ZooZ Zoozbikes Ultra Ripster Quick Start Manual

Hide thumbs

Advertisement

Table of Contents

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zoozbikes Ultra Ripster and is the answer not in the manual?

Questions and answers

Related Manuals for ZooZ Zoozbikes Ultra Ripster

Summary of Contents for ZooZ Zoozbikes Ultra Ripster

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS PERTAINING TO RISK OF FIRE or ELECTRIC SHOCK WARNING - When using this product, basic precautions should always be followed, including the following: Read all the instructions before using the product. To reduce the risk of injury, close supervision is necessary when the product is used near children. Do not put fingers or hands into the product.
  • Page 3 No liability or warranty shall be accepted if the use of the ZOOZ Bikes electric bicycle deviates from this intended use, if safety instructions are not observed, in the event of overloading, or if faults are not properly rectified. Similarly, no liability and warranty shall be accepted in the case of assembly errors, willful intent, accidents and/or if care and maintenance specications are not followed.
  • Page 4 370 Lumen LED integrated into running light when the headlight is on. the aluminum stem. RACK MOUNTING. FRAME. Mounting positions for ZOOZ 4130 chromoly steel is front and rear racks. lightweight, absorbs road shock and delivers superb ride feel. MOTOR.

  • Page 5: Before You Ride

    E-bikes experience more wear and tear than normal and safe function. Improper unpacking and assembly can cause damage bikes because of their weight and higher speeds. to the bike and/or bodily harm and is not covered by the ZOOZ Bikes warranty. Ride responsibly.

  • Page 6: Torque Specifications

    Assembly Technical Information. Assembly Video. Assembly Tip. Scan the QR Code with your phone to see Hand tighten hardware initially, adjust and align our assembly video on YouTube. your parts, then torque to the correct specs. Torque Specifications Tools Hex Wrenches. 3 mm (Display &...

  • Page 7: Installation Instructions

    Warning: This bike must be assembled by a professional for proper and safe function. Improper unpacking and assembly can cause damage to the bike and/or bodily harm and is not covered by the ZOOZ Bikes warranty. STEP 1 STEP 2 Open box.
  • Page 8 STEP 3 STEP 4 Hold the bike steady in an upright position on a soft floor surface to avoid Remove the plastic brake caliper spacer and axle brace. Be sure not scratching the frame or fork. Unscrew the 4 bolts from the top of the to squeeze the brake while the clip or the wheel is removed.
  • Page 9 STEP 5 STEP 6 Lift the bike from the handlebars to lower the forks onto the front axle Each pedal screws into the crank arms with threads that spin in the opposite and guide the disc into the brake caliper and the axle slots into the axle direction.
  • Page 10 To do so, insert the key, rotate the key forward the batt ery power. It is only for power level status. The Zooz batt ery lock has and hold it there. Grasp the batt ery in the middle and tug forward to slide it a spring loaded locking pin.
  • Page 11 OPERATING INSTRUCTIONS Adjustment & Torquing REAR WHEEL ALIGNMENT, CHAIN ADJUSTMENT Rear wheel alignment and chain tension should be checked often. Electric bikes sustain higher speeds and forces than standard bikes. Movable/adjustable parts can move more frequently than regular bikes. Make sure that the rear wheel is properly aligned by equalizing the spaces between the rear wheel/tire and the frame on either side using the adjusters.
  • Page 12 FRONT WHEEL ALIGNMENT BRAKE CALIPER ALIGNMENT Hold the bike steady in an upright position on a soft floor surface to avoid Brake caliper alignment/adjustment. It is common to get some noise from scratching the frame or fork. Unscrew the 4 bolts from the top of the brake discs if not perfectly aligned and in proper working order.
  • Page 13 STEM, FORK, HANDLEBAR CRANK BOLTS This controls your handlebar alignment and must be snugly fitted for safe The crank bolt is a critical part that must be tightened periodically to riding. The steerer tube and stem must be tight and exhibit no "play" or 23NM.
  • Page 14 CONTROLS Each control unit - brake levers, throttle and display have bolts that tighten to secure their position on the handlebar. You can loosen these bolts to adjust the angle of these controls and align them to a position that you find comfortable, but should make sure they are tightened to where they don't move during use. Hand tighten! Do not over-tighten.
  • Page 15 Ready to Ride! SHOW US HOW YOU ZOOZ! #FEEL THETHRILL Pg. 15...
  • Page 16 OPERATING INSTRUCTIONS Display, Interface and Features. Display Interface. Power Butt on Display Defi nition. *located on front of display Press/hold butt on to power on. Display 1 (trip distance) is the default screen. Bluetooth Indicator Batt ery Level Indicator Headlight Indicator Display 1 Speed Indicator Speed Unit...
  • Page 17 The ZOOZ Ripster has both thrott le and pedal assist power delivery options. The ZOOZ Ripster is able to turn on the taillight, display light and headlight Pedal assist is a feature that adds power to assist the rider when peddling *if equipped at any time when the system is powered on.
  • Page 18 Battery Level. Trip Distance. The batt ery level indicator is located at the top of the screen and is always The trip distance is able to be cleared to zero at any time. If you do not clear visible, no matt er what screen you are in. There are fi ve level indicators the trip distance, it will keep adding distance from each ride just like the inside a frame in the shape of a cell batt ery.
  • Page 19 Metric / Imperial Units. (Km/h, MPH). Speed Limit. Your bikes default unit sett ing is imperial (Mph) but can be changed to You can limit the your bikes maximum speed if you desire. The default metric (Kp/h) easily through the display. sett ings for each power level are set to achieve it’s maximum legal speed.
  • Page 20 Now, go feel the thrill you crazy kids! Pg. 20...

