INSTALLATION AND

OPERATION MANUAL

COMBI TANKS

SERIES MT 100/... HP

Table of Contents

Need help?

Do you have a question about the MT 100 HP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Mycond MT 100 HP Series

Page 1 INSTALLATION AND OPERATION MANUAL COMBI TANKS SERIES MT 100/... HP...
Page 2: Table Of Contents
CONTENT I. Instructions to installer ........................4 1. Requirements to combi tank installation room ..................4 2. Requirements for installation ......................4 II. Description on combi tank ......................5 1. High efficiency insulation and outer casing ..................5 2. Water tank ..........................6 3. Electric heating element (option) .....................6 4.
Page 3 COMBI TANKS SERIES MT 100/… HP PREFACE Dear Customers! We strongly hope that the appliance you have bought from us will contribute to creating comfort at you homes and decreasing the energy expenditure. This manual contains important information for the safe and correct installation, start-up and trouble-free operation and maintenance of the water heater.
Page 4: Instructions To Installer
■ safety during installation – personal protective equipment. Use only original Mycond parts. 1.1. REQUIREMENTS TO COMBI TANK INSTALLATION ROOM When choosing a room for tank installation observe the following requirements: ■...
Page 5: Description On Combi Tank
COMBI TANKS SERIES MT 100/… HP II. DESCRIPTION ON COMBI TANK Combi Tanks MT 100/... HP is used for production and storage of water for domestic use (DHW) and heating / cooling. The construction of two tanks in one product allows the combination of a boiler for DHW (domestic hot water) and a buffer tank for energy storage from a heat pump or solar installation.
Page 6: Water Tank
2.2. WATER TANK Water tank is made of low-carbon steel S235JR, tightly covered with titanium enamel on the inside. It is then baked to produce a smooth and uniform deposition – free glazing. Thus the domestic hot water remains clean, and the water tank is protected against corrosion. All threads are internal (see technical parameters).
Page 7 COMBI TANKS SERIES MT 100/… HP Wiring diagrams R S T Water heater control panel: wiring diagram 1 х 7,5 kW 32А, 3P See Connection 2А, 1P IMIT Thetmostat Manual Bi-Metal Thetmostat +˚C Contactor CT 3P, 40А Connection diagram is, V U W N 3 х...
Page 8: Thermometer
R S T Water heater control panel: wiring diagram 1 х 7,5 kW 32А, 3P See Connection 2А, 1P IMIT Thetmostat Manual Bi-Metal Thetmostat +˚C Contactor CT 3P, 40А Connection diagram is, V U W 3 х 400V in triangle circuit 2.4.
Page 9: (Din 4753, Part 6)
COMBI TANKS SERIES MT 100/… HP 2.5. CATHODIC CORROSION PROTECTION OF ENAMELLED STEEL TANKS FOR DOMESTIC HOT WATER (DIN 4753, PART 6) WARNING! Anode must be checked every two years. Replace the anode when needed. Model Anode connection size, mm Anode length, mm Anode Pcs.
Page 10: Thermostat (Option)
2.7. THERMOSTAT (OPTION) The thermostat may be adjusted by the user within the 101,4 9,601 44,5 range 30°С...80°С, and the thermal protection would go 11,9 off in case the water reaches 95°С. This is an adjustable double THERMOSTAT which is designed to regulate the water temperature and ensures 24,5 1/2 NPT...
Page 11 COMBI TANKS SERIES MT 100/… HP INSTALLATION AND CONNECTION CAREFULLY! Before connecting the thermostat, make sure that THE UNIT TO BE THERMALLY CONTROLLED (water heater, pump, etc.) IS NOT CONNECTED to the power supply network, and is in compliance with the instructions in Figure.
Page 12 CONNECTION (Scheme 5) Scheme 5 LIMITATION TERMINAL 2 – opens the circuit when the temperature rises. TERMINAL C – common contact. THERMOSTAT TERMINAL 1 – opens the circuit when the temperature rises. TERMINAL 2 – closes the circuit when the temperature rises. TERMINAL C –...
Page 13: Connecting Of Safety Relief Valve To Water Tank
COMBI TANKS SERIES MT 100/… HP III. CONNECTING OF SAFETY RELIEF VALVE TO WATER TANK 1. Cold water inlet – water supply 2. Check (return) valve 3. Tee 4. Safety (relief) pressure valve 5. Cold water inlet – water tank 6.
Page 14: Connection Of Combi Tanks With Heat Pump Heating Installation
IV. CONNECTION OF COMBI TANKS WITH HEAT PUMP HEATING INSTALLATION 1. Cold water inlet 2. Stopcock 3. Pressure regulator 4. Check (return) valve 5. Expansion vessel 6. Drain tap 7. Sewerage (Draining) 8. Safety valve 9. Circulation pump 10. Three-way valve 11.
Page 15: Technical Parameters
COMBI TANKS SERIES MT 100/… HP V. TECHNICAL PARAMETERS Model Units MT 100/200 HP MT 100/300 HP Total capacity L, l Hot water supply tank / buffer tank capacity L1/L2, l 200 / 100 300 / 100 Height including insulation Н, mm 1500 1759...
Page 16: Transport And Packaging
Mycond MT 100/200 HP tank dimensions V=200 l Sout Uhws S=2,9 m V=100 Mycond MT 100/300 HP tank dimensions V=300 l S=4,39m Uhws Sout V=100 VI. TRANSPORT AND PACKAGING We recommend to transport the water tank to the installation site in its packaging placed on the pallet, and stretch foil.
Page 17: Warranty
The warranty period begins from the date indicated in the purchase invoice. If a product or any component there of is determined to be defective in manufacture or materials, Mycond Ltd. will repair or replace the defective component or product.
Page 18: Claiming Warranty
5. Mycond Ltd. reserves the right to make in situ reports from the claims they have received for the purpose of checking every aspect that might be useful for better consideration of warranty claims; for this reason the customer shall not make any changes in installation conditions which are reasons for the claim without prior written consent of the Technical Department.
Page 19: Limitation Of Liability
COMBI TANKS SERIES MT 100/… HP 7.4. LIMITATION OF LIABILITY 1. Manufacturer is not liable before the customer, neither directly nor indirectly, for any non-fulfillment or delay at applying the warranty obligations which might originate from external pressure of other circumstances outside Manufacturer 2.
