OPERATOR'S MANUAL

DIVISION 1

GENERAL

BD.01/Rev.0/10.01.2022

Table of Contents

Need help?

Do you have a question about the Classic trailer and is the answer not in the manual?

Questions and answers

Summary of Contents for Hippo Classic trailer

Page 1 OPERATOR’S MANUAL DIVISION 1 GENERAL BD.01/Rev.0/10.01.2022...
Page 2 BD.01/Rev.0/10.01.2022...
Page 3 NAME AND THE ADDRESS OF THE MANUFACTURER Mega Çelik Yapı Sanayi ve Ticaret Limited Şirketi Ataköy 5. kısım A-10 Blok D:4 Bakırköy / İstanbul / TÜRKİYE Telefon : +90 212 559 98 66 : +90 212 560 11 29 e-posta : info@megacelik.com.tr : www.megacelik.com.tr NAME AND THE ADDRESS OF THE ASSEMBLY PLANT Mega Çelik Yapı...
Page 4 BD.01/Rev.0/10.01.2022...
Page 5: Table Of Contents
INDEX BEFORE USE Documents supplied with the trailer Data reconciliation between documents Registration and insurance requirements First inspection Authorized dealers and services Scope of delivery SAFETY Usage 2.1.1 Proper use 2.1.2 Improper use Safe use rule 2.2.1 Terms and symbols used 2.2.2 Cautions regarding use Stickers on the trailer...
Page 6 INDEX Components and their functions 4.7.1 Tyres 4.7.2 Electric connection 4.7.3 Lighting and light signalling devices 4.7.4 Jockey wheel 4.7.5 Adjustable support leg MAINTENANCE Maintenance concept Maintenance intervals Maintenance table Things you can do yourself 5.4.1 Tyres 5.4.2 Lubricants and greasing points 5.4.3 Bolt –...
Page 7: Before Use
1. BEFORE USE 1.1. Documents supplied with the trailer User Manual: The user manual contains the basic steps for using the trailer and provides a lot of additional information. Before using the trailer for the first time, read the user manual carefully and follow all instructions and steps completely.
Page 8: Safety
Failure to comply with the warnings and instructions in the documents accompanying the distribution,  Exposure of animals and people  Transportation of goods for which Hippo Trailer® trailers are not equipped and approved for transport  Hot and fluid products such as tar and concrete, ...
Page 9: Safe Use Rule
2. SAFETY Pay particular attention to the following:  The interior of the trailers is not waterproof or moisture-proof, except for those designed to transport refrigerated products.  The trailer's small load is only protected against splashing water, depending on the existing cover. ...
Page 10: Cautions Regarding Use
2. SAFETY 2.2.2. Cautions regarding use  Your vehicle's construction: The standard structure of your trailer should not be changed. (Example: welded addition to the chassis, tires that are not the original size, etc.) Any changes to the trailer from its factory state will reduce safety and durability and will negatively affect warranty conditions.
Page 11 2. SAFETY Only carry goods approved for the relevant trailer type. Unauthorized persons may be injured or killed in the trailer and in the access area of the trailer. Only trained persons are allowed to be in and use the trailer. Unauthorized persons may be injured or killed in the trailer and in the access area of the trailer.
Page 12: Stickers On The Trailer
2. SAFETY 2.3. Stickers on the trailer Danger of hand getting stuck Danger of hand falling Danger of hand slipping Do not step here Use protective boats Use protective gloves Wear protective overalls Wear a safety vest BD.01/Rev.0/10.01.2022...
Page 13: Product Explanations
3. PRODUCT EXPLANATIONS 3.1. Vehicle construction 3.1.1. Control components and their functions 3.1.1.1. Unbraked trailers BD.01/Rev.0/10.01.2022...
Page 14 3. PRODUCT EXPLANATIONS BD.01/Rev.0/10.01.2022...
Page 15: Braked Trailers
3. PRODUCT EXPLANATIONS Coupling head 16 Push-rod fixation pin (D pin) Trigger 17 End outline marker lamp Coupling connection lever 18 Ramp fixing pin Retaining cable 19 Ramp Trailer socket 20 Cycle front wheel holder Manufacturer’s plate 21 Tail lamp Jockey wheel height adjustment lever 22 Registration plate space Jockey wheel bracelet...
Page 16 3. PRODUCT EXPLANATIONS Coupling head 17 Push-rod fixation pin (D pin) Trigger 18 End outline marker lamp Coupling connection lever 19 Ramp fixing pin Break-away cable 20 Ramp Trailer socket 21 Cycle front wheel holder Park brake lever 22 Tail lamp İmalatçı...
