Shenzhen ELSKY Technology Co.,Ltd
Ordering Information:
Sub Model
QM9600H-2C-UA
QM9600H-2L2C-UA
QM9600H-6C-UA
QM9600H-2L6C-UA
Important notice:
(1) GPIO pin:
By default, the motherboard doesn't support GPIO pin.
(2) Power Supply:
The motherboard supports DC 12V or 19V , its full load power consumption is 40W/60W.
Please use the correct voltage. Excessive voltage will burn the motherboard.
Please use enough current. If the current is insufficient,it will not work,and even cause crashes,restarts,blue
screens and other problems.
(3) Display Function:
The VGA, HDMI, LVDS/EDP support single display, dual/triple display copy, dual/triple display
expansion,single display under DOS.
The LVDS,EDP pins cannot exist at the same time. By default,the motherboard supports LVDS,does not
support EDP. If you need EDP, please inform us in advance.
The HDMI interface supports 4K resolution 4096/3840x2160@30Hz; If you use 4K display, Windows 10
operating system is recommended.
The EDP pin supports 4K resolution 4096/3840x2160@60Hz; If you use 4K display, Windows 10 operating
system is recommended.
QM9600H-UA User Manual
Version: V2.4A
QM9600H-UA Series
Option Intel CPU
Support Intel Skylake 6th Generation
Core™ i3 i5 i7 Processors
www.miniboard.cn
RJ45 LAN
1
2
1
2
1
COM
USB2.0
USB3.0
6
2
4
6
6
4
3
Advertisement
Summary of Contents for ELSKY QM9600H-UA Series
- Page 1 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn QM9600H-UA User Manual Version: V2.4A Ordering Information: QM9600H-UA Series Sub Model Option Intel CPU RJ45 LAN USB2.0 USB3.0 QM9600H-2C-UA QM9600H-2L2C-UA Support Intel Skylake 6th Generation QM9600H-6C-UA Core™ i3 i5 i7 Processors QM9600H-2L6C-UA Important notice: (1) GPIO pin: By default, the motherboard doesn't support GPIO pin.
- Page 2 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn (4) SATA2 interface: When the motherboard has Celeron 3855U/3955U/3865U/3965U CPU,the SATA2 interface does not work(No signal). When the motherboard has Core i3/i5/i7 CPU,the SATA1,SATA2 interfaces work(Have signals). (5) Mini-PCIE interface: By default,the Mini PCIE slot has PCIE signal, has no USB,SATA signals.
- Page 3 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn The motherboard supports optional 2xCOM or 6xCOM pins. By default, all COM pins support RS232. The COM2 supports optional RS232/RS422/RS485 signal by JP3/JP4/JP5 jumper setting. The 9th pin of COM1/COM2 supports optional 0V,5V,12V output by JP1/JP2 jumper setting. By default,the COM1/COM2 has 0V.
-
Page 4: Chapter One Specification
Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn i5-6260U Intel® Iris® Graphics 540 i5-6267U Intel® Iris® Graphics 550 i5-6287U i5-6300U Intel® HD Graphics 520 i5-6360U Intel® Iris® Graphics 540 i7-6500U Intel® HD Graphics 520 i7-6560U Intel® Iris® Graphics 540 i7-6567U Intel® Iris® Graphics 550... - Page 5 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn 1xSATA1 interface Standard SATA3.0 hard disk interface; Its maximum transfer speed is 6.0 Gbps. 1xSATA2 interface Standard SATA3.0 hard disk interface; Its maximum transfer speed is 6.0 Gbps. Storage When the motherboard has Celeron 3855U/3955U/3865U/3965U CPU,the SATA2 interface does not ...
- Page 6 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn 1xCPU_FAN pin This CPU Fan pin supports temperature control. (3Pin,1x3Pin,2.54mm) CMOS Battery CR2032 3V(Detachable) Operating Operating temperature:-10℃~60℃; Environment Working humidity:5%~95% Relative humidity, no condensation. BIOS AMI BIOS; Support power on,timing switch,remote switch,intelligently identify devices. Watch Dog Watchdog programming;...
