Patlite LR5-LAN Instruction Manual

Signal tower with ethernet
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Notice to Customer
Thank you very much for purchasing our PATLITE
product.
● Request the installation and wiring be performed by a
professional contractor if construction work is involved.
● Prior to installation, read this manual thoroughly before
using this product to ensure correct use.
● Re-read this manual before conducting maintenance,
inspections, repairs, and so on.
If you have any questions about this product, please
contact the service and repair desk listed on the
website.
● Before using this product, update to the latest version
of the firmware.
By registering as a member on our home page, you
can download the latest version of the firmware from
My Page.
To the Contractor
● Prior to installation, read this manual thoroughly to
ensure it is installed correctly.
● Return this manual to the customer.
Signal Tower with Ethernet
LR5-LAN
TYPE
Instruction Manual
[Web Version]
1. Before You Begin
2. Models
3. Parts and Accessories
4. Part Names and Outer
Appearance
5. Product Features and
Functions
6. Mounting, Installation, Wiring,
and Powering on
7.
Before Use
8. How to Use
9. Maintenance
10. Troubleshooting
11. Service Parts
12. Optional Parts
13. Specifications
GA0010847_02
page
5
9
10
11
12
16
30
51
64
71
74
75
78

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LR5-LAN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Patlite LR5-LAN

Summary of Contents for Patlite LR5-LAN

  • Page 1 4. Part Names and Outer Appearance 5. Product Features and Notice to Customer Functions Thank you very much for purchasing our PATLITE 6. Mounting, Installation, Wiring, product. ● Request the installation and wiring be performed by a and Powering on professional contractor if construction work is involved.

  • Page 2: Table Of Contents

    Signal Tower with Ethernet Instruction Manual Table of Contents 1. Before You Begin ＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿ 1.1. About Safety Symbols ………………………………………………………………………………… 1.2. Safety Precautions …………………………………………………………………………………… 1.3. Trademarks …………………………………………………………………………………………… 1.4. Network Security ……………………………………………………………………………………… 2. Models ＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿ 3. Parts and Accessories ＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿ 4. Part Names and Outer Appearance ＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿ 4.1.
  • Page 3 Signal Tower with Ethernet Instruction Manual 7. Before Use ＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿ 7.1. Setting Up Network Settings on the PC …………………………………………………………… 7.1.1. Windows 10 …………………………………………………………………………………………… 7.1.2. Windows 11 …………………………………………………………………………………………… 7.2. Setting Up the Password ………………………………………………………………………… 7.3. Displaying the Web Setup Screen ……………………………………………………………… 7.4. Setting Up Product Network Settings …………………………………………………………… 7.5.
  • Page 4 Signal Tower with Ethernet Instruction Manual 9. Maintenance ＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿＿ 9.1. Initialization Method ………………………………………………………………………………… 9.1.1. How to Initialize with the "Switch for Initialize" ………………………………………………… 9.1.2. Initialize from the Web Setup Screen ……………………………………………………………… 9.2. Restarting Method ………………………………………………………………………………… 9.3. How to change Web Login Password …………………………………………………………… 9.4. How to check the Version ………………………………………………………………………… 9.5. How to update the Firmware ……………………………………………………………………… 9.6.

  • Page 5: Before You Begin

    Signal Tower with Ethernet Instruction Manual 1.Before You Begin 1. Before You Begin 1.1. About Safety Symbols To prevent injuries to the user and other personnel, as well as to prevent damage to assets, note the following. ● The following symbols classify warnings and cautions, and describe the level of harm and damage that will occur when the corresponding instructions are ignored.