Page 17: Markings
3. PRODUCT EXPLANATIONS 3.2. Markings Vehicle Identification Number Manufacturer’s plate Coupling EC Approval Number BD.01/Rev.0/10.01.2022...
Page 18: Driving With Trailer
4. USAGE 4.1. Driving with trailer 4.1.1. Check-liste before use Is there any external damage to the trailer? Are all parts of the trailer complete? Is the jockey wheel properly secured in the up position? Is the coupling properly secured to the ball? Is the trailer plug properly secured to the trailer socket of the towing vehicle? Are the retaining rope or, if provided, the breakaway rope properly attached? Is the parking brake released, if provided?
Page 19: Republic Of Turkey
4. USAGE Do not exceed technical or legal speed limits for the trailer. Adjust your speed according to road conditions 4.1.2.1. Republic of Turkey: Please remember that the speed limit for vehicles towing trailers within the borders of the Republic of Turkey is 10 km/h less than the limit determined according to the category of the towing vehicle.
Page 20 4. USAGE BD.01/Rev.0/10.01.2022...
Page 21: Retaining Cable And Breakaway Cable
4. USAGE 4.2. Retaining cable and breakaway cable It is necessary to secure the train using a safety cable between the trailer and the towing vehicle. It can save lives in an emergency. The legal status and penalties for non-compliance with the use and attachment of the breakaway cable are country-specific.
Page 22: Safety Signs On The Coupling
4. USAGE 4.3. Safety signs on the coupling Symbol Colour Meaning Illustration Improper connection or wear limit exceeded Prooperly connected and ready Green to go Open Improper connection or none wear limit exceeded Prooperly connected and ready none to go Improper connection or Amber wear limit exceeded...
Page 23: While Connecting
4. USAGE 4.4.2. While connecting  Place the trailer coupling on the tow ball.  If the trailer needs to change position, re-secure the trailer using wheel chocks and the handbrake.  Open the coupling. If provided, the safety indicator on the coupling should be in the red zone or the “X”...
Page 24: Loading
4. USAGE Never grease the inside of the coupling and the towbar ball. Just remove dust and dirt. A greased towbar ball can weaken the working effect of the coupling. There is an increased risk of slipping. 4.6. Loading 4.6.1. Important terms Maximum permissible laden mass: Indicates the maximum permissible weight including the loads your trailer will carry.
Page 25: Loading General Cargo And Bulk Loads
4. USAGE 4.6.2. Loading general cargo and bulk loads When loading a trailer on a rough road surface or in a sloped position; it may not be possible to place the load properly on the axle or distribute the bulk loads evenly in the loading area. The position of the load may change and the trailer may tip over uncontrollably.
Page 26: Loading And Unloading
4. USAGE 4.6.3. Loading and unloading If the permitted load of the ramps is exceeded, the driving ramps may be damaged. Safe loading cannot be guaranteed. The trailer and the load may be damaged. Persons in the direct area of effect may be injured or killed.
Page 27 4. USAGE Proper load distribution  The load center of gravity is directly over the axle or as close as possible.  Distributed loads are evenly distributed over the loading area.  The loading area is not loaded locally.  The load is not on one side of the loading area.
Page 28 4. USAGE Improper load distribution The load's centre of gravity is ahead of the axle(s) Possible consequences:  The load on the hitch ball is more than it should be,  The braking effectiveness, road holding and driving characteristics of the train are impaired. The load's centre of gravity is behind of the axle(s) Possible consequences: ...
Page 29: Special Characteristics
4. USAGE Loading the load unevenly close to the sides Possible consequences:  Braking efficiency, road holding and driving characteristics are impaired.  The risk of skidding and skidding increases.  The wear of trailer components and coupling increases. 4.6.5. Special characteristics Bulk loads High and wide superstructures may encourage users to overload bulk cargo.
Page 30: Securing The Load
4. USAGE 4.6.6. Securing the load Driving with an unsecured load: The load can slip and get lost. Sliding loads can affect optimum road holding. The risk of skidding increases. Before each journey, check that the load is secured firmly. Do not use damaged or unsuitable load securing equipment.
Page 31 4. USAGE Direct connection Tie-down connection Connection part Load Proper combination Eyebolt 45° 95 kg DIN 12195-2 Vertical 140 kg 45° 45 kg D ring Vertical 75 kg Miscellaneous load securing parts Tarpaulin BD.01/Rev.0/10.01.2022...
Page 32: Components And Their Functions Tyres
4. USAGE 4.7. Components and their functions 4.7.1. Tyres Tires of sizes not included in the tire list should not be installed on your trailer. The dimensions of the tires that can be installed according to the vehicle weight are given in the table below. TABLE: COMPATIBLE TIRE SIZES Tire size Capacity...
Page 33: Electric Connection
4. USAGE         195 R15C 104 / 102 1.650         215/75 R15C 100 / 97 1.600         225/75 R16C 118 / 116 2.640 ...
Page 34: Jockey Wheel
4. USAGE LEFT 1. Front end outline lamp (white) 2. Side marker lamp RIGHT LEFT (amber) 3. Rear end outline lamp (red) Side marker lamp (amber) Rear end outline lamp (red) Front end outline lamp (white) 4.7.4. Jockey wheel BD.01/Rev.0/10.01.2022...
Page 35: Adjustable Support Leg
4. USAGE To put it in the parking position  Loosen the clamp by opening the locking lever,  When the wheel is a few centimeters away from the ground, turn the lever in the opposite direction and tighten the clamp, ...
Page 36 4. USAGE To put it in park position  Remove the locking element and turn the parking support 90° towards the ground,  Re engage the locking element,  Replace the lever and turn until the support leg touches the ground. To put it in road position ...
Page 37: Maintenance
Do not neglect the operations and routine checks in the maintenance calendar. For part replacements, obtain your spare parts from Hippo Trailer approved dealers and the factory. For malfunctions and repairs that you cannot fix or perform yourself or that must be done by trained expert personnel, contact a specialist or service workshop.
Page 38 5. MAINTENANCE 5.3. Maintenance table Components Description Check the function of all locks, locking cylinders, hinges Components with mechanical x and other mechanical functional elements, clean and functions lubricate any lubrication points. Check the function of all switches, sockets, electrical Light signaling devices,...
Page 39: Tyres
5. MAINTENANCE Visually inspect for damage and corrosion, check rivet and Bed covers and ramps screw connections Components Description Floor Visually inspect for damage and corrosion Secure of load Visually inspect all fixing profiles and eyebolts for damage. Check the winch, including the wire rope, for function and damage.
Page 40: Lubricants And Greasing Points
5. MAINTENANCE Tire change Only jack up the trailer when it is empty. If necessary, take additional precautions to secure the vehicle when it is loaded. Choose a jack that is suitable for the maximum loaded weight of the trailer ...
Page 41: Bolt - Nut Connections
5. MAINTENANCE • Multi purpose grease DIN 51825 K3K-30 • Synthetic, water repellent, spreadable adhesive lubricant • Machine oil Device Greasing point Recommenden lubricant Ball housing Multi purpose grease Coupling Locking mechanism Multi purpose grease Locking mechanism slide Adhesive lubricant Overrun (greasing nipple) Multi purpose grease Brake control mechanism...
Page 42 5. MAINTENANCE BD.01/Rev.0/10.01.2022...
Page 43: Electrical System
5. MAINTENANCE 5.4.4. Electrical system Maintenance and repair work performed while the trailer electrical system is energized; People may be injured. The trailer electrical system may be damaged. Disconnect the electrical connection between the trailer and the towing vehicle before starting maintenance and repair work. Left Green Grey...
Page 44 5. MAINTENANCE BD.01/Rev.0/10.01.2022...
