Summary of Contents for ATIGO A2601
- Page 1 A2601 2-Wire BUS Relay User Manual...
-
Page 2: Table Of Contents
Table of Contents 1. About A2601 Unit ..........................4 Description: ............................4 2. Parts and Name ..........................4 3. DIP2 Settings ........................... 5 4. DIP1 Settings ........................... 6 5. Specification ............................ 7 P a g e... -
Page 3: About A2601 Unit
1. About A2601 Unit Description: The A2601 BUS relay is designed as a volt-free contact output with following features: • It only provides relay contact • It has two work modes: lock control mode and light control mode; • Allows to open gate, door, locks or control lights;... -
Page 4: Dip2 Settings
3. DIP2 Settings The DIP2 switch on the A2601 is used to set its’ address. Please refer to the followings for more detailed information about the DIP2 settings: BIT State Description OFF, OFF, Applies to door station 1 & lock 1 ON, OFF, OFF Applies to door station 1 &... -
Page 5: Dip1 Settings
4. DIP1 Settings On DIP1, first bit is used to set video Impendence match, bit 2 & 3 are used to set unlock time or light on time. Please refer to the followings for more detailed information about DIP 1 settings: BIT State Description Unlock/light time is determined by monitor... -
Page 6: Specification
5. Specification Power Supply: 18 - 28V DC Power Consumption: 10mA in standby 25mA in working Unlocking Time: 1~99s(Default 1s); Wiring: 2 wires (non-polarity) ˚ ˚ Working Temperature: C ~ +40 Dimension: 45(H) × 65(W) × 16(D) mm. P a g e...
