Summary of Contents for Janich & Klass Box-PC 3
- Page 1 Box-PC 3 Installation Manual Version: Date: 11.02.2022 Documentname: Installation Manual BoxPC 3 R1.1.docx...
-
Page 2: Table Of Contents
Installation Manual Box-PC 3 Table of contents COPYRIGHT ..........................3 TRADEMARK ..........................3 DISCLAIMER ..........................3 SAFETY ............................3 REVISIONHISTORY ........................4 NOTES ON CE MARKING ......................5 SCOPE OF DELIVERY ........................5 VIEW OF THE CONNECTION PAGE ....................6 COMMISSIONING ........................ -
Page 3: Copyright
Installation Manual Box-PC 3 1 Copyright © 2024 Janich & Klass Computertechnik GmbH. All rights reserved. Printed in Germany. The information contained in this documentation is the property of Janich & Klass Computertechnik GmbH. Without the written permission of Janich & Klass Computertechnik GmbH, neither the receipt nor the possession of this information shall create any right to reproduce or publish any part thereof. -
Page 4: Revisionhistory
Installation Manual Box-PC 3 • The device contains electrostatically endangered components. Electrostatic discharges by the human body or similar must therefore be avoided at all costs, e.g. by using a grounded wristband. This is especially true before changing assemblies. • Protect the device from moisture. Under no circumstances should objects or liquids get into the device. -
Page 5: Notes On Ce Marking
Installation Manual Box-PC 3 6 Notes on CE marking This device meets the protection requirements laid down in the Directives of Council of the European Community on the approximation of the laws of the Member States relating to electromagnetic compatibility (89/336/EEC and 93/97/EEC). -
Page 6: View Of The Connection Page
eth0 eth2 eth1 1000 1000 1000 COM1 CFast 1000 HDMI POWER eth3... -
Page 7: Commissioning
Installation Manual Box-PC 3 9 Commissioning 9.1 Checking main voltage The main input voltage of the device must be 230V 50Hz Current consumption max. 0.8A ATTENTION! Under no circumstances should the device be operated with mains voltages other than those specified above! 9.2 Installation of the device... -
Page 8: Main Connection
Installation Manual Box-PC 3 9.3 Main connection Once the mains voltage has been checked, the device must be connected to the mains via the Phoenix Combicon plug marked 'POWER'. The protective conductor on 'PE' must not be omitted. In addition, the device must be grounded via the additional 6mm threaded bolt with a short 10mm2 cable. -
Page 9: Connecting Peripherals
Installation Manual Box-PC 3 9.6 Connecting Peripherals 9.6.1 General information If peripherals are to be connected to interfaces, shielded cables must be used. Basically, the cable shield should be connected to the connector housing at both ends. However, if the... -
Page 10: Usb
Installation Manual Box-PC 3 9.6.4 USB The four sockets labelled 'USB' are used to connect USB peripherals (Universal Serial Bus). The interfaces comply with the USB specification 2.0 or 3.0 and are "hot-pluggable", i.e. they may be plugged in or unplugged during operation. -
Page 11: Changing Fuses
Installation Manual Box-PC 3 12 Changing fuses To protect against fire, there is a fine fuse in the device: • Power Supply Fuse:If this fuse needs to be replaced, please only use 5x20mm fuses with the characteristics 4A/250V, time-lag. 13 Specifications Metrics W x H x D: 83mm x 230mm x 250mm, weight approx. - Page 12 Installation Manual Box-PC 3 © 2022 by Janich & Klass Computertechnik GmbH, Wuppertal Janich & Klass Computertechnik GmbH, Zum Alten Zollhaus 24, D-42281 Wuppertal Germany Tel.: +49 (0)202 2708-0 Fax: +49 (0)202 700 625 http://www.janichklass.com Side 12 (11.02.2022)
