CHP SERIES HOT PLATES
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death.
Read the installation, operation and maintenance instructions
thoroughly before installing or servicing this equipment.
11990 Rivera Rd. Santa Fe Springs, CA 90670
www.connertoncooking.com
Installation,
Operation &
Maintenance
Instructions
Warning!
(562) 464 - 9901
1
Advertisement
Summary of Contents for Connerton CHP Series
- Page 1 Installation, Operation & Maintenance Instructions CHP SERIES HOT PLATES For Your Safety Warning! Do NOT store or use gasoline or Improper installation, adjustment, alteration, service or other flammable vapors and liquids maintenance can cause property damage, injury or death. in the vicinity of this, or any other Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment.
- Page 2 To Purchaser After installation of your hot plate, immediately contact your local gas supplier to obtain information in the event the user of your equipment smells gas. This information must be posted in a prominent location. To User RETAIN THIS MANUAL FOR FUTURE USE Upon receipt of this hot plate, inspect it thoroughly for any damage which may have occurred during shipment.
- Page 3 Gas Piping: Make sure the gas pressure regulator supplied with the hot plate is installed correctly. Connect the outlet side of regulator to hot plate. The regulator is set at 4 inches w.c. on natural gas and 11 inches w.c. on propane gas. A 1/8” pressure tap is provided on the gas manifold at the front of the hot plate for checking the gas pressure.
- Page 4 CHP HOT PLATES 20-100-01 double top grate 20-200-02 orifice hood (LP) 20-100-02 **single top grate (front only) 20-625-00 screws burner/venturi 20-400-DS body 20-350-01 double pilot assembly 20-425-DS front panel 20-350-02 **pilot stem & tip (front only) 20-450-DS drip pan 00-225-00 pilot valve (straight) 20-325-01 front (short) venturi...
-
Page 5: Troubleshooting Guide
Effective January 2020 CONNERTON (Company) warrants to the original owner that the product be free from defects in materials and/or workmanship. This warranty shall apply to units properly installed in a static location only and be in effect for two (2) years from the date of purchase but shall not exceed 30 months from the date of shipment from the Company. - Page 6 Damage incurred during transit and/or handling. Damage resulting from the use of other than genuine CONNERTON parts. Damage resulting from the use of or exposure to harsh chemicals or improper cleaning procedures. Damages caused by flood, fire or other acts of nature.