Page 45 5. MAINTENANCE Lighting equipment Changing bulbs: Changing light bulbs without protective gloves: Light bulbs can break easily and sharp edges can injure you. The natural oil film from the skin and other foreign matter on the hands can impair the durability and functionality of the lamps.
Page 46 5. MAINTENANCE Registration plate lamp Side markers 12V 5W Fuse type 5.5. Possible solutions in case of malfunction Malfunction Probable cause Solution Increased friction in the inertia brake system, Remove dirt and corrosion. Corrosion in the drawbar and brake system Clean and lubricate lubrication Low braking effect points.
Page 47: Painted Surfaces
5. MAINTENANCE surface, leaning to one side. Prolonged exposure to meteorological Clean away corrosion and paint Corrosion on edges conditions and splashing water damaged surfaces. Increased dynamic Tighten connections with torque stress during mobile Loose screw connections wrench, Replace damaged screws 5.6.
Page 48: Powder Coated Surfaces
5. MAINTENANCE This corrosion protection is a long-term and continuous process. The surfaces darken, become matt and form a protective top layer. This protective layer can be damaged by weathering, environmental or mechanical influences. Depending on the thickness of the zinc coating and the type of surface damage, the zinc protective layer can be reshaped independently.
Page 49: Wooden Floors And Walls
5. MAINTENANCE You can use a tarpaulin cleaner to clean the tarpaulin. Apply the tarpaulin cleaner according to the manufacturer's instructions. For printed or glued tarpaulins, first check a small area to make sure that the tarpaulin cleaner does not damage the printed or glued areas. We recommend not cleaning in direct sunlight or at very low temperatures.
Page 50: Periodical Maintenance
6. PERIODICAL MAINTENANCE INITIAL INSPECTION 1. PERIODICAL MAINTENANCE (When received) (1.000 km or 6 months from receiving) Tarih, kaşe ve imza Tarih, kaşe ve imza Sonraki bakım Sonraki bakım 2. PERIODICAL MAINTENANCE 3. PERIODICAL MAINTENANCE (Every 2.000 km or once a year) (Every 2.000 km or once a year) Tarih, kaşe ve imza Tarih, kaşe ve imza...
Page 51 6. PERIODICAL MAINTENANCE Tarih, kaşe ve imza Tarih, kaşe ve imza Sonraki bakım Sonraki bakım BD.01/Rev.0/10.01.2022...
Page 52: Short Term Storage
7. LONG-TERM STORAGE AND PRESERVATION The trailer is constantly exposed to water accumulation and high humidity when parked or stored. Humidity and moisture damage the trailer. The properties of the materials used may change. Accumulated and high humidity may cause corrosion and mold. The materials may swell.
Page 53: Parking
7. LONG-TERM STORAGE AND PRESERVATION 7.1.3. Parking In case of short or long-term outages in public areas, the following additional instructions should be followed:  The lighting equipment and registration number of a trailer parked in a public area should not be concealed.
Page 54: Disposing Of The Trailer Or Its Parts
7. LONG-TERM STORAGE AND PRESERVATION Only the “Classic trailer” model in category O1 can be stored upright. If you are storing your trailer in a closed area, remember that you need a height of 1.1 times its length and a width of at least 3 m.
Page 55: Cases Not Covered By Warranty
C. The warranty covers material defects, workmanship defects and design defects. The warranty is granted only for original parts in the original design of Hippo and its authorized suppliers. The warranty is granted only for accessories and spare parts together with Hippo trailers.
Page 56: Other Details Regarding Warranty
If repairs have not been agreed upon with Mega Çelik within the warranty and guarantee period and/or unauthorized repairs have been commissioned.  If your Hippo trailer has been used, serviced or maintained by unauthorized persons.  If the facts regarding the warranty claim have been distorted.
Page 57: Declarations
9. DECLARATIONS EC Declaration of Conformity Mega Çelik Yapı Sanayi ve Ticaret Limited Şirketi Ataköy 5. kısım A-10 Blok D:4 Bakırköy / İstanbul / TÜRKİYE Telefon : +90 212 559 98 66 Assembly Plant Mega Çelik Yapı Sanayi ve Ticaret Limited Şirketi Cumhuriyet Mahallesi Ali Osman Çelebi Bulvarı...
