Analytics Kit

AINVR2-PRM-FORM-D-ANK

For:

AI NVR 2 Premium Form D

Table of Contents

Need help?

Do you have a question about the AINVR2-PRM-FORM-D-ANK and is the answer not in the manual?

Questions and answers

Summary of Contents for Avigilon AINVR2-PRM-FORM-D-ANK

Page 1 Analytics Kit AINVR2-PRM-FORM-D-ANK For: AI NVR 2 Premium Form D...
Page 2 Avigilon Corporation nor any of its affiliated companies: (1) guarantees the completeness or accuracy of the information contained in this document; or (2) is responsible for your use of, or reliance on, the information. Avigilon Corporation shall not be responsible for any losses or damages (including consequential damages) caused by reliance on the information presented herein.
Page 3: Table Of Contents
Contents Installing the AI NVR 2 Premium Form D Analytics Kit Recommended Tools Opening the Cover Installing the Analytics Kit in Slot 7 of Expansion Riser Installing the Second Analytics Kit Removing the Expansion Card Risers Moving the Original T1000 GPU Installing the Second GPU Reinstalling the Expansion Card Risers Reattaching the Cover...
Page 4: Installing The Ai Nvr 2 Premium Form D Analytics Kit
Installing the AI NVR 2 Premium Form D Analytics Kit NOTE If the AI NVR 2 Premium Form D is an operating part of your security system, be aware that it must be shut down to complete this procedure. Before starting to install the kit: 1.
Page 5: Opening The Cover
Opening the Cover 1. Remove the complete access panel: a. Using a 1/4-inch flat head or a Phillips #2 screwdriver, rotate the lock counterclockwise to the unlock position. b. Lift the release latch until the system cover slides back. c. Lift the cover from the system. NOTE Turn the access panel over to locate the server access panel label.
Page 6 2. Press the tabs on either sides of the top cover, and lift the top cover out of the GPU air shroud. 3. Hold and lift the filler from the GPU air shroud. Opening the Cover...
Page 7: Installing The Analytics Kit In Slot 7 Of Expansion Riser
Installing the Analytics Kit in Slot 7 of Expansion Riser 1. Unpack the Analytics Kit and remove the plaster sticker from the heatsink. 2. Locate slot 7, found in the rightmost expansion riser on the back of the AI NVR 2 Premium Form D. This is where the Analytics Kit will be installed.
Page 8 6. Install the Analytic Kit in slot 7 of the expansion riser. a. Connect the GPU power cord to the Analytics Kit. b. Slide the card into the slot guide opposite the connector to align the connector on the card with the connector on the riser.
Page 9: Installing The Second Analytics Kit
Installing the Second Analytics Kit Removing the Expansion Card Risers 1. Loosen the captive screws on the system board, expansion card risers 1 and 3. 2. Remove each expansion card riser: a. Press the blue release tab or button. b. Hold the edges of the expansion card riser and lift it from the system board. Moving the Original T1000 GPU Before you can install the GPU from the second analytics kit, the original GPU must be moved between the two removed expansion card risers.
Page 10: Installing The Second Gpu
c. Hold the GPU by the edges and pull it from the riser. d. Disconnect the GPU power cable. 2. Install the GPU in slot 4 of expansion card riser 3: a. Locate slot 4, found in the middle expansion riser on the back of the AI NVR 2 Premium Form D. iDRAC b.
Page 11: Reinstalling The Expansion Card Risers
1. Install the GPU in slot 2 of expansion card riser 1. a. Connect the power cable to the GPU. b. Align the connector on the GPU with the slot on the riser. c. Insert the GPU into the slot. Press until firmly seated. d.
Page 12: Reattaching The Cover
Reattaching the Cover When all the components of the kit have been installed: 1. Ensure all expansion card latches are closed and there are filler covers for all empty slots. 2. Reinstall the GPU air shroud. 3. Close and lock the AI NVR 2 Premium Form D access panel. 4.
Page 13: Confirming The Installation
Confirming the Installation Verifying the Upgrade 1. Log in to the ACC Client on a workstation on the same network as the AI NVR 2 Premium Form D. 2. In the System Explorer, click Site Setup, and click Site to expand the site containing the upgraded AI NVR 2 Premium Form D.
Page 14: For More Information
For More Information For additional product documentation and software and firmware upgrades, visit support.avigilon.com. Technical Support Contact Avigilon Technical Support at support.avigilon.com/s/contactsupport. For More Information...