  • Page 6: Safety Precautions

    Mandatory ● If an unusual condition occurs while using this product, such as emitting smoke, heat, abnormal odor, or unusual sound, stop the application, disconnect the power, and contact your nearest PATLITE Sales Representative. ● To prevent accidents when operating or maintaining the product, in addition to the safety guidelines identified in the instructions of this manual, follow all general safety guidelines.
  • Page 7 Signal Tower with Ethernet Instruction Manual 1.Before You Begin CAUTION ● Do not use in locations near fire or environments with high temperature and humidity. Do not use this product where corrosive, flammable gas is present. ● Do not use this product with the O-ring or waterproof gasket removed. This will lower waterproofing performance.

  • Page 8: Trademarks

    Signal Tower with Ethernet Instruction Manual 1.Before You Begin 1.3. Trademarks ・ Microsoft Edge and Internet Explorer are registered trademarks of Microsoft Corporation in the United States and other countries. ・ Google Chrome is a trademark or registered trademark of Google LLC. ・...

  • Page 9: Models

    Signal Tower with Ethernet Instruction Manual 2.Models 2. Models Rated Mounting/ Buzzer Body LED Unit Model Size Tiers Voltage Wiring Unit Color Color Assembly ↓ ↓ ↓ - RYGBC Model Unit Model ↓ ↓ (Body Unit) Off-white φ 50 ～ 24V DC Tiers (Material:PC)

  • Page 10: Parts And Accessories

    Signal Tower with Ethernet Instruction Manual 3.Parts and Accessories 3. Parts and Accessories Depending on the model, the contents vary. Installtion Manual : 1 Accessory Main Unit : 1 Hexagon Nut with Flange L-bracket Size 付属品 * The product appearance varies depending on the product specifications. For details, please refer to “4. Part Names and Outer Appearance ( ☞...

  • Page 11: Part Names And Outer Appearance

    Signal Tower with Ethernet Instruction Manual 4.Part Names and Outer Appearance 4. Part Names and Outer Appearance 4.1. Names of Parts ● With buzzer unit Head Cover ● With buzzer unit Head Cover Buzzer Unit Buzzer Unit LED Unit ● Mounting with pole LED Unit ●...

  • Page 12: Product Features And Functions

    Signal Tower with Ethernet Instruction Manual 5.Product Features and Functions 5. Product Features and Functions 5.1. Product Features 5.1.1. Product Features Buzzer Unit Environmentally resistant ・ IP rating: *When “With buzzer” option is Direct Mount IP65 Pole Mount IP54 chosen ・Operating Temperature Range: - 20℃...

  • Page 13: Product Functions

    Signal Tower with Ethernet Instruction Manual 5.Product Features and Functions 5.2. Product Functions This section describes the functions of this product. 5.2.1. Signal Tower and Buzzer Notification Functions ・ You can turn on, turn off or flash the Signal Tower, or emit a buzzer in response to events. ・...

  • Page 14: Communication Command Control Function

    Signal Tower with Ethernet Instruction Manual 5.Product Features and Functions 5.2.2. Communication Command Control Function ・ You can use various commands to control light or buzzer of Signal Tower and send notifications. ・ Following commands can be executed in each communication. ●...

  • Page 15: Connection Monitoring Function

    Signal Tower with Ethernet Instruction Manual 5.Product Features and Functions 5.2.3. Connection Monitoring Function • You can observe network and connection of a device by using ping monitoring or Modbus/TCP connection monitoring. • As the monitoring function, only one of the above monitoring methods can be selected. Ping monitoring Monitoring of Modbus/TCP connection The ping command is used to monitor...

  • Page 16: Mounting, Installation, Wiring, And Powering On

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6. Mounting, Installation, Wiring, and Powering on CAUTION Install a location with low vibration and sufficient strength. This product can only be mounted in upright position. Use this product indoors only. (Do not use outdoors.) When increased waterproofing is required, seal the screw or flanged nut parts, as well as over the waterproof sheet around the mounting hole, with a waterproof sealant.

  • Page 17: How To Install

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.1. How to Install 6.1.1. When Directly Installing the Product ❶ Drill a mounting hole and wire entry hole Mounting dimensions at the mounting position of the product. Mounting hole ×...

