TOLSEN TOOLS FORCE XPRESS 79559 Instruction Manual

Electric router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
79559
ELECTRIC ROUTER
INSTRUCTION MANUAL
SAVE THIS MANUAL !
You will need this manual for safety instructions, operating procedures and warranty.
Put it and the original sales receipt in a safe dry place for future reference.
220-240V~50/60Hz 2100W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FORCE XPRESS 79559 and is the answer not in the manual?

Questions and answers

Summary of Contents for TOLSEN TOOLS FORCE XPRESS 79559

  • Page 1 79559 ELECTRIC ROUTER INSTRUCTION MANUAL 220-240V~50/60Hz 2100W SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference.

  • Page 2: Safety Instructions

    SAFETY SAFETY INSTRUCTIONS WARNING Remove the plug from the socket before carrying out any adjustment, servicing or maintenance. Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Make sure the voltage corresponds to the type label on the unit. Packing materials are no toys! Children must not play with plastic bags! Danger of suffocation! The power tool noise output may exceed 85dB(A) at the workplace.
  • Page 3 SAFETY 4. Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off.
  • Page 4 SAFETY o) Keep your hands away from the routing area and router bit cutter. Hold the auxiliary handle or an insulated gripping surface with your second hand p) NEVER start the router while the cutter is touching the workpiece q) Ensure the plunge spring is always fitted when using hand‐held r) Ensure the cutter has completely stopped before plunging to the collet lock position s) The maximum speed of the router bit/cutter must be at least as high as the maximum speed of the power tool t) Parts of the router bits may become hot during operation.

  • Page 5: Specifications

    SPECIFICATIONS SPECIFICATIONS 220-240V~50/60Hz Electrical Rating 2100W Rated Power : 12000-23000/min Motor No Load Speed Max. Chuck Diameter 1/2” (12mm) plunge stroke 0-50mm Explanation of the symbols Double insulated for additional protection. Read the instruction manual before using. CE conformity. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste.
  • Page 6 SPECIFICATIONS FUNCTIONS 1. Le Handle 2. Adjusting knob 3. Brush Access Cover 4. Variable Speed Dial 5. Right Handle 6. Depth Scale 7. Stopper pole 8. Fast-feed button 9. Stopper block 10. Collet Nut 11. Safety Button 12. ON/OFF Switch 13.

  • Page 7: Functional Description

    SETUP FUNCTIONAL DESCRIPTION CAUTION: Always be sure that the tool is switched off and unplugged before adjusting or checking function on the tool. Adjusting the depth of cut 1. Adjusting knob 2. Lock lever 3. Stopper pole 4. Fast-feed button 5.
  • Page 8 SETUP CAUTION Since excessive cutting may cause overload of the motor or difficulty in controlling the tool, the depth of cut should not be more than 15 mm (19/32") at a pass when cutting grooves with an 8 mm (5/16") diameter bit. When cutting grooves with a 20 mm (13/16") diameter bit, the depth of cut should not be more than 5 mm (3/16") at a pass.
  • Page 9 SETUP ASSEMBLY CAUTION Always be sure that the tool is switched off and unplugged before carrying out any work on the tool 1. Sha lock 2. Wrench Installing or removing the bit CAUTION Install the bit securely. Always use only the wrench provided with the tool. A loose or overtightened bit can be dangerous.

  • Page 10: Operation

    SETUP OPERATION CAUTION Before operation, always make sure that the tool body automatically rises to the upper limit and the bit does not protrude from the tool base when the lock lever is loosened. Before operation, always make sure that the chip deflector is installed properly. Always use both grips and firmly hold the tool by both grips during operations.
  • Page 11 SETUP Templet guide (optional accessory) The templet guide provides a sleeve through which the bit passes, allowing use of the tool with templet patterns. To install the templet guide, pull the lock plate lever and insert the templet guide. 1.Bit 1.

  • Page 12: Maintenance

    MAINTENANCE MAINTENANCE CAUTION Always be sure that the tool is switched off and unplugged before attempting to perform inspection or maintenance. Replacing carbon brush Limit mark Remove and check the carbon brushes regularly. Replace when they wear down to the limit mark. Keep the carbon brushes clean and free to slip in the holders.

  • Page 13: Ce Declaration Of Conformity

    CE DECLARATION OF CONFORMITY SUZHOU TOLSEN TOOLS CO.,LTD. 198 HUASHAN ROAD, ZHANGJIAGANG, JIANGSU, CHINA Declare that the product 79559 ELECTRIC ROUTER Complies with the essential health and safety requirements of the following Directices: council directive 2006/42/EC Standards and technical specifications referred to:...
  • Page 14 SUZHOU TOLSEN TOOLS CO.,LTD. www.tolsentools.com TOLSEN is a trademark or registered trademark of TOLSEN TOOLS. All rights reserved. SCAN TO VISIT TolsenWorld MADE IN CHINA PRODUCT LINK...
