Summary of Contents for Truper Expert SOIN-250
- Page 1 Manual Inverter Welder 50 % Work Cycle Applies for: Code Model 17411 SOIN-250 SOIN-250 Read the user’s manual thoroughly CAUTION before operating this tool.
-
Page 2: Table Of Contents
Contents CAUTION Technical specifications Power requirements To gain the best performance of the tool, prolong the duty life, General power tools safety warnings make the Warranty valid if necessary, and to avoid hazards Safety warnings for inverter welders of fatal injuries please read and understand this Manual before Parts using the tool. -
Page 3: Technical Specifications
Technical specifications SOIN-250 Code 17411 Description Inverter welder Input Voltage 220 V Frequency 50 Hz / 60 Hz Current 55 A Input Rated Capacity 12.1 kVA No. of Phases 2 Phases Output Open Circuit Voltage SMAW: 14.8 V c.c. TIG: 14.8 V c.c. -
Page 4: General Power Tools Safety Warnings
General power tools safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Inverter Welders
Safety warnings for inverter welders Protection Equipment for Welding Prevent Injuries and Accidents WARNING WARNING • Wear a welding mask to protect eyes • Risks of electric shock: and face when soldering. Assure the mask protective glass An electric shock coming from the soldering electrode may shade is adequate for the soldering process to carry out. -
Page 6: Parts
Parts Carrying Handle Thermal Protection Light Welding Process Selector (SMAW o TIG) Grounding Clamp to the Work Piece Arch Current Dial Control Negative Connection ( - ) Positive Connection ( + ) Electrode Holder Power Cord Carrying Strap Switch Ventilation Slots Hammer-Brush for Slag Removal... -
Page 7: Installation (Smaw)
Installation (SMAW) Connections To prevent an electric shock, the user must CAUTION see the information in “Power Requirements” in page 3 and 5. • The fast connections of the electrode holder and the ground clamp are inserted and turned one quarter of a turn in a clockwise direction in the outlets set in the front panel to secure perfectly. -
Page 8: Installation (Tig)
Installation (TIG) TIG Connection • This inverter welder can also be used for TIG welding, a high-quality welding process with non-consumable tungsten electrodes and arch protected with inert gas like argon gas o helium. • TIG welding is ideal to weld stainless steel, iron and copper. •... -
Page 9: Start Up
Start up Preparation • Only through experience, practice and care a good welding process can be guaranteed. • The factors arousing in the welding process are many: current required, distance between the electrode and the work piece, 45° 45° speed and direction of the welding, thickness and type of material, position of the work piece and welding direction, and also, the gauge, material and covering of the electrode. - Page 10 Start up Examples of welding Correctly Applied Welding Electrode movement too fast and / or very low current. Electrode movement too slow and / or very high current. Electrode too separated from the work piece. Spiral movement. Half-Moon movement. Bevel Zigzag Movement.
-
Page 11: Maintenance
Maintenance • The correct use and regular cleansing extend the useful life of the welder. CAUTION • Only qualified personnel shall carry out repairs. We recommend visiting a TRUPER Authorized Service Center to repair your welder, get supplies or accessories. Regular Maintenance Storage •... -
Page 12: Troubleshooting
Troubleshooting Problem Cause Solution The thermal protection • The welder has no adequate ventilation. • Keep the welder least 11.8” away from any walls at to light is ON. allow air circulation. • Environment temperature is too high. • The welder will recuperate once the temperature gets back to the right range to operate. -
Page 13: Authorized Service Centers
Authorized service centers In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. DE TODO PARA LA CONSTRUCCIÓN FIX FERRETERÍAS AGUASCALIENTES... -
Page 14: Warranty Policy
Model Brand 17411 SOIN-250 Warranty. Duration: 2 years. Coverage: parts, components and workmanship against manufacturing or operating defects, except if used under conditions other than normal; when it was not operated in accordance with the instructive; was altered or repaired by personnel not authorized by TRUPER .
