OWNER'S MANUAL
LED LCD Monitor
(LED Monitor*)
*LG LED Monitors are LCD Monitors with LED Backlighting.
Please read this manual carefully before operating your set and
retain it for future reference.
LED LCD MONITOR MODEL
(20MK400H,20MK410H,20MK420H,20MK430H)
20MK4 series
(22MK400H,22MK420H,22MK430H)
22MK4 series
(24MK400H,24MK430H)
24MK4 series
(27MK400H,27MK430H)
27MK4 series
Questo manuale d'istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per
tuo prodotto tra le
migliori offerte di Monitor
LG 27MK430H-B
o cerca il
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 27MK430H-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LG 27MK430H-B

Summary of Contents for LG 27MK430H-B

  • Page 1 Monitor OWNER'S MANUAL LED LCD Monitor (LED Monitor*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read this manual carefully before operating your set and retain it for future reference. LED LCD MONITOR MODEL (20MK400H,20MK410H,20MK420H,20MK430H)

  • Page 2: Table Of Contents

    CONTENTS LICENSE ---------------------------- ASSEMBLING AND PREPARING - - Product Components -------------------------- 4 - Supported Drivers and Software -------------- 5 - Component and Button Description ---------- 6 How to Use the Joystick Button Input Connector - Moving and Lifting the Monitor --------------- 8 - Setting up the Monitor set ------------------- 9 Attaching the Stand Base Mounting on a table...

  • Page 3: License

    LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

  • Page 4: Assembling And Preparing

    ASSEMBLING AND PREPARING Product Components Please check whether all the components are included in the box before using the product. If there are missing components, contact the retail store where you purchased the product. Note that the product and components may look different from those shown here.

  • Page 5: Supported Drivers And Software

    The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE Note that the components may look different from those shown here.

  • Page 6: Component And Button Description

    Component and Button Description Joystick Button How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. Basic Functions Press the joystick button once with your finger to turn on the Power on monitor.

  • Page 7: Input Connector

    Input Connector Connection panel (See p.14~15)

  • Page 8: How To Use The Joystick Button

    Moving and Lifting the Monitor CAUTION When moving or lifting the monitor, follow these in- As far as possible, avoid touching the monitor screen. structions to prevent the monitor from being scratched This may result in damage to the screen or some of or damaged and to ensure safe transportation regard- the pixels used to create images.

  • Page 9: Setting Up The Monitor Set

    Setting up the Monitor set Attaching the Stand Base 20MK4 series 22MK4 series 24MK4 series 27MK4 series CAUTION To protect the screen from scratches, cover the surface with a soft cloth. CAUTION To protect the screen from scratches, cover the surface with a soft cloth.
  • Page 10 WARNING To avoid injury to the fingers and foot when Assembly Stand Body and Base, should hold Base when assembly stand body and base. CAUTION Illustrations in this document represent typical procedures, so they may look different from the actual product. Do not carry the monitor upside down by just holding the stand base.

  • Page 11: Mounting On A Table

    Mounting on a table Press the joystick button on the bottom of the Lift and tilt the Monitor set into its upright position monitor to turn on the monitor. on a table. Leave a 100 mm (minimum) space from the wall for proper ventilation.
  • Page 12 WARNING NOTE When you adjust the angle, do not hold the bottom The angle of the screen can be adjusted forward or of the Monitor set frame as shown on the following backward from -5° to 20° for a comfortable viewing illustration, as may injure your fingers.

  • Page 13: Mounting On A Wall

    Back Cover might be damaged internally. Standard screw If you use improper screw, the product might be dam- aged and drop from mounted position. In this case, LG Electronics is not responsible for it. Max.8mm Model 20MK4 series 22MK4 series NOTE...

  • Page 14: Using The Monitor Set

    USING THE MONITOR SET Connecting to a PC HDMI connection Transmits the digital video and audio signals from Your Monitor set supports Plug & Play*. your PC to the Monitor set. Connect the PC and the *Plug & Play: A PC recognizes a connected device Monitor set with the HDMI cable as shown in the following that users connect to a PC and turn on, without device configuration or user intervention.

  • Page 15: Connecting To Av Devices

    Connecting to AV Devices Connecting Peripherals HDMI connection Connecting Headphones Transmits the digital video and audio signals from your Connect peripherals to the monitor via the headphones AV devices to the monitor. Connect your AV device to port. Connect as illustrated. the monitor with the HDMI cable as illustrated below.

  • Page 16: Customizing Settings

    CUSTOMIZING SETTINGS Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right( ◄ / ► ) to set the options. Press the joystick button once more to close the main menu. Joystick Button Button Menu Status...
  • Page 17 Customizing settings Settings > Quick Settings Description Brightness Adjusts the contrast and brightness of the screen. Contrast Volume Adjusts the volume.(for HDMI only) NOTE You can adjust Mute/ Unmute by moving the joystick button to ▼ in the Volume menu. Settings >...
  • Page 18 Customizing settings Settings > Description Picture Picture Mode Custom Allows the user to adjust each element. The color mode of the main menu can be adjusted. Reader Optimizes the screen for viewing documents. You can brighten the screen in the OSD menu. Photo Optimizes the screen to view photos.
  • Page 19 Game Adjust Response Time Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Fast. For a fast-moving picture, it is recommended that you use Faster. Once Faster Mode is selected, Motion Blur may occur depending on the content.
  • Page 20 Customizing settings Settings > General Description Language To choose the language in which the control names are displayed. SMART ENERGY High Saves energy using the high-efficiency SMART ENERGY SAVING feature. SAVING Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature.

