- Page 1 CM712x Low Power Audio DSP&CODEC Hub System CM712x Audio DSP＆ ＆ ＆ ＆ CODEC Hub System User Guide Dec. 18, 2017 www.cmedia.com.tw Rev. 1.0 ︱ Page 1/7 Copyright © C-Media Electronics Inc.
- Page 2 CM712x Low Power Audio DSP&CODEC Hub System 1. Connect the USB audio control board and CM712X Demo Board www.cmedia.com.tw Rev. 1.0 ︱ Page 2/7 Copyright © C-Media Electronics Inc.
- Page 3 CM712x Low Power Audio DSP&CODEC Hub System 2. Definition of the pin header (a).Ground pins (b).Main Function www.cmedia.com.tw Rev. 1.0 ︱ Page 3/7 Copyright © C-Media Electronics Inc.
- Page 4 J102 (BCLK1 signal from J91, connect pin1 to pin2, align left) J101 (LRCK1 signal from J91, connect pin1 to pin2, align left) J2 (connect 1.8V power, please insert a jumper) www.cmedia.com.tw Rev. 1.0 ︱ Page 4/7 Copyright © C-Media Electronics Inc.
- Page 5 J47 (MONOVDD 3.3V power, please insert a jumper) Notes: J103 (MCLK selection: Connect pin 3 to pin 4, the signal is from the oscillator (12.288MHZ) of CM7120 PCB board. www.cmedia.com.tw Rev. 1.0 ︱ Page 5/7 Copyright © C-Media Electronics Inc.
- Page 6 CM712x Low Power Audio DSP&CODEC Hub System 3. Especial Attention Control： ： ： ： a).J55(SEL1_MODE)，J117(SEL2_MODE) SEL2_MODE SEL1_MODE I2C Control High Flash Boot High SPI Control HIgh High SLIMBUS Control www.cmedia.com.tw Rev. 1.0 ︱ Page 6/7 Copyright © C-Media Electronics Inc.
- Page 7 Low Power Audio DSP&CODEC Hub System b).J53 of DBVDD should be connected to 3.3V, Because DBVDD is also shared with the pin 8 of U11A(W25Q16JV Flash),this pin is needed 3.0~3.6V power。 www.cmedia.com.tw Rev. 1.0 ︱ Page 7/7 Copyright © C-Media Electronics Inc.
