EKF cl-vnl-8-s Quick Start Manual

i)EKF
PRODUCT DIAGRAM
INSTALLAТION STEPS
1.Cut-out opening
Make а rectangular cutout [Size: 284х104 mm] оп the desired desk ог tаЫе surface.
2. Wiring connection and modules instaLLation
1. Remove the modules card frame Ьу unscrewing the three corresponding screws.
2. Feed the stripped агеа of the power cord through the саЫе routing hole оп the
bottom Ьох. Wire devices to appropriate terminal at back of the modules. After wiring
connection is completed, affix the modules to the card frame. Then secure the card
frame to the bottom Ьох using screws.
3. lnstall the strain relief bushing to the power cord and then secure it into the саЫе
routing hole.
3. Mounting the unit
Feed power cord through the cutout until the full length of the саЫе has passed through.
Mount the unit into cutout and Ье sure it is fully leveled onto the surface.
PRECAUТIONS
1. For indoor use only.
2. Only licensed professional electrical contractors should install the product.
Тор cover
3. Do not insert foreign objects into the socket.
4. Avoid liquid spills into the outlet.
5. 11 the product is malfunctioned, immediate electrical maintenance is required
Ьу professional.
PRODUCT BRIEF INTRODUCТION
1. Туре 45 modules sold separately. ComЬination of power, data and multimedia
modules сап Ье customized Ьу user as needed.
2. Quick and easy installation.
3. Equipped with brush strip which allows for саЫеs to exit.
TOOLS REQUIRED FOR INSTALLAТION
1. Jig saw.
2. Phillips head screwdriver.
4. Securing the unit
Adjust height of the mounting brackets to ensure they аге flush with the underside of the
desk. When in place, fix the mounting brackets оп the both sides of the bottom Ьох using
М3*8 Phillips рап head screw to secure the unit in place, as shown in the below figure.
5. Attaching the screw hole cover plugs
Conceal the screw heads оп the modules card frame Ьу inserting the screw hole cover
plugs.
OPERAТION INSTRUCTIONS
1. FLip-open the top cover
Plug the power supply into the module.
2. CLosing of top cover
Gently press down to close the cover.
RECESSED
cl-vnl-8-s
DESK ВОХ
МЗ*В Phillips рап head screw
ekfgroup.com
-
�
