wood, pellet and electric hearth appliances (each a “Product” and collectively, the “Product(s)”) and certain component parts set forth in the table below (“Component Part(s)”) that are purchased from a HHT authorized dealer or distributor.
Page 6 B. Limited Lifetime Warranty (Continued) WARRANTY CONDITIONS: • Because HHT cannot control the quality of any Products sold by unauthorized sellers, this Warranty only covers Products that are purchased through an HHT authorized dealer or distributor unless otherwise prohibited by law; a list of HHT authorized dealers is available on the HHT branded websites.
Page 7: Product Specific And Important Safety Information
Product Specific and Important Safety Information A. Appliance Certification PROPANE/LP: An external regulator is required to re- duce supply pressure to a maximum of 13.0” wc. OD-STSP18-N MODEL(S): OD-STSP18-P D. High Altitude Installations OD-STSP24-N OD-STSP24-P NOTICE: If the heating value of the gas has been reduced, these rules do not apply.
Page 8: Requirements For The Commonwealth Of Massachusetts
H. Requirements for the Commonwealth of Exemptions Massachusetts The following equipment is exempt from 248 CMR 5.08(2) (a)1 through 4: For all side wall horizontally vented gas fueled equipment • The equipment listed in Chapter 10 entitled “Equipment installed in every dwelling, building or structure used in Not Required To Be Vented”...
Page 9: Important Safety And Operating Information
Important Safety and Operating Information A. Appliance Safety Clear Space WARNING! DO NOT operate appliance before WARNING! DO NOT place combustible objects in reading and understanding operating instructions. front of the appliance. High temperatures may start a fire. Failure to operate appliance according to operating in- See Figure 3.1.
Page 10: Getting Started
Getting Started A. Design and Installation Considerations C. Inspect Appliance and Components Installation MUST comply with local, regional, state and • Carefully remove the applaince and components from national codes and regulations. Consult insurance carrier, the packaging. local building inspector, fire officials or authorities having •...
Page 11: Minimum Hearth Dimensions
E. Minimum Hearth Dimensions WARNING Do not install the applaince: • Where curtains, furniture, clothing, or other flammable objects are less than 36" from the front of the heater. • In high traffic areas. • In windy or drafty areas. Damper Stop Installation A damper stop is provided with this appliance.
Page 12: Adequate Combustion Ventilation Air
Damper Stop Installation (cont.) WARNING If the area in which the appliance may be Damper operated does not meet the required volume Stop for indoor combustion air, combustion and ventilation air shall be provided by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, the International Fuel Gas Code or applicable local codes.
Page 13 Combustion tables for Masonry and Factory Built Table 4.4 • Outdoor Lifestyles by Hearth & Home Technologies Burner/Hearth Kits • 4004-905 Rev B •03/25...
Page 14: Gas Information
Gas Information Note: Have the gas supply line installed in accordance WARNING with local codes, if any. If not, follow ANSI Z223.1. Instal- lation should be done by a qualified installer approved Use new black iron or steel pipe. Internally tinned and/or licensed as required by the locality (In the Com- copper or copper tubing can be used per National monwealth of Massachusetts installation must be per-...
Page 15 Appliance Installation and Set-up C.Log Placement WARNING These logs are sold separately. For log placement instructions refer to the installation in- You must secure the gas log appliance to the structions supplied with the log set. fireplace floor. If not, the entire unit may move when NOTE: The appliance is designed to be operated with you adjust the controls.
Page 16: For Your Safety Read Before Lighting
Operating Instructions A. Lighting Instructions Safety Pilot Valve (STANDING PILOT VALVE) • FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: IF THESE INSTRUCTIONS ARE NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. A.
Page 17: Maintenance And Service
Maintenance and Service B.Cleaning and Servicing Any safety screen removed for servicing must be replaced prior to operating the appliance. Annual inspection and cleaning by your dealer or quali- fied service technician is recommended to prevent mal- When properly maintained, your appliance will give you function and/or sooting.
Page 18: Troubleshooting
A. Troubleshooting With proper installation and maintenance, your new decorative gas appliance should provide years of trouble-free service. If you do experience a problem, refer to the troubleshooting guide below. This guide will assist you or a qualified service technician in the diagnosis of problems and the corrective action to be taken. Symptoms Possible Causes Corrective Action...
Page 19: Service Parts
OD-STSP18-N / OD-STSP18-P Service Parts Beginning Manufacturing Date:Feb 2025 Outdoor Safety Pilot 18” Hearth Kits Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth Stocked and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
Page 20 OD-STSP24-N / OD-STSP24-P Service Parts Beginning Manufacturing Date:Feb 2025 Outdoor Safety Pilot 24” Hearth Kits Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth Stocked and Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
Page 21: Contact Information
B. Contact Information Hearth & Home Technologies 7571 215 Street West, Lakeville, MN 55044 www.hearthnhome.com Please contact your dealer with any questions or concerns. For the location of your nearest dealer, please visit www.hearthnhome.com - NOTES - CAUTION DO NOT DISCARD THIS MANUAL Read, understand Leave this manual with •...