  • Page 18: When Using A Pole To Fix The Product

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.1.2. When Using a Pole to Fix the Product ❶ Mounting dimensions Make mounting holes in the mounting L-bracket Outline position of the L-bracket. ❷ 2-φ11 Remove the body from the upper bracket φ9 by turning it counterclockwise.

  • Page 19: How To Wiring

    (You can use either a straight through or crossover cable.) When wiring, do not tug the power supply wires, LAN cable, or RJ45 connector, nor stuff them into the main unit. 6.2.1. Wiring Example LR5-LAN LAN connector (RJ-45) 24V DC （Class2）...

  • Page 20: How To Wire To The Power Terminal Block

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.2.2. How to Wire to the Power Terminal Block ❶ Power terminal block’s connector section Using a flathead screwdriver or a similar tool, depress the power terminal block’s connector section.

  • Page 21: Buzzer Pattern Set-Up

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.3. Buzzer Pattern Set-up • If your product is a model with a buzzer unit ( �� ), you can set a buzzer sound pattern and volume. • To set them, you have to remove the buzzer unit and configure the DIP switches on its bottom. •...

  • Page 22: Unit Detachment Method

    • Refer to the following diagrams when detaching the buzzer unit, recombining the LED Unit, etc. • The removal and attachment procedures are also available on the product page. URL of product page: https://www.patlite.com/product/detail0000000983.html WARNING Be sure the power is disconnected before working on this product.

  • Page 23: Led Unit To Body

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.4.1. LED Unit to Body ● Removal LED Unit or Buzzer Unit While holding the body or LED unit, turn the LED unit counterclockwise, until it unlocks, then pull it upwards to remove. ■...

  • Page 24: Body Unit

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.4.2. Body Unit ● Removal While holding the direct mount bracket, turn the body counterclockwise until it unlocks, then pull it upwards to remove. ■ Positioning Mark Body ＜...

  • Page 25: Troubleshooting The Buzzer Unit Attachment

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.4.3. Troubleshooting the Buzzer Unit Attachment The Buzzer Unit is generally in the status shown in the diagram below after removal. Buzzer Unit Groove Positioning Mark LED Unit Buzzer Unit (Detached) Bottom View Body...

  • Page 26: Example For Led Unit Reconfiguration

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.4.4. Example for LED Unit Reconfiguration ● Moving an LED Unit lower ❶ ❷ ❸ ❶ Remove the LED Unit right Turn the LED Unit to remove 　 Align the positioning marks and above the LED Unit in the counterclockwise while holding insert the LED Unit that was...
  • Page 27 Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on ● Troubleshooting the LED Unit The structure of the LED Unit is indicated below. Status Condition Lens LED Unit Rib/Groove Positioning Mark Rib/Groove Body LED Unit (Detached) Top View The rib of the lens generally fits into the groove when the LED Unit has been removed from the product.
  • Page 28 Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on CAUTION Lens Check whether the rib of the lens inside of the LED Unit fits into the groove if the LED Unit does not attach properly. Groove Attach the LED Unit by referring to the next page if the rib does not fit into the groove as shown in the diagram below.

  • Page 29: Checking At Startup

    Signal Tower with Ethernet Instruction Manual 6.Mounting, Installation, Wiring, and Powering on 6.5. Checking at Startup • After turning on the power of the body, you have to check the lighting condition of each LED unit. • When the product gets ready for use, the units light up to inform the user of the product condition. •...

  • Page 30: Before Use

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7. Before Use This section describes the setup procedure required to use this product. Follow the steps below for setup. Set Up Network Settings on the １ STEP 　 Connect this product to a PC ２ STEP 　 “6.2. How to Wiring ( ☞ P.19)” with a LAN cable ３...

