ZENITH
CHASSIS 7N02, 7N06
RATING: 32 Watts, .32 Amp. @ 117 Volts AC (Less Clock)
Zenith Models N724A, X390W (Cll. 7N06) N728W, T2536A, X318A, M (Cll. 7N02)
DIAL CORD STRINGING
For Current Address, See Annual Index
7-Tube AM Receiver
110-120 Volts AC, 60 Cycles
TYPE SET:
TRADE NAME:
SUPPLIER:
POWER SUPPLY:
