RL 9816L Operation Instruction

166.00 mm
Car Parking Indicator(Infrared Alarm)
One million sets of learning codes to effectively avoid interference.
The melody volume can is adjustable .
Sound and light indication function.
BATTERY REQUIREMENTS Receiver: 3 x 1.5V AA Batteries (Not supplied)
成品尺寸：166*190mm，材质：300g白板对折，磨光，四色印刷
MODEL: RL-9816L
DIY
3 AA alkaline DingDong
Do it yourself
batteries Sound
Transmitter: 1 x 9V alkaline battery（G6F22M）(Not supplied)
Car Parking Indicator(Infrared Alarm)
When the car or someone moves around in the PIR induction area, the indoor unit will sound an alarm, the volume of which can be adjusted.
There will be flashlight along with the alarm siren.
PIR induction angle: ≥75°. PIR induction distance: ≥6m .
With auto code-learning technology and strong anti-interference feature. The wireless transmission distance is over 100m.
Powered by DC current. The receiver has low-voltage indication function.
The PIR transmitter can be installed at the balcony or in the garage.
Operation Instruction:
1) There are two switches on the indoor unit.
ON/OFF: As the name suggests, this switch turns the Indoor Unit ON or OFF.
HI/LO: Change the volume of the chime between high (HI) volume and low (LO) volume.
2) Code Learning
Insert batteries into the Indoor Unit, the unit will emit "ding-dong" sound and flash once to let you know the batteries have been installed.
Next, press the Coding button at the back of the indoor unit and then insert batteries into the Outdoor Unit. The Outdoor Unit will give off
red light and send out wireless signals. After the Indoor Unit receives the signals, it will emit "ding-dong" sound and flashing light, which
indicates the code learning is successful.
3) Code Clearing
Press and hold the coding button and then power on. After 11s, let go after you hear one "DI" tone. Then after 4s you will hear "Di Di Di
DingDong" tone which indicates successful code clearing.
4) Low Voltage Indication Instructions:
Indoor Unit: When the voltage is less than 3.3V, the LED light will be on constantly.
Outdoor Unit: When the voltage is less than 6.1V, the LED light will be on constantly.
Note: When the low voltage indication is on, please replace the batteries as soon as possible to avoid any effect to your operation.
The indicator light will turn off when the power runs out.
Technical Parameters:
A.Outdoor Unit (Transmitter)
B.Indoor Unit (Receiver)
Power Supply: 9V alkaline battery（G6F22M） Battery: DC 4.5V(AA*3)
Working Current: ＜10mA Working Current: ＜170mA
Standby Current: ＜20uA Standby Average Current: <180uA
Infrared Sensing Distance: ≥6m Max. Alarm Volume: ≥100dB
Low Voltage Indicator: ＜3.3V
Infrared Sensing Angle: ≥75°
Low Voltage Indicator: ＜6.1V±0.1V
Wireless Receiving Frequency: 433.92MHz
Transmitting Time Per Time: ≈2 seconds Wireless Receiving Distance: ≥100m
Time Interval Between Transmissions: ≈6 seconds
Transmission Distance (open air): ≥100m
Wireless Transmitting Frequency: 433.92MHz±100Hz
MODEL: RL-9816L
