Summary of Contents for Wadax STUDIO PLAYER

Page 3 Welcome. Thank you for selecting WADAX as a part of your music playback system. The Studio Player is a no- compromise design intended for the ultimate in music reproduction. The Studio Player combines a CD/SACD transport and streamer with Atlantis Reference DAC technology in a singular, easy to use, high performance component.
Page 4: Table Of Contents
Contents Warnings Front View Back View Installation Settings Operation Maintenance Warranty Speciﬁcations...
Page 5 If the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the obsolete outlet. Studio Player is a Class 1 Laser Product. It complies with U.S. FDA 21CFR subchapter J. This Laser Product is designated as •...
Page 6: Front View
Front View...
Page 7: Back View
Back View...
Page 8: Installation
Ensure your furniture is designed appropriately for this weight. You may leave Studio Player on at all times, unless you will not be using your system for an extended period. Studio Connect the Internet to Studio Player with an appropriate Player requires nominal power when left powered on, and cable from your router to the input marked ‘INTERNET’.
Page 9: Additional Connections
ISOLATION FOOTERS Digital Outputs Studio Player is equipped with four isolation footers Three digital outputs are o ered on Studio Player - BNC, designed to isolate the player from mechanical RCA, and AES/EBU. Connect these to an external digital interferences. The footers are comprised of a number device such as a processor or D/A converter.
Page 10 Settings Studio Player o ers a series of setup options to optimize both functionality and the performance. To access the setup menu, touch the gear icon at the top left of the home screen. This will take you to a menu with a list of options on the left, and the associated values of each option on the right.
Page 11: Settings Options
Settings SETTINGS OPTIONS Clock The clock setting tells Studio Player if you are using the Output Level built-in clock or an external device. The available values are The output level allows you to change the output voltage, internal and external. Select the appropriate value based on and thereby the overall output volume of Studio Player.
Page 12: Operation
Studio Player has a simple, easy-to-use touch screen interface on the front panel. It has been designed to To play a CD or SACD, insert a disc into Studio Player by control all functionality of the player e ciently while touching the Tray Open/Close icon on the display.
Page 13 Operation Studio Player in disc playback mode Expanded Controls for disc playback (seek forward/reverse and repeat all/one track)
Page 14 Operation STREAMING PLAYBACK Studio Player is certiﬁed for direct connect to Spotify and Tidal. This feature allows you to connect directly to Studio Player from the apps of the three aforementioned services. To connect to Tidal, open the Tidal app. On the player page is a small icon for connect;...
Page 15 Connecting Studio Player to a DLNA/UPnP device is similar Studio Player must be powered on in order to connect to it. to connecting to a streaming app. First, ensure your device is UPnP capable. Follow the instructions of your device to Check the menu settings of your streaming program or navigate to the connection page;...
Page 16 Operation Standby 0-9 Numeric Buttons Volume Up/Down WADAX A/B Buttons WADAX Non-Functional MENU Playback/Transport Controls Setup EJECT SETUP...
Page 17: Remote Control Functions
Standby - Puts Studio Player into standby mode. Please changes via the remote to the setup menu. note this does not shut down Studio Player; to do so you must switch the power rocker switch on the back panel to the OFF position.
Page 18: Maintenance
Maintenance SERVICE DISPOSAL AND RECYCLING Warranty claims should be made to WADAX or to your To dispose of this electronic product, do not dealer or importing distributor. When returning the place in a landﬁll. In accordance with the product for service, the original shipping container and all European Union Waste Electrical and Electronic packaging should be included with the product;...
Page 19: Limited Warranty
Warranty LIMITED WARRANTY CONDITIONS Thank you for choosing WADAX to be a part of your music In the event of a failure or defect during the warranty listening system. Your new component has been designed period, WADAX will provide at no charge all parts, labor, to provide years of trouble-free use and enjoyment.
Page 20: Specifications
Specifications Voltage Input: 100/110/220v 48cm/18.9in Display: 5 inch full color Weight: 45kg/99lb (shipping) 30kg/66lb (Studio Player) 26.5cm 10.45in 43.5cm 17.1in...
