  • Page 1 SCRUBBER DRYER INSTRUCTION MANUAL Contact Information: IIC Products Ltd T/A Victor Floorcare Lancaster Court Lancaster Road Shrewsbury SY1 3LG United Kingdom 0121 706 3553 E-mail: Sales@VictorFloorcare.com www.VictorFloorcare.com...
  • Page 2 Instruction Manual V-SD30 V-SD 30 INSTRUCTION MANUAL • Description: Walk-behind scrubber-dryer for use in retail/industrial premises • Model: SD30 • Manual revision: 1.0 In order to obtain the best results, it is recommended to use original consumables The trade or registered marks mentioned in this manual belong to their respective owners.
  • Page 3: Table Of Contents

    Instruction Manual V-SD30 TABLE OF CONTENTS MACHINE DESCRIPTION 1.1. Description of control panel TECHNICAL SPECIFICATIONS 2.1. Functional units SAFETY FEATURES 3.1. Declaration of absence of harmful substances 3.2. Safety devices of fixed closing guards 3.3. Safety devices relevant to mobile guards...
  • Page 4: For Safety

    PRESENTATION Dear Customer, We would like, first of all, to thank you for choosing to purchase, the new V-SD30 Walk-behind Scrubber- Dryers which, thanks to its features – described in this manual – we are confident will meet your needs.
  • Page 5: Machine Description

    Instruction Manual V-SD30 MACHINE DESCRIPTION V-SD30 is a Walk-behind Scrubber-Dryer machine, to wash and dry hard floors, battery powered intended for retail use. The main systems of the machine are as follows: ▪ The detergent solution tank and relevant circuit, ▪...
  • Page 6 Instruction Manual V-SD30 The function of the control devices is to control the various settings of the machine. They include: 1. Start controls 2. Display 3. Brush function pushbutton 4. Suction function pushbutton 5. Solenoid valve function pushbutton 6. Traction speed control pushbutton, decrease speed (only for FT) 7.
  • Page 7: Description Of Control Panel

    Instruction Manual V-SD30 1. Control panel description Start-up commands Press either the right or left red button on the handle to start the machine. CAUTION: when the machine is switched on, the red lever must NOT be pressed, otherwise the RELEASE RED...
  • Page 8: Technical Specifications

    Instruction Manual V-SD30 6/7. Traction speed buttons Press button «6» to decrease, «7» to increase the forward speed of the machine, only for models with FT traction. The ladder on the left side of the display will light up accordingly.
  • Page 9: Functional Units

    Instruction Manual V-SD30 2.1 Functional units LIST OF UNITS 8. Vacuum engine (turbine) 1. Control panel 9. Battery compartment 2. Solution tank 10. Turbine discharge air filter 3. Recovery tank 11. Brush rotation motor 4. Recovery tank lid 12. Water loading spout 5.
  • Page 10: Safety Features

    Instruction Manual V-SD30 Tank internal view Float At the turbine Recovery tank cover with seal Dirty water from squeegee Water loading inlet 3. SAFETY FEATURES In view of the safety standards of the unified text of the Machine Directive 2006/42/CE and Electromagnetic Compatibility 2014/30/EU.
  • Page 11 Instruction Manual V-SD30 • When the machine is left unattended, adopt all necessary measures to prevent any unintentional movement of the same. • The machine must be exclusively operated by trained and authorized personnel. • When the machine is left unattended, engage the emergency, turn the locking key and extract the key.
  • Page 12: Declaration Of Absence Of Harmful Substances

    Instruction Manual V-SD30 3.1. Declaration of absence of harmful substances We hereby declare that our products, used in the process of assembling the machine, are produced with materials that comply with the limits established by the regulations in force on the protection of health and the environment and do not contain substances classified as SVHC (Substance of Very High Concern) in accordance with CE 1907/2006 regulation (REACH, i.e.
  • Page 13: Intended Use Of The Machine (Washing And Drying Phase)

    INTENDED USE OF THE MACHINE (machine being moved without washing or drying) V-SD30 can be handled without brush plate lowered and brushes in contact with the floor, or with the drying turbine turned off. This can happen during transfer from one room to another, at the end of cleaning or for other reasons. Just act on the rear support located on the machine back to be able to move it conveniently.
  • Page 14: Supplied Kit