  • Page 31: Setting Up Network Settings On The Pc

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.1. Setting Up Network Settings on the PC • To display the productʼs Web Setup Screen, set up is required on a personal computer. • The setup procedure differs according to the OS. You have to see the procedure appropriate to the OS of your PC.
  • Page 32 Signal Tower with Ethernet Instruction Manual 7.Before Use ❺ Click "Properties". ❺ ❻ Select "Internet Protocol Version 4 (TCP/ IPv4)" and click "Properties". ❻...
  • Page 33 Signal Tower with Ethernet Instruction Manual 7.Before Use ❼ In the "General" tab, select the "Use the following IP address:" check box and set the items. ･ IP address: 192.168.10.2 to 254 ･ Subnet mask: 255.255.255.0 ･ Default gateway: No setting is required for a direct ❼...

  • Page 34: Windows 11

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.1.2. Windows 11 ❶ ❶ Right-click “Start” to display the menu, and then click “Network Connections”. ❷ Click “Advanced network settings”. ❷ ❸ Click ▽ of “Ethernet” used to connect the product. ❸...
  • Page 35 Signal Tower with Ethernet Instruction Manual 7.Before Use ❺ Select "Internet Protocol Version 4 (TCP/ IPv4)" and click "Properties". ❻ ❻ In the "General" tab, select the "Use the following IP address:" check box and set the items. ❼ ･ IP address: 192.168.10.2 to 254 ･...

  • Page 36: Setting Up The Password

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.2. Setting Up the Password • The web browsers compatible with the product are Google Chrome (version 128 whose operation testing is completed) and Microsoft Edge (version 128 whose operation testing is completed). •...
  • Page 37 Signal Tower with Ethernet Instruction Manual 7.Before Use ❹ Enter the password and click the "Settings" button. • "Password": Enter the password • “Verify Password”: Reenter the password you want to set * The password must be 1 to 16 single - by te alphanumeric characters.

  • Page 38: Displaying The Web Setup Screen

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.3. Displaying the Web Setup Screen CAUTION While logged in, after a specified period of inactivity (approx. 10 minutes) you are automatically logged out. If the screen does not display correctly due to corrupted characters, change the character encoding to Unicode (UTF-8). To prevent set up from multiple locations at the same time, duplicate logins are not allowed.
  • Page 39 Signal Tower with Ethernet Instruction Manual 7.Before Use ● How to Read the Top Screen ④ ① ⑤ ② ③ Name Description ① Header Displays the product information. ② Menu Navigate to each function. ③ Setting Screen Set the of each function. ④...

  • Page 40: Setting Up Product Network Settings

    Required Maximum 63 Host Name Enter the product's host name. lr5-lan Required characters * Single-byte alphanumeric characters, hyphens, and periods can be used. Hyphen cannot be used at the beginning and end of a “label” separated by periods. Each label must contain at least one alphabetic character.

  • Page 41: Make Settings To Receive Commands

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.5. Make Settings to Receive Commands • You have to make settings to receive various commands. • From “Command Reception Settings” on the menu screen, you display the screen where you set various commands.

  • Page 42: Setting Up Modbus/Tcp

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.5.2. Setting up Modbus/TCP ❶ ❶ Choose “Enabled” for Modbus/TCP communication. ❷ Enter the port number to use. ❸ Click "Settings" to apply the defined settings. ❷ • If a change is made in these settings, the product is disconnected from the currently connected Modbus master.

  • Page 43: Setting Up Connection Monitoring

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.6. Setting up Connection Monitoring • You can set up connection monitoring. • From “Monitoring Settings” on the menu screen, you display the connection monitoring setup screen. • The setup allows a choice between ping monitoring and Modbus/TCP connection monitoring. 7.6.1.
  • Page 44 Signal Tower with Ethernet Instruction Manual 7.Before Use ❶ ❶ Select “Ping monitoring” from the pulldown menu. ❷ Set the Monitored Equipment. In "Monitored Address", register the Monitored Address of the equipment. ❷ In "Number of transmissions (1-30)", set the number of Ping responses that are identified as ❸...
  • Page 45 Signal Tower with Ethernet Instruction Manual 7.Before Use Default Item Description Input Range Input Value Not Used, Ping monitoring, Select the content of connection Network Monitoring Function Modbus/TCP Connection Required monitoring to be performed. Used Monitoring Monitored Enter the IP address that undergoes Blank IPv4 address format Address...

