Summary of Contents for Atlas IED IP-RC
- Page 1 IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE 1601 JACK MCKAY BLVD. 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 TELEPHONE: (800) 876-3333 AtlasIED.com AtlasIED.com ENNIS, TEXAS 75119 U.S.A. ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM...
-
Page 2: Table Of Contents
TABLE OF CONTE NTS Introduction ...................... 3 Key Features .....................3 Important Safety Instructions ..............4 Installing the IP-RC ..................5 Configure IP Speaker to test IP-RC’s functionally ........8 Configure IP Speakers to Trigger InformaCast .........9 Dimentional Drawings ................. 10 Compatibility Device List .................11 Architect & Engineer Specifications ............12 Warranty ......................12 Service ......................12... -
Page 3: Introduction
The system consists of 2 parts the IP-RC is a relay board that mates with the IP Speakers main PCB, and responds to button presses on the IP-PB. -
Page 4: Important Safety Instructions
IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE IMP ORTANT SA F ETY I N STRU CTI O N S CAUTI O N - S HO C K R I S K 1. Read these instructions.. -
Page 5: Installing The Ip-Rc
IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE INSTAL L ING THE IP -RC 1. Remove the IP Speaker from its enclosure and disconnect from the network. 2. Locate the 24 pin daughter board connector on the IP Speakers main PCB. (Fig 1) - Page 6 QUICK INSTALLATION GUIDE INSTAL L ING THE IP -RC - ( CO NT INUE D ) 4. Carefully align the 24 pin connector of the IP-RC PCB with the 24 Pin daughter board connector and seat fully. (Fig. 2) Carefully align connectors and seat fully.
- Page 7 INSTAL L ING THE IP -RC - ( CO NT INUE D ) 6. Install the included wires from the IP-RC connector to the main PCB connector as follows. (Fig. 3) a. Main PCB pin 1 to IP-RC Pin 6 (Logic 2+) b.
-
Page 8: Configure Ip Speaker To Test Ip-Rc's Functionally
IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE CON FIG URE IP SPE AKE R TO TE ST I P -R C ’s FUNCT I ON A L LY 1. Log into IP speaker under test by navigating to it IP address via a PC browser on the same network as the IP Speaker. Default credentials... -
Page 9: Configure Ip Speakers To Trigger Informacast
IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE CON FIG URE IP SPE AKE RS TO T RI GG ER INFO RM ACA ST WHE N BUT TO NS A R E PR E SS E D 1. -
Page 10: Dimentional Drawings
IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE DIME NSIONAL DRAWI N GS 2 15 16 " [74mm] 1 7 8 " [48mm] 2 3 16 " [56mm] Rapid Alert 3 3 8 " [86mm]... -
Page 11: Compatibility Device List
IP-RC IP-PB BLE CONTROLLED WEARABLE PANIC RELAY BOARD BUTTON SYSTEM FOR IPX QUICK INSTALLATION GUIDE COMPATIB IL ITY DEVIC E LI ST CATEGORY DEVICES Compatible Devices IP-SDMF, IP-SDMF-72, IP-SDM, IP-SDM-72, IP-SDH, IP-SM, IP-SM-72, IP-DDS, IP-DD, IP-12SYSM, IP-12SYSMF, IP-22SYSM, IP-22SYSMF, IP-DM,... -
Page 12: Architect & Engineer Specifications
Activating a rapid series of button pushes on the IP-PB will result in a relay return can be selected. closure on the IP-RC. 2 rapid button presses will activate relay 1 and 6 or more rapid button presses will activate relay 2.