  • Page 21: User Maintenance Instructions

    No liability or warranty shall be accepted if the use of the ZOOZ Ripster electric bicycle deviates from this intended use, if safety instructions are not observed, in the event of overloading, or if faults are not properly rectified. Similarly, no liability and warranty shall be accepted in the case of assembly errors, willful intent, accidents and/or if care and maintenance specications are not followed.
  • Page 22 Battery Usage and Care Details. The battery is the most important component of your ZOOZ Ripster electric bike. Following a few simple rules, you can optimize its life: • The battery can be charged both mounted on the bike or separately from the bike. Two keys are supplied to lock/unlock and remove the battery.
  • Page 23 Range. The maximum range of a full charge depends on many variables such as: age of battery, type of terrain and incline, rider weight, speed, outside temperature, driving style, amount of pedaling and tire pressure. Range in cold weather: • In case of extreme cold, the range of your electric bike is reduced.

  • Page 24: Limited Warranty

    ZOOZ BIKES. This is a consumer warranty and does not apply to products used applicable warranty period set forth above, ZOOZ BIKES will evaluate the warranty commercially or in rental operations.
  • Page 25 LIMITATION OF LIABILITY. TO THE EXTENT PERMITTED BY LAW, IN NO EVENT Shipping and disassembly instructions from either the dealer or ZOOZ BIKES must be WILL ZOOZ BIKES OR ITS AFFILIATES, OR ITS AND ITS AFFILIATES' RESPECTIVE followed.
  • Page 26 form or amount, the relief allowed by the applicable law. The arbitration will be conducted in accordance with JAMS consumer arbitration rules and procedures or other arbitration procedures appropriate for use in consumer disputes. The arbitration provision is entered into pursuant to the Federal Arbitration Act, and the substantive laws of the State of Texas, without reference to its choice of law principles, will otherwise govern the interpretation of the Limited Warranty and all disputes that are subject to this arbitration provision.
  • Page 27 ZOOZERS A COMMUNITY LIKE NO OTHER. Contact Us. Home base www.zoozbikes.com Customer Support support@zoozbikes.com General Inquiries hello@zoozbikes.com Follow us zoozbikes zoozbikes * Assembly Video Link Pg. 27...
  • Page 28 feel the thrill Copyright Zoozbikes.com 2024...