-
Page 7: Chapter Two The Motherboard Pin Definition And Description
Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn Chapter Two The motherboard pin definition and description 2.0 The 1st pin identification methods: (1) Method 1: Look at the silkscreen mark next to the front pin of the motherboard. Will be represented by a... - Page 8 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn HDMI_TXD2P HDMI_TXD1P HDMI_TXD2N HDMI_TXD1N HDMI_TXD0P HDMI_TXC0P HDMI_TXD0N HDMI_TXC0N HDMI_5V HDMI_CLK HDMI_5V HDMI_DATA HDMI_HPD Notice: When inserting the HDMI cable, the first pin of the HDMI cable must correspond to the first pin of the HDMI_CON pin on motherboard. If the plug is reversed or inserted incorrectly,the screen will not be displayed.
- Page 9 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn BCLK- BCLK+ BDO3- BDO3+ Notice:When inserting the LVDS cable, the first pin of the LVDS cable must correspond to the first pin of the LVDS pin on motherboard. If the port is reversed or inserted incorrectly, there is a danger of burning the screen and burning the motherboard! 2.4.1 Backlight power supply definition:...
- Page 10 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn 2.5 J_GPIO pin definition: Position symbol: J_GPIO (2x5Pin,2.0mm) pin position symbol drawing: definition definition GPIO_IN0 GPIO_OUT0 GPIO_IN1 GPIO_OUT1 GPIO_IN2 GPIO_OUT2 GPIO_IN3 GPIO_OUT3 Input and output can be adjusted according to demand. 2.6 Serial port(COM) function and pin definition: ...
- Page 11 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn 2.6.2 COM3~6 pin definition: Position symbol: COM3~6 (2x20Pin,2.0mm) pin position symbol drawing: definition definition COM3_DCD COM3_RXD COM3_TXD COM3_DTR COM3_DSR COM3_RTS COM3_CTS COM3-RI COM4_DCD COM4_RXD COM4_TXD COM4_DTR COM4_DSR COM4_RTS COM4_CTS COM4-RI COM5_DCD COM5_RXD COM5_TXD COM5_DTR COM5_DSR...
-
Page 12: Usb Pin Definition
Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn The RS422 / RS485 definition of the COM2: Position symbol: COM2 (2x5Pin,2.54mm) signal Pin definition RS485 1(S485-) 2(S485+) RS422 1(TXD-) 2(TXD+) 3(RXD+) 4(RXD-) 2.7 USB pin definition: Position symbol: F_USB1, F_USB2 (2x5Pin,2.54mm) pin position symbol drawing:... - Page 13 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn pin position symbol drawing: Position symbol: SYS_FAN (1x3Pin,2.54mm) definition +12V TAC(Fan speed detection) 2.10 Audio interface and pin definition: Position symbol: F_AUDIO (2x5Pin,2.54mm) pin position symbol drawing: definition definition MIC-L MIC-R LINE OUT-R MIC_JD FAUDIO_JD...
- Page 14 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn Switch pin definition: Position symbol: F_PANEL (2x5Pin,2.0mm) pin position symbol drawing: definition definition HDLED+ PWRLED+ Hard Disk LED Power LED HDLED- P_SW IN Restart Switch (1) Hard disk LED indicator light: The 1st and 3rd pins are HDDLED. The 1st pin is the positive side of the LED.When the hard disk is being read or written, the indicator light will flash, indicating that the hard disk is running.
- Page 15 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn SATA_TXN SATA_RXN SATA_RXP SATA_PWR definition: Position symbol: SATA_PWR (1x4Pin,2.54mm) pin position symbol drawing: definition Notice:The first pin of the "SATA_PWR" hard disk power supply interface is 12V output, and the fourth pin is 5V output. When using, you must use the customized power cord from our company to avoid burning the hard disk.
- Page 16 Shenzhen ELSKY Technology Co.,Ltd www.miniboard.cn 1-2 short circuit Clear CMOS content,BIOS will restore factory settings. Notice: Please do not clear the "CMOS" when the motherboard is running or charging, so as not to damage the motherboard. Notice: (1) Please make sure the battery is facing up.
