Signature Sleep 4906215COM Manual

Wall bed - full size daybed
Hide thumbs

Advertisement

Available languages

Available languages

Table of Contents

4906215COM (CENTURY BARN PINE)
4906341COM (MAGNOLIA OAK)
Wall Bed - Full Size Daybed
Date of Purchase ___ / ___ / ___
Lot Number:
WARNING:
* WARNING FOR YOUNG CHILDREN -
This product contains small components,
please ensure that they are kept away
from small children. Children under the
age of 6, small infants and babies must
not sleep on this bed for safety reasons.
To prevent injury and damage to this unit,
PROHIBIT jumping on it.
* This product is designed for home use
and not intended for commercial use.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Visit: www.ameriwoodhome.com
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Professional installation is
required for this unit.
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall
- Do Not allow children to climb on unit
Professional
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B344906000COM0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4906215COM and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Signature Sleep 4906215COM

Summary of Contents for Signature Sleep 4906215COM

  • Page 1 4906215COM (CENTURY BARN PINE) 4906341COM (MAGNOLIA OAK) Wall Bed - Full Size Daybed B344906000COM0 Date of Purchase ___ / ___ / ___ Lot Number: WARNING: * WARNING FOR YOUNG CHILDREN - This product contains small components, please ensure that they are kept away from small children.

  • Page 2: Helpful Hints

    Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Call us! 1-800-489-3351 Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints - Open your item in the area you plan to keep it to avoid excessive heavy lifting. - Identify, sort and count the parts before attempting assembly.
