Backyard Creations Rhodes F170227-A1 Manual

Fire column
Hide thumbs

Advertisement

Table of Contents

Rhodes Fire Column
ITM./ART.#: 2595184
MODEL#: F170227-A1
ANS Z21.97 CSA 2.41-2017
Outdoor Decorative Gas Appliances
Maximum inlet supply pressure: 13 in wc (3.24KPa)
Minimum inlet supply pressure: 8 in wc (1.99 KPa)
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
Shut off gas to the appliance.
Extinguish any open flame.
If odor continues, leave the area immediately.
After leaving the area, call your gas supplier or fire
department.
Failure to follow these instructions could result in
fire or explosion, which could cause property
damage, personal injury, or death.
DANGER
WARNING:
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
WARNING: For Outdoor Use Only.
Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
WARNING
Do not store or use gasoline, or other
flammable vapors and liquids,in the
vicinity of this or any other
appliance.
An LP-cylinder not connected for use
shall not be stored in the vicinity of
this or any other appliance.
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rhodes F170227-A1 and is the answer not in the manual?

Questions and answers

Related Manuals for Backyard Creations Rhodes F170227-A1

Summary of Contents for Backyard Creations Rhodes F170227-A1

  • Page 1 Rhodes Fire Column ITM./ART.#: 2595184 MODEL#: F170227-A1 ANS Z21.97 CSA 2.41-2017 Outdoor Decorative Gas Appliances Maximum inlet supply pressure: 13 in wc (3.24KPa) Minimum inlet supply pressure: 8 in wc (1.99 KPa) INSTALLER: Leave this manual with the appliance. WARNING: For Outdoor Use Only. CONSUMER: Retain this manual for future reference.

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 NFPA 54; National Fuel Gas Code; Natural Gas and Propane Installation Code, CSA B149.1; ● or Propane Storage and Handling Code, CSA B149.2, as applicable.

  • Page 3: Specifications

    IMPORTANT SAFETY INFORMATION ABOUT PROPANE (LP) GAS The LP-gas supply cylinder to be used must be constructed and marked in accordance with the U.S. Deparment of Transportation (D.O.T.) Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for Transportation of Dangerous Goods and Commission, CAN/CSA-B339, as applicable. The LP-gas supply cylinder to be used must have a listed overfilling prevention device (See Figure 1).

  • Page 4: Package Contents

    PACKAGE CONTENTS PART DESCRIPTION QUANTITY Fire pit body 1 pc 1 pc Door 1 pc Weather cover Lava rock (4.18 Ibs) 1 box ASSEMBLY INSTRUCTIONS Carefully unpack all parts from the box, compare parts with package content listed above, make sure all parts are present before beginning assembly of product.
  • Page 5 4. Place the gas cylinder into the cylinder holder. Secure the cylinder by tightening clockwise the butterfly screw found on the cylinder holder (See Figure 3), so that the cylinder cannot move from side to side or fall down. Connect the regulator, screw the black handle (See Figure 4) clockwise to tighten, turn the black handle counterclockwise to remove.
  • Page 6 BATTERY Make sure the control knob is in the “OFF” position. Unscrew the push button cap on the ignitor module located on the control panel to access the battery compartment. The ignitor module requires one AAA size battery (See Figure 7), BATTERY IS NOT INCLUDED. WARNING: 1.

  • Page 7: Lighting Instructions

    gas valve-hose connection (Figure 10) inlet tube-bellows connection (Figure 11) To perform a leak test: Make 2~3 oz. of leak solution by mixing one part liquid dishwashing detergent and three parts water. Noted: make sure control knob is “OFF”. Apply several drops of solution where the cylinder attaches to regulator (See Figure 8), inspect the solution at the connection looking for bubbles.

  • Page 8: Care And Maintenance

    Observe Flame Height When Lit: The burner will display blue and yellow flames. These flames should be a blue / yellow color between 1~2 in. height (See Figure 13). These flames should not be yellow or produce thick smoke. This would indicate an obstruction of airflow through the burners. The flames should be blue with straight yellow tops.

  • Page 9: Warranty Exclusions

    WARRANTY Firepits Burner, steel fire pit bowl, all mechanical parts and fittings to control panel and burner assembly, and all fire pit tops that are not cast aluminum are warranted for a period of one (1) year from original date of purchase, against defects in material and or workmanship.
