Model 730A TABLE OF CONTENTS Section 1 Instrument Description 1.1 Specifications 1.2 Optional Accessories and Ordering Information 1.3 TEGAM Family of Handheld Bond Meters Section 2 Preparation for Use 2.1 General Information 2.2 Feature Overview 2.3 Safety Notices and Information 2.4 Unpacking and Inspection 2.5 Battery Installation and Replacement 2.6 Making Your First Resistance Measurement...
Page 4
Model 730A TABLE OF CONTENTS Section 4 Display Probe (Optional) 4.1 Overview 4.2 Display 4.3 Remote HOLD Button 4.4 PASS/FAIL LED 4.5 UNDER/OVER Indicator 4.6 Open Lead Detection 4.7 Connection 4.8 Operation Section 5 Service Information 5.1 Inspection and Cleaning 5.2 Calibration 5.3 Troubleshooting 5.4 Diagnostic Routines and Error Codes...
Model 730A SECTION 1 INSTRUMENT DESCRIPTIONS Specifications General Specifications Accuracy ±(0.2% Reading + 0.02% Range) -10 to 55 Full Scale Resolution Test Current 100 mA 10 mA Resistance Ranges and Test Currents 1 mA Connector Type Max. Lead Resistance Four and one-half (4 1/2) digit LCD, with Range, Units, Function, Battery, Display and Decimal Indicators Display Backlight...
Page 6
Model 730A SECTION 1 INSTRUMENT DESCRIPTIONS Specifications Environment Standards MIL-PRF-28800F, Class 2 Operating Temp -10 to 55 -14 to 131 Humidity 5 to 95%, 10 to 30 5 to 95%, 50 to 86 Altitude 0 to 4600 m 0 to 15,092 ft Vibration Random 10 –...
Model 730A SECTION 1 INSTRUMENT DESCRIPTIONS Optional Accessories and Ordering Information Product Model Description BKDP-M2 Big Kelvin Display Probe, 700 Series BKP-M2 Big Kelvin Probe, 700 Series BKDP-M2S Big Kelvin Display Probe, 700 Series, Intrinsically Safe BKP-M2S Big Kelvin Probe, 700 Series, Intrinsically Safe BKEP-M2 Big Kelvin Extended Probe, 700 Series BKP-B...
SECTION 2 PREPARATION FOR USE General Information The TEGAM 730A Wireless Datalogging Handheld Bond Meters are high-accuracy micro-ohmmeters that provide accurate resistance readings in a wide range of manufacturing and service applications. These full- featured, durable, and versatile instruments simplify the process of resistance measurement through the intuitive user-interface.
Model 730A SECTION 2 PREPARATION FOR USE Safety Notices and Information Read this Operation Manual thoroughly before using the instrument to become familiar with its operations and capabilities. Visually inspect instrument before using. Do not use if unit appears damaged or with any part of the case removed.
Model 730A SECTION 2 PREPARATION FOR USE CAUTION RISK OF INCORRECT READING Do not use when AC or DC voltages exist. Excessive voltage could result in an incorrect reading, or in more extreme cases, a blown fuse that will result in incorrect readings and need for repair. Do not use on reactive loads exceeding 2 mH or 100 uF.
Model 730A SECTION 2 PREPARATION FOR USE Battery Installation and Replacement Three (3) AA 1.5 V batteries are supplied with the instrument, but not installed. Read the following battery replacement instructions before attempting to install or remove the batteries. Always turn the instrument off and disconnect any connections to DUT before replacing the CAUTION batteries.
Model 730A SECTION 2 PREPARATION FOR USE Making Your First Resistance Measurement TEGAM’s 700 Series Handheld Bond Meters are designed for easy operation, while still providing a feature- rich experience via the intuitive user interface. To get started making resistance measurements right away, follow these steps: Perform Section 2.5, Battery Installation and Replacement;...
Model 730A SECTION 2 PREPARATION FOR USE Recording Resistance Data The TEGAMLink B mobile application provides convenient two-way communication between your TEGAM Bond Meter and compatible Bluetooth low energy technology / version 4.0 mobile devices. TEGAMLink B duplicates the Bond meter display for easy monitoring from up to 30 feet away. See Figure 2 below for a description of the TEGAMLink B user interface.
Page 15
Model 730A SECTION 2 PREPARATION FOR USE To connect to the TEGAMLink B mobile app: Before beginning, ensure your mobile device is Bluetooth low energy technology / version 4.0 compatible; Visit the Google Play store or Apple App store and search for “TEGAM” to download TEGAMLink B; Install the mobile app to your device and accept the license agreement and permissions requests;...
Model 730A SECTION 3 OPERATING INSTRUCTIONS Keypad Functions The instrument keypad is a six (6) key, sealed membrane keypad. Each key provides audible and tactile user feedback when pressed. Key functions are described in Figure 3-1 below. Power instrument ON or OFF (1.5s) Disable auto-power OFF while instrument is on (1.5s)
Model 730A SECTION 3 OPERATING INSTRUCTIONS LCD Display The display is a large, easy to read, LCD display, with an LED backlight for clear viewing in low-light conditions. It can simultaneously display the resistance reading, range, PASS/FAIL status, open lead detection, over/under indication and the battery level.