  • Page 46: Setting Up Modbus/Tcp Connection Monitoring

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.6.2. Setting up Modbus/TCP Connection Monitoring • You can make settings to use the function of monitoring Modbus/TCP connection. • During Modbus/TCP connection, you can monitor communication with the Modbus master to detect disconnection. •...
  • Page 47 Signal Tower with Ethernet Instruction Manual 7.Before Use When clear operation is done under abnormal condition detected during monitoring Example 3 Detection of disconnected communication Execution of Detection of restored Clear with Modbus master clear operation communication with Modbus master Operation This Product...

  • Page 48: Performing Operational Check Of The Signal Lights

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.7. Performing Operational Check of the Signal Lights You can operate the signal lights from the Web Setup Screen to check their operation before actual use. In addition, you can generate PNS and HTTP commands, and check the commands used during operation. ❶...

  • Page 49: Reading Configuration Data

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.8. Reading Configuration Data • You can read setting items of this product and saved as setup data on a PC. • You can select and write the setup data of this product that has been read. ❶...

  • Page 50: How To Logout From The Web Setup Screen

    Signal Tower with Ethernet Instruction Manual 7.Before Use 7.10. How to logout from the Web setup screen When the settings on the Web Setup Screen are completed, click “Log out” to exit. Click when settings are complete.

  • Page 51: How To Use

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8. How to Use 8.1. PNS Commands • By sending PNS commands from your computer, you can do things like control this product or get its status. • For the protocol, select either "TCP" or "UDP". •...

  • Page 52: Signal Tower Motion Control Commands

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.1.1. Signal Tower Motion Control Commands You can control the red, amber, green, blue and white LED units and the buzzer with the lighting and sound patterns specified in the data area. Request Command ・Transmission Data Format Data Area *3 (6 byte)

  • Page 53: Clear Command

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.1.2. Clear Command Turns off the Signal Tower and stops the buzzer. Request Command ・Transmission Data Format Product Category *1 ID *2 Unused Data Size 1 byte 1 byte 1 byte 1 byte 2 byte * 1 This product's product category is "AB".
  • Page 54 Signal Tower with Ethernet Instruction Manual 8.How to Use Response Command ・ Response Data (Normal response) Data Area (6 byte) Signal Tower Buzzer Amber Green Blue White 1 byte 1 byte 1 byte 1 byte 1 byte 1 byte ・Data Area Type Value Description...

  • Page 55: Modbus/Tcp

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.2. Modbus/TCP ・ By sending commands from a Modbus/TCP supported master device, you can do things like control this product or get its status. ・ You can use communication port numbers 502, and 1024 to 65535. POINT ●...

  • Page 56: Register Address

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.2.2. Register Address Register Control Data Address High 00H: Do not control, 01H: Control Signal Tower motion control 1 (01H) LED Unit: Red Control of signal light operation. Signal light pattern (Lower bits) * High 00H: Do not control, 01H: Control Signal Tower motion control...

  • Page 57: Example Mapping Of Registers

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.2.3. Example Mapping of Registers Register Address Register Number Example data 1 (01H) 40001 Continuous on: 0101H = 257, Flashing (slow): 0102H = 258 2 (02H) 40002 Continuous on: 0101H = 257, Flashing (slow): 0102H = 258 3 (03H) 40003 Continuous on: 0101H = 257, Flashing (slow): 0102H = 258...
  • Page 58 Signal Tower with Ethernet Instruction Manual 8.How to Use ● Write Single Resister (06H) Control Command Signal light: Operation with “Amber: Flashing (medium)” Data Transaction ID Protocol ID Field Length Unit ID Function Code Address *1 Register2 *2 00H 02H 00H 00H 00H 06H 00H 01H...
  • Page 59 Signal Tower with Ethernet Instruction Manual 8.How to Use ● Write Multiple Resisters (10H) Control Command • Signal light: Red: Continuous on, Amber: Flashing (slow), Green: No Change, Blue: Continuous on, White: Off • Buzzer: ON Transaction ID Protocol ID Field Length Unit ID Function Code...

