Samsung SM-G930F Service Manual
  1. Manuals
  2. Brands
  3. Samsung Manuals
  4. Cell Phone
  5. SM-G930F
  6. Service manual
Samsung SM-G930F Service Manual

Samsung SM-G930F Service Manual

Mobile device
Hide thumbs Also See for SM-G930F:
Table of Contents

Advertisement

Quick Links

Download this manual
Mobile Device
Mobile Device
SM-G930F
CONTENTS
3. Product Function
9. Reference data
Notice: All functionality, features, specifications, and
other product information provided in this document,
including but not limited to, benefits, design, pricing,
components, performance, availability, and capabiliti-
es of the product are subject to change without
notice. Samsung reserves the right to alter this doc-
ument or the product described herein at anytime,
without obligation to provide notification of such
changes.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM-G930F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung SM-G930F

Summary of Contents for Samsung SM-G930F

  • Page 1: Table Of Contents

    Samsung reserves the right to alter this doc- ument or the product described herein at anytime, without obligation to provide notification of such...

  • Page 2: Safety Precautions

    Always use the replacement parts that are registered in the SEC system. Third-party replacement parts may not function properly. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 3: Esd(Electrostatically Sensitive Devices) Precaution

    Increase the airflow to the working area to decrease the chance of accidental static electricity discharges. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 4: Gsm & Wcdma General Specification

    2 K m 2 K m 2 K m Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 5 1 1 . 2 5 K m Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 6 > 5 K m > 5 K m Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 7 > 5 K m > 5 K m Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 8 > 5 K m > 5 K m Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 9 > 5 K m > 5 K m Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 10: Main Function

    Accessory OTG gender Ear phone: 3.5pi, 4pin Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 11: Exploded View And Parts List

    4. Exploded View and Parts List 4-1. Cellular phone Exploded View Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 12: Main Electrical Parts List

    U3002 1009-001066 U6000 1105-002752 UCP601UP 1107-002452 UME3000 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 13 VARISTOR 1405-001395 V7004,V9000,V9001 VARISTOR 1405-001395 V9004 VARISTOR Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 14 R-CHIP 2007-008516 R5024,R5025,R5027 R-CHIP 2007-008516 R5072,R5080,R7003 R-CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 15 R-CHIP 2007-011648 R8026 R-CHIP 2007-012033 R1008,R1009 R-CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 16 C-CERAMIC,CHIP 2203-005777 C1042,C1082,C1089 C-CERAMIC,CHIP 2203-005777 C1090,C2011 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 17 C-CERAMIC,CHIP 2203-006839 C1056,C1057,C1058 C-CERAMIC,CHIP 2203-006839 C1059,C1061,C1066 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 18 C-CERAMIC,CHIP 2203-007449 C3028,C4004,C4006 C-CERAMIC,CHIP 2203-007449 C4008,C4009,C4010 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 19 C-CERAMIC,CHIP 2203-008158 C7123 C-CERAMIC,CHIP 2203-008161 C7117,C7121 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 20 C-CERAMIC,CHIP 2203-008860 C9040 C-CERAMIC,CHIP 2203-008876 C8000 C-CERAMIC,CHIP Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 21 INDUCTOR-SMD 2703-004012 L1045,L1054,L1068 INDUCTOR-SMD 2703-004012 L1072,L1077 INDUCTOR-SMD Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 22 INDUCTOR-SMD 2703-004901 L7014,L7015,L7016 INDUCTOR-SMD 2703-004901 L7017,L7018,L9007 INDUCTOR-SMD Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 23 FILTER 2910-000364 F1001 FILTER 2911-000403 U2008 FILTER Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 24 ANT4003,ANT4004 CONNECTOR 3712-001604 ANT4005,ANT7000 CONNECTOR 3712-001604 ANT7001,ANT7002 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 25 P l e a s e c o n s u l t t h e G S P N we b s i t e ( S a m s u n g P o r t a l ) f o r t h e m o s t r e c e n t v e r s i o n o f t h e p r o d u c t ' s p a r t l i s t . Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 26: Level 1 Repair

     Mobile device specific S/W: Binary files ※ Settings Data Cable : GH-01801B Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 27  Open up the S/W Installation Program by executing the "Odin3 v3.11.1.exe" Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 28 * Note : "Odin v3.10 or above" checks MD5 checksum just after file selection. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 29 Button simultaneously followed by pressing Volume up button as a direction of the phone. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 30 The device is now connected with the PC and ready to download the binary files in it. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 31 You can perform Factory Reset by Settings → Accounts → Backup and reset Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 32 Copy Model File under the ‘Model Name’ folder ④Model File Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 33 Select folder where the Launcher exists Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 34 IMEI program, check IMEI and click Extract & Run. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 35 7. Check SVC , User Ticket No and click OK Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 36 8. Click Hardware Config 9. Click Port Setting Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 37 10. Select Port Number and SAVE 11.Click OK to proceed Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 38 12. Click Model Info and OK when pop-up shows SM-G930F 13. Click OK Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 39 15. Input IMEI Number and click Apply SM-G930F Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 40 After connecting the phone, the phone will be booted automatically. 18. IMEI Writing Proceeding Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 41 6. Level 1 Repair 19. IMEI Writing Success Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 42 Divider Cable 50Ω terminator Divider 4 Port Divider Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 43 6. Level 1 Repair  SETTING Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 44 2. Run the RF Calibration Program Launcher, ‘DASEUL_Launcher_v4.0.0.exe'. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 45 'Calibration' menu, and select 'Extract & Run'. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 46 Click DASEUL Icon on your left side. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 47 5. Change the Resolution setting and select a sequence file Click Start Button. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 48 'Block Cell' and disable 'Smart Cloud Cell'. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 49: Hardware Config

