Pollet Water ESLI BUDGET 125-3 Operation And Maintenance Manual

Reverse osmosis systems
Hide thumbs

Advertisement

Table of Contents

BUDGET SERIES
REVERSE OSMOSIS SYSTEMS
OPERATION AND MAINTENANCE MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESLI BUDGET 125-3 and is the answer not in the manual?

Questions and answers

Related Manuals for Pollet Water ESLI BUDGET 125-3

Summary of Contents for Pollet Water ESLI BUDGET 125-3

  • Page 1 BUDGET SERIES REVERSE OSMOSIS SYSTEMS OPERATION AND MAINTENANCE MANUAL...
  • Page 2 BUDGET SERIES REVERSE OSMOSIS SYSTEMS OPERATION AND MAINTENANCE MANUAL BUDGET 125-3...
  • Page 3 BUDGET SERIES SPECIFICATIONS The Budget 125-3 RO works directly from a raw water inlet connection (preferably on a softened supply) and a (220 V/50HZ) electrical connection. The inlet pressure/temperature must be between (2 and 4 bar) and (10 to 40 °C) to operate. If the inlet pressure is too low the system will not function. Raw Water Spec.
  • Page 4 REVERSE OSMOSIS SYSTEM DESCRIPTION Osmosis is the movement of water from a high concentration to a low concentration, through a SEMI-permable membrane. Osmosis is 'complete' when both sides are in the state of equalibrium which this means when the water molecules are of equal concentration on both sides of the membrane.

  • Page 5: Before Commissioning

    Assuming the pressure is ok the high pressure pump will start up and boost the pressure to 5 to 10 bar (see pressure guage). Water is forced through the mebrane while the minerals and concentrate go to waste. There is a flow restrictor in the waste nozzle fitting DO NOT REMOVE this.

  • Page 6: Hydraulic Connection

    HYDRAULIC CONNECTION Connect the raw water supply. Connect the permeate (product) water line to the permeate tank. Within specification (table Permeate water back pressure should be less than 0,5 bar. If the pressure is higher than 0,5 bar, a check valve has to be put into this line ( 3m of head). If there has to be a shut off valve, the safety valve must be put before the shut off valve.

  • Page 7: Daily Maintenance

    PERIODICAL MAINTENANCES DAILY MAINTENANCE Check static and dynamic elements in the plant. ) Check for any leakage of water. ) Check the cartridge filter check input / output pressure. If the pressure limit exceeds 0,8 bar, change the cartridge. ) Check product water and waste water flow ) Check the pressure on manometer ) Check inlet temperature of the reverse osmosis device ) Check the reverse osmosis operation efficiency...
  • Page 8 LOW PRESSURE SETTINGS...
  • Page 9 The pressure sensor is pre set . If it needs to be adjusted then the start-stop set pressure increases in a clock wise direction and decreases in a counterclock wise direction. Diff (differential) works the opposite way. Start – Stop is the low pressure value. Differential; is the range either side of the low pressure value..
  • Page 10 K FACTOR SETTINGS This should not be altered unless the probe is changed. When pressing the SET buton for 3 seconds (time counts up from 0 to 3 and 1,000 appears on the screen. The K value is written on the conductivity probe and this should be entered by using the button.
  • Page 11 MEMBRANE PROTECTION PREPARING OF PROTECTION SOLUTION 1. Protection Chemical: sodium bisulphite (SBS), %95 powder 2. Protection Solution Concentration:% 1-2 weight / weight 3. Protection Solution Preparing Rate: 1-2 kg %95 powder SBS for 100 lt Ro Permeate Water. PROTECTION SOLUTION REFRESHING 1.
  • Page 12 Membrane replacement Turn off power. Depressurise the system Close the input valve. Remove one of the endscaps from the vessels by removing the two screws that retain the two retaining clips (see picture 1) take care not damge the retaining slot when removing the retainers and screws.

  • Page 13: Warranty Conditions

    WARRANTY CONDITIONS WARRANTY CONDITIONS This Water Treatment Systems has a 2 YEAR limited warranty from the invioce date against manufacturing and material faults. ) Should this equipment fail due to manufacturing or material fault during this period it will be repaired free or charge at the discression of the supplier.
  • Page 14 STANDARD PERFORMANCE GUARANTEES ) In the warranty period, some units will lose their performance to a degree. These are shown below. Membranes:  %10 increase per year in salt passage. %5 decrease in recovery rate. Ion exchangers:  %5 decrease per year in ion removal efficiency. Multi media filters: ...
  • Page 15 NAME OF MATERIAL SPECIFICATIONS SUPPLIED BY STOCK NO SOLENOİD VALVE 3/4 SELONİD VALF N.K.0,5-16 BAR 24 V AC GEVAX 1303002 BOBBIN FİLTER HOUSING ATLAS 3P HAUSING MONO 3P10AFOSXTS 3/4" AQUALINE 0701004 CARTRIDGE FILTER AQUALINE 10" 1 MIC. SPUN W/OUT ENDCAP AQUALINE 0703001 LOW PRESSURE SWITCH...
  • Page 16 ELECTRICAL PROJECT...
