Karlsson DUO CUCKOO KA5789 Instruction Manual

INSTRUCTION MANUAL | WALL CLOCK DUO CUCKOO KA5789
INSTRUCTIONS
1. Volume Switch
2. Battery Compartment
3. Soft Set Button
4. Time Setting Knob
5. Battery Compartment 2
BATTERY INSERTION AND SETUP
INSERT BATTERIES:
Insert 2 "AA" batteries into Battery Compartment 1 (2).
Insert 1 "AA" battery into Battery Compartment 2 (5).
Follow the indicated anodes (+) and cathodes (–).
Adjust the Time Setting Knob (4) to set the time.
Adjust Volume:
The Volume Switch (1) has three positions: left (mute),
middle (low), and right (high).
Move it to the desired position.
Configure the Bird Voice:
Note: The programmed silent period is from 22:00 to 5:00,
so the initial bird voice playback starts at 5:00 AM. You
need to indicate whether the current local time is during
the day or night.
Setting time 5:00
(present time)
to
5:59
pressing times 0
Setting time 17:00
(present time) to
17:59
pressing times 12
(1)
(2)
(3)
6:00 7:00 8:00
to to to
6:59 7:59 8:59
1 2 3
18:00 19:00 20:00
to to to
18:59 19:59 21:59
13 14 15
If the time is between 5:00 and 5:59: No button press is needed.
If the time is between 6:00 and 6:59: Press the Soft Set Button
(3) once.
If the time is between 7:00 and 7:59: Quickly press the Soft Set
Button (3) twice (do not let the bird sound play).
If the time is between 8:00 and 8:59: Quickly press the Soft Set
Button (3) three times (do not let the bird sound play).
If the time is between 9:00 and 9:59: Quickly press the Soft Set
Button (3) four times (do not let the bird sound play).
PLEASE REFER TO THE FOLLOWING TABLE FOR
DETAILED PRESSING TIMES.
9:00 10:00 11:00
to to to
9:59 10:59 11:59
4 5 6
21:00 22:00 23:00
to to to
21:59 22:59 23:59
16 17 18
12:00 13:00 14:00
to to to
12:59 13:59 14:59
7 8 9
00:00 01:00 02:00
to to to
00:59 01:59 02:59
19 20 21
(4)
(5)
15:00 16:00
to to
15:59 16:59
10 11
03:00 04:00
to to
03:59 04:59
22 23
