The ramp people TRP608 Series User Instructions

User Instructions
Economy folding Ramp
TRP608-Range
Product Code SKU Length
610mm
TRP608-2
914mm
TRP608-3
1219mm
TRP608-4
1500mm
TRP608-5
1829mm
TRP608-6
*Product weights are approximate and may vary.
General Safety Warning
Please ensure these instructions are fully
read and implemented. Failure to do so
may result in injury to the user. Retain in a
safe place for future reference.
Intended Use
This folding ramp, TRP608- is designed to
provide access for manual or powered
wheelchair, walkers and mobility scooters
(and their carers, if appropriate) over
thresholds, steps and curbs. There are
various available length versions in the range,
see table above for size information
Unpacking
•
No tools are required to assemble this
product.
•
Remove item from packaging; Check
for damage. If you see any, or
suspect a fault, do not assemble or
use the product; contact your supplier
immediately.
Usable Width Overall Width Product weight Maximum load
715mm 720mm
715mm 720mm
715mm 720mm
715mm 720mm
715mm 720mm
5.4kg
8kg
10.4kg
13.2kg
15.8kg
Safety Precautions
When choosing a ramp, the length, and therefore
the angle of the ramp depend upon:
•
The height to be raised
•
The type of wheelchair or scooter
•
The weight of the wheelchair or scooter
and the user
•
The strength of the helper or user.
As a general guide, a minimum gradient of 1 in 6
is suggested, although 1 in 8 is recommended,
when the user is seated on the wheelchair or
scooter. If you have low clearance you may
require a longer ramp.
For loading an unmanned wheelchair or scooter
into a vehicle, a higher gradient can be used, but
this should not exceed 1 in 3.3 In addition to this, it
is important that you refer to your vehicle's user
guide for the proper degree of incline/decline and
direction before using the ramp.
- Never exceed its recommendations.
•
Only carry the ramp using the carry
handles. Take care when lifting; follow
standard manual handling procedures.
•
Take particular care when using the ramp
in wet/damp conditions.
Capacity
height (1:6)
100mm 300kg
150mm 300kg
200mm 300kg
250mm 300kg
300mm 300kg
