Onyx FF 2020C-B User Manual

PATENTS:
2023 3023 3617.8
2015 2001 7468.1
2022 2355 4253.2
2020 3024 3743.8
USER'S MANUAL
Tips
1. This machine is not designed to be used on synthetic hair or for any other purpose other than cutting 100%
human hair. The company will not take responsibility for malfunctions or damages caused by misuse.
2. This product is designed for professional use only.
Safety precautions
Keep Away from Children:
Please store clipper away from children. Clipper contains sharp blades and small parts that can be harmful
to minors.
Safety Use:
1. Unplug the power adapter before cleaning the clipper.
2. Remove the blade first, then use cleaning brush to remove any hair buildup.
3. Keep away from water in order to avoid shock or damage to the clipper.
4. If the clipper is accidentally dropped into water or any other chemicals, discard immediately. Do not try
to dry it and plug it into a power source.
5. To properly store, remove clipper form dock, unplug adapter, and thoroughly clean your unit. Do not
store the clipper on the charging dock or leave it attached to the adapter.
6. If the cord on the power adapter is damaged, stop using it immediately and replace right away.
7. Do not disassemble this product on your own. Visit authorized dealers for service and repair.
8. Choose the correct voltage socket before charging (AC100-240V 50/60Hz).
9. Please do not twist, disassemble or puncture the rechargeable battery within the clipper, otherwise it may
cause a short circuit or burn the machine. If the battery is not working, do not run the clipper and take it to
an authorized dealer.
10. Extended use in temperatures below -10
battery.
To Avoid Product Damage:
1. Only use original accessories.
2. Do not sharpen the blade on your own.
3. Only use the original power adapter manufactured by JRL. Using any other adapters from a different
company may cause the clipper to malfunction while charging.
4. WARNING: For the purposes of recharging the battery, only use the detachable supply unit provided
with this appliance.
Product overview
Blade Adjusting
Lever
Switch
Clipper
Product specifications
Item Specifications
Input AC 100-240V 50/60Hz
Power adapter
Output DC 5V 2A
EN
Battery capacity 3.6V 3500mAh
o o
C or above 40 C is not recommended as it may damage the
Screwdriver Cleaning Brush Blade Adjustment Tool
& Protector
Lubricating Oil Combs x10 Charging Dock
Charger Adapter
Product code: 2020C-B
Item Specifications
Type of battery Lithium ion battery
2.5 hours for Fast Charging
Charging time
5 hours for Reset IQ Charge
Usage time 5 hours
01
How to charge your clipper
Important: Use only original power cord to charge.
You can charge your unit on the portable charging base, or charge
the clipper directly by plugging the power cord to the clipper itself.
Note: When the clipper is low on charge, the adapter can be
plugged into the clipper directly. You may use the clipper while
it is charging.
Reset IQ Technology Charge
Connect charging base to the power adapter, green light turns
on. Using the Reset IQ Charge will extend the life of battery and
take about 5 hours to fully charge.
Fast Charging Method
Press the button once on charging base to switch to
Fast Charging
fast charge , white light turns on. The set mode
rapid Fast Charging Method takes approximately
2.5 hours.
LED Functions
When the clipper is not fully charged, the indicator light will
continue to flash, and the battery indicator will show the current
usable time.
When the clipper has less than 40 minutes of usable time, the
warning light flashes in red.
When the clipper has more than 40 minutes of usable time:
warning light flashes in white when Fast Charging
warning light flashes in green when Recovery Charging
When the clipper is fully charged, the warning light will stop
flashing and the white light will remain on.
Usage instructions
Switching and shifting instructions:
By pushing the switch, the speed of the clipper can also be adjusted:
O: Shutdown (off)
I: Power on / first gear 6000 RPM
II: Second speed 7500 RPM
Clipper status indication by LED light:
The battery indicator shows the usable time of the clipper in the
current speed setting.
When the clipper is in high power mode, the white light is on.
Switch
After an hour of using the clipper, the oil Indicator will prompt.
When the clipper battery is low, the red light will flash.
when the battery is dead.
Adjusting the cutting length
The clipper comes with 5 different adjustment levels,
which are: 0.5mm, 1.4mm, 2.0mm, 2.8mm, 3.5mm.
Users can adjust the level according to their needs.
Push the blade adjustment lever forward for a closer cut.
Push the blade back for the reverse effect.
Blade Adjusting Lever
How to install and replace guards
Clipper comes with 10 guards.
Sizes are: 1/2#(1.5mm), 1#(3mm), 1-1/2#(4.5mm), 2#(6mm), 3#(10mm), 4#(13mm), 5#(16mm), 6#(19mm),
7#(22mm), 8#(25mm).
Installing your guard:
As shown in the figure below, align the card slot corresponding to the guard with the main unit of the
product, and then lift the main unit gently until you hear a 'click', which indicates the installation of
the guard is complete.
Note:
Make sure the guard is installed properly, and is not loose before use.
Removing your guard:
As shown on the right, you can remove the guard by turning the tail of the comb with your finger.
Guard installation Remove guard method
02
Electrical Outlet
Power Adapter
Reset IQ Charge
Switch
Minute
Usable Time
Hour
Charge Indicator
Oil Indicator
On
