Aliaxis Opti Operation & Maintenance Manual

Active control hardware

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Opti Active Control Hardware Operations &

Maintenance Manual

Prepared by

OptiRTC, Inc.

98 North Washington St.

Suite 210

Boston, MA 02114

DISCLAIMER: This document and its contents (the "Materials") are provided by OptiRTC, Inc. (Opti)

solely for use by appropriately licensed and skilled engineering and construction professionals that

are authorized, directly or indirectly, pursuant to a corresponding contract with Opti (a "Contract"),

to use the Materials in connection with the installation of Opti products or related services. Any

other use, and any unauthorized use, misuse, copying, publication or distribution of the Materials, is

strictly prohibited. Subject to the terms of the applicable Contract: (a) the Materials are provided "as

is," without any warranty whatsoever; (b) Opti hereby expressly disclaims any and all representations

and warranties relating to the Materials or the use thereof, express or implied, including, but not

limited to, any warranty of merchantability, title, or ﬁtness for a particular purpose; and (c) under no

circumstances shall Opti be responsible or liable for any damages whatsoever arising from or in

connection with the Materials or any use or misinterpretation thereof, including but not limited to

any consequential, incidental, special, or indirect damages.

Last Updated: October 2024

Confidential Information

Table of Contents

Need help?

Do you have a question about the Opti and is the answer not in the manual?