    (Check the GPIB address of equipments in advance) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 50 RF Calibration after completing all settings. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 51 6. Level 1 Repair 9. Use Start Button to Calibrate Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 52: Speaker Calibration

    7-1-3 Lay-out 7-1-4 How to Calibrate Speaker Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 53 6. Level 1 Repair Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 54 6. Level 1 Repair Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 55 7-2-4 How to Initialize Battery Accumulated Usage Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 56 6. Level 1 Repair Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 57: Level 2 Repair

    7. Level 2 Repair 7-1. Components on the Rear Case Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 58: Level 3 Repair

    A OCTA Disassembly Holder Ethyl Alcohol Cotton Swab Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 59 For front part reqair cases GH02-12271A A/S-OCTA_COVER PANEL GH81-13705A Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 60 TAPE DOUBLE FACE-HOME KEY BASE GH02-12170A A/S-SUB PBA_DOUBLE TAPE ARRAY GH81-13747A Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 61 1) Be care of Rear and connector damage Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 62 2) Be care of SUB PBA connector Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 63 2)Be careful of LDI galss crack during detaching CU disassembly stick to remove. tape&sponge. Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 64 1) Be care of chip damage nearby screw point 2) Be care of press power/time Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 65 1) Be care of FPCB and UB damage 1) Be care of Pressure Power/Time Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 66 1) Be care of scratch and REAR damage Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 67 - Front part repair : 1N for 2minutes Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 68: Block Diagram

    8. Level 3 Repair 8-1. Block Diagram Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 69: Pcb Diagrams

    C4065 C4066 R4016 U4013 ZD4009 C4063 ZD4010 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 70 TP8007 TP8008 TP8009 TP8010 TP8011 HDC8000 TP8006 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 71 R10 9 R10 3 U121 U105 L11 4 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 72 ANT107 V10 4 V106 ANT111 ANT106 LED100 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 73 ↑ 8960 & Spectrum Analyzer ↑ Soldering iron Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 74 : 20.0 us.div ( time division) check the initial operation Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 75 Check the U7000 ( Crack etc) Normal Change UCP601 Abnormal Change PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 76 Replace the TCX3000 Frequency = 26 MHz Replace UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 77 Check the UCP601 ( Crack etc) ( C5033) < 1.8V Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 78: Charging Part

    CHG_IN_5P0(C7149)=5V or 9V Battery is Charging? Replace U7011 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 79 Check VBUS_5P0(L7022) =5V Replace SUB PBA OTG is working? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 80 C4004,C4017,C4019 = 1.8V Replace U4004 ( Sensor Hub) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 81: Magnetic Sensor

    ( I2C is OK?) Replace U4011 ( Magnetic Sensor) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 82 ( SPI is OK?) Replace U4006 (6 Axis Sensor) Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 83 ( I2C is OK?) Replace Sensor IC U4007 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 84 ( Connector is OK?) Replace Sensor FPCB Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 85 ( I2C is OK?) Replace Sensor IC U4010 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 86: Hall Sensor

    Replace U7000 ( SENSOR's Voltage) Replace SUB PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 87 39 PIN of HDC8000 = 1.8V ? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 88 Check the voltage at replace U8010 C8038 = 1.8V Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 89: Speaker Part

    ANT8000, ANT8001 Replace rear ass'y with speaker module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 90: Receiver Part

    Check the signals on Replace U8010 V8000, V8001 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 91 C4016, C4012, F4002 L4023 Resolder or Replace U4005 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 92 ( short, open, crack, etc.) Change U4004 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 93 R4013, C4058, C4064 Resolder or Replace U4012 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 94 ELAVDD_7P0=5. 8~7.9V(C9040) Replace th e LCD module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 95 26 MHz(C9010) Replace the camera module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 96 24 MHz(L9002) Replace the camera module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 97 1.85V / 3.3V => U7000 Replace LCD Module Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 98 Resolder : U7011 Replace Motor or PBA Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 99 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 100 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 101 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 102 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 103 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 104 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 105 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 106 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 107 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 108 R esolder or change UCP601 Receiver is O.K? Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 109 R esolder or change Receiver is O.K? UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 110 R esolder or change Receiver is O.K? UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 111 R esolder or change Receiver is O.K? UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 112 R esolder or change Receiver is O.K? UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 113 R esolder or change Receiver is O.K? UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 114 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 115 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 116 C3013 = 1.2 V R esolder or change UCP3002 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 117 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 118 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 119 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 120 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 121 C3013 = 1.2 V R esolder or change UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 122 Resolder or replace U7014 Check the Status of U7014 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 123 8-4. Service Schematics -NC Point(Top View) UCP601 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

  • Page 124: Reference Abbreviate

    ― TDM : Time Division Multiplexing ― TS : Transport Stream Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.
  • Page 125 This Service Manual is a property of Samsung Electronics Co.,Ltd. ⓒ Samsung Electronics Co.,Ltd Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2016. 02. Rev 1.0...

Table of Contents
