Index Introduction.................... 01.1 About this manual................... 01.2 CE Declaration of Conformity..............01.3 Warning Symbols Used in the Instruction Manual......Safety noticies..................02.1 Personnel....................02.2 General Safety Recommendations............02.3 Residual Hazards..................02.4 Safety Measures..................Product information................03.1 Description of the Ezoord Repair Stand..........03.2 Technical Features.................
Introduction 01.1 About this manual This manual contains important safety instructions that must be followed when operating the Ezoord Repair Stand. See the web version: www.ezoord.com WARNING! Read the instruction manual carefully before using the Repair Stand. 01.2 CE Declaración of Conformuty The company PHOENIX SYSTEMS MECANO ESPAÑA, S.A.
01. 3 Warning Symbols Used in the Instruction Manual Correct identification and interpretation of the instructions and recommen- dations are critical for avoiding accidents that could cause personal injury and material damage. Therefore, special attention should be paid to this section. Symbols Used in the Instruccion Manual It generally indicates that the instruction it accompanies poses some danger to the working personnel. It generally indicates that the instruction it accompanies contains some risk of material damage.
Safety notices WARNING! Read the safety recommendations carefully be- fore using the repair stand. It is very important to unders- tand and follow the safety guidelines. Failure to comply with them may endanger people’s health and cause mate- rial damage. 02.1 Personnel People who use the repair stand are responsible for their own safety, avoi ding dangerous situations.
Page 6
Recommendations Danger! Electrocution due to poor electrical installation. • Do not carry out any activity if the electrical installation is damaged. Danger! Electrocution due to water infiltration into the device. • Avoid using liquids that may enter the interior of the elevator. Danger! Electrocution due to water entering the device. • Do not wash bicycles on the bicycle lift. Danger! Sharp-edged cuts. • Wear gloves when working with the bike lift. Danger! Overturning. • Do not use the bicycle lift on uneven or uneven floors, floors with obstacles, or when moving the bicycle lift while it is eleva- ted. Danger! Risk of tripping over the base. • Pay attention to the base of the bike lift when moving around it. Danger! The bike may fall if it is not properly secured with the clamp. •...
Page 7
Applying the necessary safety measures and protective equipment, according to the applicable occupational risk prevention legislation, to protect and guarantee the health and safety of the workers, considering the operations ca- rried out, tools used and the work environment. It is not permitted to override the safety functions of the bicycle lift.
02.3 Residual Hazards Despite integrating all possible safety measures into the design, providing additional safety devices and instructions, residual risks cannot be completely eliminated. The user can ensure safety in use by paying attention and applying the necessary measures to prevent accidents. The risk zone is marked on the equipment with the following warning: 02.4 Safety Measures Safety measures provided for the bicycle lift: • ISP function, Intelligent System Protection ( anti-entrapment system ). • Heavy base provides stability, reducing the risk of tipping over when wor- king at height. •...
Attention! Any modification to the equipment voids the warranty and CE marking. Description Gripper Crank Handset with display Tray Lifting column Foot control Base Wheel Handle Control box Housing Adjustable lever Clamp Figure 01. Clamp handle 03.2 Technical Features Technical features Dimensions (Width/Depth/Height) 860 x 633 x 800 mm Weight 41 Kg Maximum Lift (Electric Column)
03.3 Dimensions Figure 02. 03.4 Workstation Obstacles people free zone Working Area Figure 03. It is recommended to leave a free space of 2 meters at the back and 1.5 meters on both sides, as well as in front of the bicycle lift. Page 09-24...
Caution! The rear area must remain free of obstacles and people. Risk of entrapment accidents. Attention! It is prohibited to use the elevator’s up and down functions in the presence of people in the spaces indicated in figure 4. Danger of entrapment. Attention! It is prohibited to use the automatic up and down function and to leave the work station.
Assembly The bicycle lift is supplied fully assembled. 05.1 Disassembly and Recycling It is recommended to recycle all components that cannot be reused, taking special care with electrical and electronic components, following local regulations. Instructions for use Before using the bicycle lift, make sure that it is in good condition, without any bumps, damage, injured cables, etc. 06.1 Connection to the mains Before connecting the Bicycle lift: •...
06. 2 PD15 Power Supply ELECTRICAL POWER SUPPLY 100-240V50/60Hz 3.5A-1.6A OUTPUT VOLTAGE WIRE 2 POLES TRANSPORT/STORAGE TEMP. -20 ºC to +50 ºC Housing Red trim Plug PD15 Jumper cable Page 12-24...
06 .3 Using the Controls Handset with display Foot control Control symbols Symbol Type of Control With Display "M" Memory With Display "1" Memory 1 With Display "2" Memory 2 With Display "3" Memory 3 With Display "UP" With Display "DOWN"...
Page 15
Note: During initial start-up and after disconnecting the power, a manual reset is required to be able to use the product. Reset Using the handset with display • Press and hold the “DOWN” key until the lift reaches the lowest posi- tion.
Adjust the height using the foot pedal • Press and hold the “UP” key and the elevator will rise until it reaches the desired position. Release the key to stop the movement. • Press and hold the “DOWN” key and the elevator will lower to the desired position.
ISP Function • If, despite the safety measures taken, a collision occurs while moving at nominal speed, the Ezoord bicycle lift detects this: it stops immediately and moves back approximately 20 mm in the opposite direction to its initial travel. •...
06.5 Manual Adjustment of Grip Height It is possible to adjust the clamping height manually, in a range of 300mm with the help of the adjustable handle (11): To adjust the lever to a comfortable position for use: lift the lever to release the teeth of the locking device by placing your thumb on the red button and turn. In the desired position, release the lever.
06.6 The Gripper Clamp Handle Clamp Gripper Jaws Crank 06.7 How to fit a bicycle 1. Unlock the clamp rotation using the adjustable handle (13) on the clamp. Rotate the clamp to the desired position and lock the clamp rotation. 2.
Attention! The closing pressure of the clamp will be determi- ned by the user, who is the sole responsible party. Phoenix Systems Mecano España, SA is not responsible for damage caused by excessive or insufficient tightening. Attention! Do not hold the bicycle frame by the ends, this can cause accidents and material damage.
Maintenance Ezoord bike lift is maintenance-free, some of the parts wear out with use. The lifespan of these parts will depend on the intensity of use. It is recommended to clean the equipment after each use and to ensure that it is in good general condition and that the warning signs are intact.
