AC 30473 — OUTSIDE LADDER
CAYMAN ENTRY SYSTEM
This enclosed ladder will attach to the universal step (AC 30163). Please open the step carton
and assemble the step per the instructions. Refer to this book for instructions on the assembly
and attachment of the ladder when instructed in step manual.
This ladder may be added onto the Blue Hawaiian step to create
NOTE
an A-frame entry system in the event that a step only is no longer
acceptable for use.
FOR USE WITH:
TOOLS REQUIRED
• Drill with 1/8" drill bit
• Small rubber mallet or hammer w/piece of wood
• Phillips head screwdriver
• Pliers
• Spray lubricant or liquid soap
10520
Advertisement
Related Manuals for Blue Torrent CAYMAN ENTRY SYSTEM AC 30473
Summary of Contents for Blue Torrent CAYMAN ENTRY SYSTEM AC 30473
- Page 1 AC 30473 — OUTSIDE LADDER FOR USE WITH: CAYMAN ENTRY SYSTEM This enclosed ladder will attach to the universal step (AC 30163). Please open the step carton and assemble the step per the instructions. Refer to this book for instructions on the assembly and attachment of the ladder when instructed in step manual.
- Page 2 PARTS & HARDWARE FOR STEP A. UPPER STEP (4) B. MOUNTING BLOCKS (2) C. ADJUSTABLE TUBE (2) (AC MKSTEP) (AC MTBLOCK) (AC ADJTUBE) E. LEG (2) D. HANDRAIL (2) (AC MKLEG) (AC HANDRAIL) G. BOTTOM STEP F. PLATFORM (AC BTSTEP) (AC PLATFORM) H.
- Page 3 CAYMAN ENTRY SYSTEM PARTS PART # MODEL # DESCRIPTION AC SHIELD Shield AC HANDRAIL Handrail AC LOCKCAP Lock Caps AC ADJTUBE Adjustable Tube AC MTBLOCK Mount Block AC PLATFORM Platform AC STEPCONR Right Step Connection AC MKLEG Molokai Leg AC BSTEP Bottom Step AC MKSTEP Mid Steps...
- Page 4 IMPORTANT SAFETY INSTRUCTIONS PLEASE READ PRIOR TO ASSEMBLY/USE The Ladder must be installed based on Manufacturer’s Instructions • One person on the Ladder/Stair at a time • This Ladder is designed and manufactured for a specific Pool Wall Height and/or Deck of the Pool •...
- Page 5 STEP 3 • Put ladder aside for now and install handrails (D) onto platform (F). • Lay one handrail on flat surface and push the connected dowels of the platform into the openings on the handrail until fully seated. Make sure treads of platform are facing upward.
- Page 6 STEP 4 - CONT. • Place washer on bolt and insert from INSIDE of ladder thru leg and step connector. Insert second washer on end of bolt and screw on nut. Do not over tighten. • Repeat above steps for the right step connector with remaining bolt, washers and nut.
- Page 7 STEP 6 • Once shields are situated properly, lift ladder up and line up the openings of shield with long handrail posts of the step. Slide the ladder down until it rests on ground • outside. OPEN Coat adjustable tube (C) with lubricant and slip (1) •...
-
Page 8: Maintenance
STEP 7 • Lubricate inside of long and short handrail posts on step with liquid soap or lubricant. • Attach handrails (D) from step box (AC 30163) to handrail posts by pushing into posts. The more curved part of the handrail is meant to be installed in the long handrail post. - Page 9 WARNING This ladder is designed and manufactured for SAFETY Aboveground, Semi-Inground NOTICE Flat Bottom IMPORTANT Pools 48”, 52” and 54” in wall height and pool decks 48”, 52” and 54” in height WARNING DANGER DANGER PLEASE When READ Entry/Exit of NOT IN USE BEFORE remove or...
-
Page 10: Year Limited Warranty
Blue Torrent’s ENTRY SYSTEMS, LADDERS AND STEPS are warranteed as follows: 1 YEAR LIMITED WARRANTY Blue Torrent warrants its Entry Systems, Ladders and Steps to be free of defects in material and/or workmanship for a period of one year from the original date of purchase.