    Instruction Manual V-SD30 Warning The machine has been designed to work on flat surfaces and minor gradients. The maximum permitted gradient, which can be travelled up either during operation or transfers, is 2%. To travel down, it is recommended to move in reverse for optimal performance.
  • Page 15: Machine Preparation And Commissioning

    Instruction Manual V-SD30 11. MACHINE PREPARATION AND COMMISSIONING 11.1. Machine start up NOTE: Before operating the machine, perform preliminary inspection. For Safety Before starting the machine up, ensure the emergency on the back of the machine is not pressed. 11.2 Machine filling...
  • Page 16: Use Of The Machine

    Instruction Manual V-SD30 12. USE OF THE MACHINE 12.1. Floor washing and drying Plan the washing and drying route in advance. The longest route follows the perimeter of the area to be treated. The ideal route has the least turns, stops or brush plate lifting and lowering (to maneuver).
  • Page 17: Emptying And Cleaning The Recovery Tank

    Instruction Manual V-SD30 12.4. Emptying and cleaning the recovery tank 1. Place the vehicle near a manhole drain. The discharge pipe is at the rear of the machine. 2. Remove the drain hose from the hook. Unscrew the cap and lower the drain hose towards the floor drain.
  • Page 18: Control Station

    Instruction Manual V-SD30 13. CONTROL PANEL 13.1 Control panel Start-up commands Press either the right or left red button on the handle to start the machine. CAUTION: when the machine is switched on, the red lever must NOT be pressed, otherwise the RELEASE RED...
  • Page 19: Controls

    Instruction Manual V-SD30 13.2 CONTROLS It is recommended to clean the wiper after each work cycle: release it from the connection by unscrewing the locking knobs “1” and clean in running water. Water filter cleaning: it’s located in the middle under the machine, unscrew the cap “2” and clean the inner mesh.
  • Page 20: Charging The Batteries

    Instruction Manual V-SD30 Indications for proper maintenance Maintenance - Recharge within 6 months. Recommended 3 months. - Store at a temperature between 5 and 30 °C, in the original packaging. Main rules and precautions for use - protect the battery from possible impacts and mechanical and thermal shocks...
  • Page 21: Brush Replacement

    Instruction Manual V-SD30 13.5. Brush replacement This is done as follows. 1. With brush plate raised (tilted machine) ATTENTION: Operation to be carried out with empty recovery tank 2. Pull the brush using the handle located in the center of the brush itself (1).
  • Page 22: Wiper Assembly

    Instruction Manual V-SD30 13.6. Wiper assembly The machine is packed, shipped and delivered with assembled wiper. 13.7. Wiper adjustment Two wiper adjustments are possible: lengthwise tilting, act on the wheel locking nut, vertically move the two side wheels (1) to adjust the height and the central one (2) to adjust the tilt.
  • Page 23: Hepa Filter Replacement

    Instruction Manual V-SD30 13.10. Clean water filter cleaning The clean water filter is fitted under the machine's floor, in the middle. The filter has the purpose of preserving the solenoid valve controlling solution flow rate from any debris or sediment and dirt there might be in the solution tank.
  • Page 24: Troubleshooting

    Instruction Manual V-SD30 13.13 Troubleshooting PROBLEM CAUSE SOLUTION Emergency button pressed Check the button Machinery without power Disconnected power cables (behind supply Check connections. emergency button) Flat battery See display Worn brushes Check wear No thrust forward or poor Unsuitable brushes for the floor...
  • Page 25: Alarms On Display

    Instruction Manual V-SD30 13.14 Alarms on the display PROBLEM CAUSE SOLUTION Check that the brushes rotate freely Absorption limit allowed for the brush motor OVER CURRENT BRUSH Check that the brush/flooring is correctly exceeded matched Check that the brushes rotate freely...
  • Page 26: Sound Emission

    IEC standards with constant fast-slow reading, both from the position where the operator is located, and in positions surrounding the machine being considered. The measured value of the sound pressure at the level of the operator, is equal to: V-SD30 → Leq(A) = 63,9 dB(A) Wiring diagram Legenda...
  • Page 27: Declaration Of Conformity Ukca

    Instruction Manual V-SD30 UK DECLARATION OF CONFORMITY IIC Products Ltd T/A Victor Floorcare, Lancaster Court, Lancaster Road, Shrewsbury, SY1 3LG United Kingdom 0121 706 3553 declare under our responsibility that the products: ❑ SD-30 Machine Type: Serial number: __________ Year of manufacture: ______...
