BeLeaf Smart Socket
CH 1
I
CH 2
CH 3
CH 4
J
Status
RS 485 IN
A.
Date and time
B.
Channel status
C.
Confirm button
D.
Return button
E.
Up button
F.
Down button
G.
Connect to BeHive host
H.
Connect to the next device
I.
4 channel status indicator lights, the light
is on to indicate a connection, and the
light is off to indicate no connection
J.
Power indicator
Specification
Device Operating
Voltage
Total Input Current
Maximum Current
per Channel
18 : 12 : 00
CH2
B
C
D
OK
RS 485 OUT
G
H
120-240VAC 50/60Hz
＜ 15A (US)
＜ 13A (UK)
＜ 10A (AU)
＜ 16A (EU)
8A
A
11/23
VALVE
OFF
E
F
BSS-E4
Smart Socket