Questions and answers

Summary of Contents for Aliaxis Opti

Page 1 Opti (a “Contract”), to use the Materials in connection with the installation of Opti products or related services. Any other use, and any unauthorized use, misuse, copying, publication or distribution of the Materials, is strictly prohibited.
Page 2: Table Of Contents
Local Manual Override with Hand Crank Actuator Calibration Battery Back-up Failsafe Position Conﬁrmation Water Level Sensor Calibration Winterization and Dewinterization Winterization Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 2...
Page 3 Valve clog Pressure Transducer Electrical Failure I/O Module disconnection Recurring Overnight Ofﬂine Periods Appendix A: Inspection/Maintenance Log Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 3...
Page 4 1-844-OPTIRTC www.optirtc.com LIST OF FIGURES Figure 1 Opti active control installation Figure 2 Opti Control Panel cover, swing door, and interior Figure 3 Opti Control panel swing door controls Figure 4 Opti control panel annotated with major components Figure 5 Example of actuator and butterﬂy valve...
Page 5: Safety Information
Email: support@optirtc.com Phone: (844) 678-4782, Ext. 2 Necessary Tools This is a list of tools routinely used for maintenance on Opti hardware. Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved.
Page 6 Towels / rags For cleaning solar panel, rain gauge Typical Misc. Supplies Electrical tape, cable ties, wire nuts, etc. Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 6...
Page 7: Introduction
ﬂow, and/or restore ecological ﬂow rates in streams. Each Opti installation is unique and may include hardware not described in this manual. Contact Opti Support for questions about custom hardware maintenance. Figure 1: Opti active control installation Questions? Email us at support@optirtc.com...
Page 8: Hardware Information
Opti Control Panel To open the Opti Control Panel, unlock the lock on the panel. Depending on the type of panel, you may need to unlatch latches on the side, turn knobs, or use a large ﬂathead screwdriver to access the swing door and the interior (Figure 2).
Page 9: Control Panel Interior
Before electrical maintenance, check the wiring and electrical diagrams prepared for your site. Figure 4: Opti control panel annotated with major components Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control...
Page 10: Optithunder Cellular Gateway
The OptiThunder cellular gateway processes all incoming sensor and battery information and connects the panel to the Opti cloud platform. When on site, the status indicator lights will provide the best indication of its behavior. During normal operation, the status light “breathes”...
Page 11: Panel Circuit Breakers
The signal conditioner manages the input signals from the manual controls on the swing door. It converts those inputs into 4-20 mA signals before they are read by the I/O modules. Typically, this is used to open and close the valve from the panel, bypassing Opti’s online controls.
Page 12: Level Sensor Bellows
To minimize error from waves and other disturbances, the pressure transducer is protected in a stilling well. Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 12...
Page 13: Power
Power Opti hardware can be powered by 120 V AC line power or a 24 V DC battery charged by a solar panel. If line powered, there will be a breaker nearby to disconnect power. If power is lost, a backup battery inside the actuator will move the valve to a predetermined failsafe position.
Page 14 Biannually and during every site Stilling Well Clean as needed. Draw down pond if visit trash rack is submerged. Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 14...
Page 15: Control Panel De-Energizing Procedure
Remote Manual Control A user with administrative permissions can override the Opti automatic controls of the valve using the online dashboard. Sign into the Opti web portal and navigate to the system control pod in the top left (Figure 6).
Page 16: Local Manual Override With Control Panel
4. Once maintenance is complete, set the “local valve open” knob back to 0% open and turn the “valve control” switch to the remote position, so that Opti can continue to autonomously control the hardware. Local Manual Override with Hand Crank To physically operate the valve using the hand crank, follow this procedure: Follow the Control Panel De-Energizing Procedure to turn power off.
Page 17: Actuator Calibration
3. Put the valve in the fully closed position (0% open). When you can see the valve is fully closed, record the time. 4. Contact Opti Support and send the three recordings of time and target positions. Battery Back-up Failsafe Position Conﬁrmation The battery back-up failsafe position needs to be conﬁrmed during routine site visits.
Page 18: Winterization And Dewinterization
This is recommended for pressure transducers, TSS sensors, and multiparameter sensors, which may be damaged by freezing water. 3. Once you have locked the site again, notify Opti support via email or phone that the site has been winterized.
Page 19: Troubleshooting
Boston, MA 02114 1-844-OPTIRTC www.optirtc.com 4. Notify Opti Support that the site is now dewinterized. Include water level sensor calibration measurements. 5. Place the site from manual mode into auto mode on the online portal. 6. Monitor the site for one week or until the ﬁrst rain event to ensure it is functioning correctly.
Page 20 Figure 7: Dependency ﬂow diagram Triggers for Maintenance By providing real-time data online on the Opti Dashboard, indicators of maintenance needs can be observed remotely. Please see below for some examples of unusual data patterns (observed on the Opti Dashboard) that indicate when maintenance is required: Valve Clog, Pressure Transducer Electrical Failure, and I/O Module Disconnection.
Page 21 Boston, MA 02114 1-844-OPTIRTC www.optirtc.com Figure 8: Opti dashboard during a valve clog Pressure Transducer Electrical Failure In this example, the water level sensor PT3 (orange) frequently spikes to the high end of its range (Figure 9). Since the sensor outputs an electrical signal, it appears that electrical components may be short-circuited.
Page 22 Figure 10: Sensor datastream failure during I/O module disconnection Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 22...
Page 23 25.2V. During the daytime hours the solar panel generates enough energy to operate the Opti system; as the sun sets the batteries rapidly lose charge and the site goes ofﬂine (Figure 11). The system needs to be energized and de-energized in a speciﬁc order to safely replace the batteries and protect system components, described below.
Page 24 OptiThunder status indicator lights. When the status indicator light is breathing cyan your Opti system is connected to the cloud. Additionally, please verify on your site’s dashboard that Opti Thunder is able to read data from the solar charge controller.
Page 25 Recommended: bring the list of tools found in Inspections_Tool_Kit.pdf to perform maintenance and repairs as needed. Contact Opti Support (support@optirtc.com 1-844-678-4782 ext. 2) during inspection as indicated below or if major repairs are necessary. Component and site photos are required for a complete inspection.
Page 26 Junction box watertight / dry? Y / N Bellows dry? Y / N Comments / Notes: Valve / Actuator: Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 26...
Page 27 Checklist Item Result Clear trash rack of debris Calibration check: Set to 0% and Valve closed position (from screen): 50% open from Opti Panel; verify with Opti support Valve open position (from screen): Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control ©...
Page 28 Davis Texas Electronics: 16: Red 16: Red 20: Green 20: White Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 28...
Page 29 98 North Washington St Suite 210 Boston, MA 02114 1-844-OPTIRTC www.optirtc.com Call Opti Support and test if the rain gauge is working as expected by simulating a precipitation event by pouring small amounts of water into the rain gauge to see if this is reﬂected on the dashboard.
Page 30 Photo documentation of hardware Submit to Opti and general ﬁeld conditions taken Completed By: _______________________ Signature:_____________________Date:___________ Questions? Email us at support@optirtc.com Opti Hardware O&M Manual: Continuous Control © OptiRTC, Inc. 2024. All Rights Reserved. Conﬁdential Information | Page 30...
