Waytronic WT-C21 User Manual

Smart socket
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

1.
Introduction
This product is built in GSM module, controlling socket through SMS command;It can perform functions such as
power supply change notification, time period, temperature and temperature alarm settings, and status query. The
user can use mobile phone to control electric appliances at any time and any place, making home appliances more
intelligent.
For your better understanding of the installation and configuration of your product, please read the instruction
carefully.
1.
1 Appearance introduction
Temperature
Sensor
SIM card
insert direction
SIM card slot
Shenzhen Waytronic Electronics Co., Ltd
WT-C21 Smart Socket
User Manual
V1.00 Version
Plug
1
Model No.: WT-C21
USB port
Indicator lamp
Reset key
Power key
Output interface

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WT-C21 and is the answer not in the manual?

Questions and answers

Summary of Contents for Waytronic WT-C21

  • Page 1 Shenzhen Waytronic Electronics Co., Ltd Model No.: WT-C21 WT-C21 Smart Socket User Manual V1.00 Version Introduction This product is built in GSM module, controlling socket through SMS command;It can perform functions such as power supply change notification, time period, temperature and temperature alarm settings, and status query. The user can use mobile phone to control electric appliances at any time and any place, making home appliances more intelligent.

  • Page 2: Performance Parameter

    Shenzhen Waytronic Electronics Co., Ltd Model No.: WT-C21 2. Key and Function The Status of Name Operating mode Function Remarks indicator lamp Keep press for 6 Restore factory Reset key The buzzer "beep" four times seconds setting Open output Power key blue light on The buzzer "beep"...
  • Page 3 Shenzhen Waytronic Electronics Co., Ltd Model No.: WT-C21 4.2 Setting output default on or off after the device is powered on SMS commands Function Message reply The output is open after #21#1# Successfully setted the default output is the device is powered on...
  • Page 4 Shenzhen Waytronic Electronics Co., Ltd Model No.: WT-C21 (1) Scene 1: Opening the socket output at low temperature SMS commands Message reply #159#0#T0#T1#TIME1#TIME2# Set successfully For example：The SMS command is :#159#0#25#30#1630#1730#.159 means set code;0 means scene 1;25 means minimum temperature;30 means maximum temperature; 1630#1730 means time period（...
  • Page 5 Shenzhen Waytronic Electronics Co., Ltd Model No.: WT-C21 4.8.2 Opening/Closing the scene mode SMS commands Function Message reply Open the scene Open the function of temperature #159#1# mode control Close the scene Close the function of temperature #159#0# mode control...

  • Page 6: Faq And Solutions

    Temperature Sensor User manual Disclaimer Shenzhen Waytronic Electronics Co., Ltd. reserves the right to modify the use of materials without notifying customers. The new product specifications will be subject to the latest version of the usage data. Contact Us Shenzhen Waytronic Electronics Co., Ltd.
