  • Page 1 Machine Translated by Google V1.12 30.09.21 USER MANUAL WELDING INVERTER RECTIFIER TIG 201 AC/DC...

  • Page 2: General Remarks

    Machine Translated by Google ATTENTION! Before installing and starting the device, please read this manual 1. GENERAL REMARKS The device may only be started and operated after carefully reading this Operating Instructions. Due to the continuous technical development of the device, some of its functions may be modified and their operation may differ in detail from the descriptions in the manual.
  • Page 3 Machine Translated by Google • Use protective curtains made of non-flammable materials and choose the right wall colors absorbing harmful radiation. Prevention of poisoning by vapors and gases emitted during welding from electrode coating and metal evaporation: • Use ventilation devices and exhaust systems installed in places with limited air exchange. air, •...

  • Page 4: Technical Parameters

    3. GENERAL DESCRIPTION The TIG 201 AC/DC welder is used for manual welding of structural steel with direct current using coated electrodes (MMA method), a non-consumable electrode in an inert gas shield using direct current for steel, copper and its alloys (TIG DC method) and alternating current for aluminum and its alloys (TIG AC method).
  • Page 5 1. The device should only be used in a single-phase power supply system, three-wire, with grounded neutral point. 2. TIG 201 AC/DC inverter rectifiers are designed to work with a 230V 50 Hz network. protected by 25 A delayed fuses. The power supply should be stable, without voltage drops.
  • Page 6 Machine Translated by Google 7. DESCRIPTION OF SWITCH AND KNOB FUNCTIONS 1. Signaling that the device is connected to the network 2. Overheating/device failure indication 3. Welding current display 4. Current drop adjustment knob 5. Gas flow delay adjustment knob 6.

  • Page 7: Overheating Protection

    10.3. Arc initiation and welding process The TIG 201 AC/DC device is equipped with an ionizer enabling contactless arc ignition. To strike the arc, bring the electrode a few millimeters away from the welded material and press the button on the torch handle.

  • Page 8: Before You Call For Service

    Machine Translated by Google NOTE! Do not activate the button at a distance greater than 2 mm from the welded material. If the arc does not ignite within 2 seconds, release the button. Activating the ionizer for longer than 2 seconds may damage the ionizer! CAUTION! Do not touch the electrode while the button on the handle is pressed.

  • Page 9: Maintenance Instructions

    4. Check the cylinder reducer. 12. OPERATING INSTRUCTIONS The TIG 201 AC/DC device should be operated in an atmosphere free from corrosive components and high dust levels. The device should not be placed in dusty places, near working grinders, etc. Dust and contamination with metal filings of control boards, cables and connections inside the device may lead to an electrical short circuit and, consequently, to damage to the welder.
  • Page 10 During transport, the packed device should be secured against moving and ensured in the correct position. 15. COMPLETE SPECIFICATION 1. TIG 201 AC/DC source 1 pc. 2. TIG welding holder 1 pc. 3. Electrode cable for MMA welding 1 pc.

  • Page 11: Warranty

    Machine Translated by Google 17. WARRANTY The warranty is granted for a period of 12 months for business entities, but excluding warranty claims, or 24 months for consumers from the date of sale. The warranty will be honored upon presentation by the claimant of proof of purchase (invoice or receipt) and a warranty card with the product name, serial number, date of sale and the stamp of the point of sale.
  • Page 12 1G Krzyÿowa Street POLAND We declare that the product listed below: Inverter welder Trade name: TIG 201 AC/DC TIG 200 AC/DC Type: Manufacturer's trademark: to which this declaration relates complies with the requirements of the following European Union directives and the national...