  • Page 60: Http Commands

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.3. HTTP Commands By sending HTTP commands, you can control this product and obtain the status of this product ● HTTP Command Control Parameter Name Description alert Controls the each color of the Signal Tower and controls the buzzer. Turns off the Signal Tower and stops the buzzer.

  • Page 61: Alert" Control

    User authentication：Enabled ・Signal light: Red: Off, Amber: Continuous on, Green: Flashing (slow), Blue: Off, White: Continuous on ・Buzzer: No change ・Username："Username1:patlite”,Password："Password1:patlite" http://192.168.10.1/api/control?alert=012019&user=patlite&pass=patlite ● clear When you disable user authentication, turn off the signal lights and stop the buzzer: http://192.168.10.1/api/control?clear=1...

  • Page 62: Get Http Command Status

    Signal Tower with Ethernet Instruction Manual 8.How to Use 8.3.2. Get HTTP command status By sending HTTP command, you can check the Signal Tower and buzzer status, and also the software version. Item Description Protocol HTTP Method Syntax http://<IPaddress>/api/status?<Parameter Name>=<Value>[&<Parameter Name>=<Value>] Response data in text and When the parameter name is correct.
  • Page 63 Signal Tower with Ethernet Instruction Manual 8.How to Use ● Signal Tower control status (pattern) ● Buzzer control status - >Displays in decimal - >Displays in decimal Type Value Description Type Value Description Light off Buzzer pattern Light on Flashing (slow) Flashing (medium) ● Obtained data format specifications Pattern...

  • Page 64: Maintenance

    Signal Tower with Ethernet Instruction Manual 9.Maintenance 9. Maintenance 9.1. Initialization Method This product can be initialized in two methods. For information about the items that can be initialized, refer to the table below Initialization Method Main unit settings Network Settings ●...

  • Page 65: Initialize From The Web Setup Screen

    Signal Tower with Ethernet Instruction Manual 9.Maintenance 9.1.2. Initialize from the Web Setup Screen CAUTION If you initialize with the "Initialize the network" check box selected, this product's network settings revert to the default settings. To use it again, you need to reconfigure the network. ❶...
  • Page 66 ● Initial values of each item after initialization (factory default) Item Default Value Setting Method Setup Manually IP Address 192.168.10.1 Network Settings Subnet Mask 255.255.255.0 Default Gateway 0.0.0.0 Host Name lr5-lan Socket communication Enabled function Socket communication Device Port Number 10000 settings Setting Protocol Modbus/TCP Command Reception...

  • Page 67: Restarting Method

    Signal Tower with Ethernet Instruction Manual 9.Maintenance 9.2. Restarting Method Use the Web setup screen to restart this product ❶ Log in to the Web Setup Screen. ・ "“7.3. Displaying the Web Setup Screen ( ☞ P.38)”" ❷ From the menu items, select “Restart”. ❸...

  • Page 68: How To Change Web Login Password

    Signal Tower with Ethernet Instruction Manual 9.Maintenance 9.3. How to change Web Login Password You can change the password in the Web Setup Screen. Changing the password also on the Web setup screen. ❶ ❷ From the menu items, select “User Authentication Settings”.

  • Page 69: How To Update The Firmware

    Signal Tower with Ethernet Instruction Manual 9.Maintenance 9.5. How to update the Firmware You can update the firmware of this product on the Web set up screen. CAUTION After clicking "Update", do not interact with the browser until firmware update is complete. During an update, never power off the product.

