High-Current Density Surface Mount Schottky Rectifier
DO-214AC (SMA)
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
E
AS
V
F
T max.
J
MAXIMUM RATINGS (T
PARAMETER
Device marking code
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified currentat T
Peak forward surge current 8.3 ms single halfsine-wave
superimposed on rated load
Non-repetitive avalanche energy at T
Voltage rate of change (rated V
Operating junction temperature range
Storage temperature range
Document Number: 88882
Revision: 19-May-08
2.0 A
30 V, 40 V
60 A
11.25 mJ
0.38 V, 0.42 V
150 °C
= 25 °C unless otherwise noted)
A
(Fig. 1)
L
= 25 °C, I = 1.5 A, L = 10 mH
A AS
)
R
For technical questions within your region, please contact one of the following:
PDD-Americas@vishay.com, PDD-Asia@vishay.com, PDD-Europe@vishay.com
New Product
Vishay General Semiconductor
FEATURES
• Low profile package
• Ideal for automated placement
• Guardring for overvoltage protection
• Low power losses, high efficiency
• Low forward voltage drop
• High surge capability
• Meets MSL level 1, per J-STD-020, LF maximum
peak of 260 °C
• Solder dip 260 °C, 40 s
• Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
TYPICAL APPLICATIONS
For use in low voltage high frequency inverters,
freewheeling,
protection applications.
MECHANICAL DATA
Case: DO-214AC (SMA)
Epoxy meets UL 94V-0 flammability rating
Terminals: Matte tin plated leads, solderable per
J-STD-002 and JESD22-B102
E3 suffix for consumer grade, meets JESD 201 class
1A whisker test, HE3 suffix for high reliability grade
(AEC Q101 qualified), meets JESD 201 class 2
whisker test
Polarity: Color band denotes the cathode end
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
E
AS
dV/dt
T
J
T
STG
SSA23L & SSA24
dc-to-dc converters,
SSA23L SSA24
23L S24
30 40
21 28
30 40
2.0
60
11.25
10 000
- 65 to + 150
- 65 to + 150
and polarity
UNIT
V
V
V
V
A
A
mJ
V/µs
°C
°C
