Summary of Contents for DigiWeigh DWP-5000FL
- Page 1 DWP-5000FL WEIGHING INDICATOR User Manual Rev1.1 WARNING Ask professional personnel to debug, detect and repair indicator. WARNING Please keep good grounding of indicator.
-
Page 2: Table Of Contents
WARNING In electrical connection of indicator, please cut off the power supply in advance. Wait for 30 seconds between power-on of the indicator for 2 times. Pay Attention to Static Electricity The indicator is a device sensitive to static electricity, thus please take anti-static precautions in use and maintenance. -
Page 3: Technical Parameters
Technical parameters ● Data Transfer: Wireless: From weighing scale to indicator data transfer methods is bluetooth. ● Bluetooth interface (Optional) ● Version of bluetooth: BLE5.0 Maximum transmitted power: +4dbm Antennae: PCB antennae ● 3.5”TFT color screen display ● 6 function buttons. Operation is simple and convenient ●... -
Page 4: Introduction Of Panel
3. Introduction of panel... -
Page 5: Introduction Of Keys
4. Introduction of keys Sign Mode Short press Long press Normal Turn on Turn off Reset Return Normal Enter calibration Reset Move cursor to left Normal Add current weight to total Clear the total Reset Move cursor to right Tare (gross weight to net weight)/ Remove the tare Enter to adjust the angle Normal... - Page 6 2. Peeling and clearing operation In the weighing display state, when the displayed weight is positive and weighing is stable, press the [Tare] key to deduct the displayed weight value as the tare weight. At this time, the indicator shows that the net weight is 0, and the symbol is “G\B”...
- Page 7 B. Accumulative weight clearing operation Press and hold the [Add] key for about 2 seconds until "Total: 0" and "Count: 0" are displayed, indicating that the accumulated weight has been cleared. As shown below: 4. Printing operation A. Weighing ticket printing In the weighing display state, when the displayed weight is positive and the weighing is stable, press the [Print] key, and the printer will print the current weighing ticket in the following format:...
- Page 8 B. Cumulative weight printing In the weighing display state, quickly press the [Print] key twice, the printer will print the current accumulated times and accumulated weight in the following format:...
-
Page 9: Setting And Calibration
Below instructions only for trained engineer. 6. Setting and calibration： Long press “Print”，enter system setting menu，press“ ”or“ ”; red） ， press“ ”enter menu of next Pick up the parameter （ the chosen one is in ”to return to the menu of previous menu。 level or confirm the setting 。Press“... - Page 10 B、Check the internal code of left and right fork Long press“Zero”to check the internal code of left and right fork. Apply force to the weighing area of forks and observe the change of internal code for checking the working condition of forks and bluetooth. C、Angle adjustment Long press “Tare”...
- Page 11 It will show“operation end” Press“Print”or“Return”to go back to the main menu. D、Calibration Long press “Cal”to enter calibration. Please ensure finish angle adjustment before calibration. Press “Zero” or “Tare” for choosing zero point calibration or loading point calibration. If it is the first time of calibration, zero point calibration, and then loading point calibration.
- Page 12 Sampling in zero point calibration. After sampling finish, enter next level menu. Zero point calibration ends. When showing zero point calibration ends, then loading point calibration. Press“Print”to enter loading point calibration. Setting the number of loading points. If only calibrate the zero point and one loading point, set Points to“2”.
- Page 13 Input the number of the applied weight. Switch the cursor with “Cal”&“Add”; Change the number with“Tare” &“Zero” Input the right number and press“Print”to enter sampling interface. After sampling, enter to next interface. Loading point calibration ends, press“Print”or“return” to back to main menu.
-
Page 14: Continuous Output Format Specification
7. Continuous output format specification Start of text Left fork weight End of text Current total weight Right fork weight 0x0d 、0x0a 0x02 XXXXX YYYYY ZZZZZ 1、 Weight value is ASCII text. 2、 XXXXX = YYYYY + ZZZZZ. 3、 Transmission frequency：20 FPS. 4、...