  • Page 70: Setting Up Security

    Signal Tower with Ethernet Instruction Manual 9.Maintenance 9.6. Setting Up Security ・ Select the protocol to be used when accessing the Web setting screen or controlling with HTTP commands with HTTP or HTTPS. ・ Register the certificate and private key used when selecting HTTPS. Specification of Certificate and Private key Certificate * PEM format.

  • Page 71: Troubleshooting

    Signal Tower with Ethernet Instruction Manual 10.Troubleshooting 10. Troubleshooting 10.1. Troubleshooting Issue Checklist Reference Is the power supply applied at the correct voltage? Check that the power supply is applied at the rated voltage. Power does not turn on “6.2. How to Wiring ( ☞ P.19)” Is the power supply wiring reversed? Check that the power supply wiring.
  • Page 72 Signal Tower with Ethernet Instruction Manual 10.Troubleshooting Issue Checklist Reference At startup, if access to the DHCP server is unavailable, this product uses its default value 192.168.10.1 in the network Cannot automatically get settings. Check if the environment supports connecting to the IP address, does not start DHCP server.
  • Page 73 Signal Tower with Ethernet Instruction Manual 10.Troubleshooting Issue Checklist Reference Is it writing the correct firmware? “9.5. How to update the Failed to write the firmware Firmware ( ☞ P.69)” Check if it is writing the correct firmware. Have you taken action to be done upon error occurrence during connection monitoring? “7.6.

  • Page 74: Service Parts

    Signal Tower with Ethernet Instruction Manual 11.Service Parts 11. Service Parts These are the various parts for the customer to use when repairing or replacing parts for the product. O-ring 50 Head Cover 50 Shading Sheet 50 5 pcs. 5 pcs.
  • Page 75 Signal Tower with Ethernet Instruction Manual 12.Optional Parts 12. Optional Parts 12.1. Optional Parts The optional parts for this product are listed below. ● LED Unit Model External Diagram General Specifications LR5-E- □ □ * ・ Ambient operating temperature: -20℃～ +50℃ ・...

  • Page 76: Optional Parts For Attachment

    Signal Tower with Ethernet Instruction Manual 12.Optional Parts ● Wireless Data Communication System Transmitter Model External Diagram General Specifications ・ Ambient operating temperature: -10℃～ +50℃ ・ Ambient operating humidity: 85 % RH or less; No condensation ・ Mass (Tolerance: ±10 %): 0.074kg ・...
  • Page 77 Signal Tower with Ethernet Instruction Manual 12.Optional Parts 12.2. Optional Parts for attachment The optional parts for attachment are listed in the following table: Wall-Mount Bracket Circular Bracket L-bracket SZK-002W SZK-001U SZ-010 SZL-001 Circular Bracket Mounting Bracket AC Adapter SZW-001W SZW-002W ADP-001C AC Adapter...

  • Page 78: Specifications

    Signal Tower with Ethernet Instruction Manual 13.Specifications 13. Specifications Rated Voltage 24V DC Operating Voltage Range Rated Voltage ± 10% Main Unit Typ.15 mA Max. 20 mA Rated Current LED Unit Typ.40 mA Max. 45 mA (per tier) Consumption Buzzer Unit Typ.40 mA Max.
  • Page 79 Signal Tower with Ethernet Instruction Manual 13.Specifications Screwless Terminal Block (24V DC) Power Supported Wire Single wire: φ 0.5-1.2mm Supply Interfaces Diameter Stranded wire: 0.2-1.5mm (AWG24-16) Ethernet RJ-45 Connector Network Communication Ethernet (IEEE802.3 Conformity) Format 10BASE-T/100BASE-TX (Auto-MDI/MDIX) Operation Interface Switch for Initialize ×1pc WE Type Hexagon nut with flange(M3) ×3pcs Accessories...