  • Page 21: Troubleshooting

    Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Have you installed the display driver? y Be sure to install the display driver from our web site: http://www.lg.com . y Make sure to check if the video card supports Plug&Play function.

  • Page 22: Specifications

    SPECIFICATIONS 20MK4 series LCD Screen Type TFT (Thin Film Transistor) LCD(Liquid Crystal Display) Screen Resolution Maximum Resolution 1366 x 768 @ 60Hz (HDMI) 1366 x 768 @ 60Hz (D-sub) Recommended Resolution 1366 x 768 @ 60Hz Video Signal Horizontal Frequency 30 kHz to 61 kHz Vertical Frequency HDMI...
  • Page 23 SPECIFICATIONS 22MK4 series LCD Screen Type TFT (Thin Film Transistor) LCD(Liquid Crystal Display) Screen Resolution Maximum Resolution 1920 x 1080 @ 75 Hz (HDMI) 1920 x 1080 @ 60 Hz (D-sub) Recommended Resolution 1920 × 1080 @ 60 Hz Video Signal Horizontal Frequency HDMI : 30 kHz to 85 kHz D-SUB: 30 kHz to 83 kHz...
  • Page 24 Type ADS-18SG-19-3 19016G, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-18FSG-19 19016GPG, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-18FSG-19 19016GPI, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-18FSG-19 19016GPCU, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-18FSG-19 19016GPB, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-25SFA-19-3 19016E, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-25FSF-19 19016EPCU-1, manufactured by SHENZHEN HONOR ELECTRONIC or Type ADS-25FSF-19 19016EPBR-1, manufactured by SHENZHEN HONOR ELECTRONIC...
  • Page 25 SPECIFICATIONS 24MK4 series LCD Screen Type TFT (Thin Film Transistor) LCD(Liquid Crystal Display) Screen Resolution Maximum Resolution 1920 x 1080 @ 75 Hz (HDMI) 1920 x 1080 @ 60 Hz (D-sub) Recommended Resolution 1920 × 1080 @ 60 Hz Video Signal Horizontal Frequency HDMI : 30 kHz to 85 kHz D-SUB: 30 kHz to 83 kHz...
  • Page 26 Dimension Monitor Size (Width x Height x Depth) With Stand 555 mm x 421 mm x 181.9 mm Without Stand 555 mm x 330.9 mm x 38.4 mm Weight (Without With Stand 24MK430H: 3.1 kg Packaging) 24MK400H: 2.8 kg Without Stand 24MK430H: 2.8 kg 24MK400H: 2.5 kg Product specifications shown above may be changed without prior notice due to upgrade of product functions.
  • Page 27 SPECIFICATIONS 27MK4 series LCD Screen Type TFT (Thin Film Transistor) LCD(Liquid Crystal Display) Screen Resolution Maximum Resolution 1920 x 1080 @ 75 Hz (HDMI) 1920 x 1080 @ 60 Hz (D-sub) Recommended Resolution 1920 × 1080 @ 60 Hz Video Signal Horizontal Frequency HDMI : 30 kHz to 85 kHz D-SUB: 30 kHz to 83 kHz...
  • Page 28 Dimension Monitor Size (Width x Height x Depth) With Stand 625.6 mm x 468.7 mm x 204.1 mm Without Stand 625.6 mm x 375.2 mm x 44 mm Weight (Without With Stand 27MK400H: 4.6 kg Packaging) 27MK430H: 4.0 kg Without Stand 27MK400H: 4.2 kg 27MK430H: 3.6 kg The specifications are subject to change without notice.

  • Page 29: Preset Modes (Resolution)

    Preset Modes (Resolution) D-SUB / HDMI PC Timing 20MK4 series Horizontal Display Modes (Resolution) Vertical Frequency(Hz) Polarity(H/V) Frequency(kHz) 720 x 400 31.468 70.08 640 x 480 31.469 59.94 640 x 480 37.5 800 x 600 37.879 60.317 800 x 600 46.875 1024 x 768 48.363...
  • Page 30 1280 x 1024 63.981 60.023 1280 x 1024 79.976 75.035 1680 x 1050 65.290 59.954 1920 x 1080 67.500 Recommend Mode 1920 x 1080 83.89 74.97 HDMI AV Timing 20MK4 series Factory support mode Horizontal Vertical HDMI (Preset Mode) Frequency(kHz) Frequency(Hz) 480P 31.50...
  • Page 31 （for 27MK4 series） ENERGY STAR is a set of power-saving guidelines issued by the U.S.Environmental Protection Agency(EPA). Make sure to read the Safety Precautions before using the product. As an ENERGY STAR Partner LGE U. S. The model and serial number of the product are located on the back and on one side of the product.