Model 730A SECTION 3 OPERATING INSTRUCTIONS Test Limit Menu Key designators followed by (1.5s), e.g., (1.5s), indicate that the key should be pressed and held for 1.5 seconds, then released to access the desired function. Test limits are available for the user to easily identify if a measurement is above or below a resistance value with an OK/FAIL indication.
Model 730A SECTION 3 OPERATING INSTRUCTIONS Auto-Hold Function The Auto Hold function allows the user to take a measurement, have the unit determine a stable reading, and hold that value. Once the user is ready to make the next measurement, is pressed momentarily to clear the last reading from the display and re-initiate Auto-Hold mode.
Model 730A SECTION 3 OPERATING INSTRUCTIONS Open Lead Detection The 700 Series Handheld Bond Meters feature open lead detection for all ranges. This feature monitors the test current across the leads on each channel. A small current is sourced between the Kelvin connection of each channel’s test leads.
Model 730A SECTION 3 OPERATING INSTRUCTIONS 3.12 Invalid Measurement Indications The LCD display indicates when a measurement is invalid, as shown in Figure 5 below. Indication Description ————— The device is auto ranging. OVER and ----- Reading is 110% of full scale or higher. If possible, switch to a higher range. UNDER Reading is 10% of full scale or less.
Model 730A SECTION 4 DISPLAY PROBE (OPTIONAL) Overview An optional accessory for the 730A, the Display Probe features an integrated OLED display, a remote HOLD button, and a PASS/FAIL LED. The Display Probe controls are shown in Figure 6 below. Remote HOLD button OLED Display PASS/FAIL LED...
Model 730A SECTION 4 DISPLAY PROBE (OPTIONAL) Connection The 730A Display Probe must be used in conjunction with a non-display probe. As long as the Display Probe is connected to Channel 1, any combination of probes can be used with the display probe. To connect the 730A Display Probe: Power off the 730A and remove the probe from channel 1 if there is one connected.
Model 730A SECTION 5 SERVICE INFORMATION Inspection and Cleaning To extend the life of the instrument, inspect and clean the instrument regularly. Inspect the instrument for any significant abrasions, cuts, cracks, dents, or other signs of damage on the case, keypad, and display lens. Inspect the connectors for breaks, dirt, or corrosion.
Page 25
Model 730A SECTION 5 SERVICE INFORMATION Indicate if the value exceeds the high limit or low limit calculated in Step 6 using “Pass/Fail” column of Appendix B. Indicate if the value exceeds the high limit or low limit calculated in Step 6 using “Pass/Fail” column of Appendix B.
Page 26
Model 730A SECTION 5 SERVICE INFORMATION Short the leads of the unit in the following order: +I to -I, -I to +E, and +E to -E. (See Figure 7) The unit should display 0.000 (±0.002). ±0.050), check that the connection of the shorted leads are in the correct order With the leads still shorted together, insert a rigid wire through the alignment access hole and gently press the calibration enable...
Page 27
Model 730A SECTION 5 SERVICE INFORMATION Short the leads of the unit as described in Step 6. Press to select 0.00. Press “-----” will flash periodically The UUT display will then indicate as follows: “2” Line 1: ----- Press “-----” will flash periodically. The UUT display will indicate as follows: “1”...
Page 28
Model 730A SECTION 5 SERVICE INFORMATION Press to select 0.000. Press “-----” will flash periodically. The UUT display will then indicate as follows: “2” Line 1: ----- Press “-----” will flash periodically. Short the leads of the unit as described in Step 6. Press the to select 0.00.
Model 730A SECTION 5 SERVICE INFORMATION Troubleshooting TEGAM’s handheld bond meters are designed and built to provide years of uninterrupted use. In the event the instrument malfunctions or does not perform as expected, helpful troubleshooting tips are provided below. Figure 8 below lists some of the more common issues and their resolutions. Symptom Description Resolution...
Model 730A SECTION 5 SERVICE INFORMATION Preparation for Calibration or Repair Service Once you have verified that the cause of the malfunction cannot be solved in the field and the need for repair and calibration service arises, contact AE technical support to obtain an RMA (Returned Material Authorization) number.
Model 730A SECTION 5 SERVICE INFORMATION Expedite Repair & Calibration Form Use this form to provide additional repair information and service instructions. The completion of this form and including it with your instrument will expedite the processing and repair process. RMA #: Instrument Model #: Serial Number:...
Model 730A SECTION 5 SERVICE INFORMATION Warranty Advanced Energy Inc. warrants this product to be free from defects in material and workmanship for a period of three (3) years from the date of shipment. During this warranty period, if a product proves to be defective, Advanced Energy Inc., at its option, will either repair the defective product without charge for parts and labor, or exchange any product that proves to be defective.
Model 730A APPENDICES REQUIRED ALIGNMENT AND VERIFICATION EQUIPMENT Equipment Normal Value Tolerance Resistance Standards ±10% Nominal 100 µ Required to access the calibration enable switch. Any rigid wire, Rigid Wire approximately 0.8 mm in diameter, may be used. Note 5 - The resistance standards' total contribution to the calculated calibration uncertainty is the responsibility of the calibrating laboratory.
Model 730A SECTION 6 SERVICE INFORMATION Issue Date Description Originators 02.06.2025 First Issue Zoey Yasheng advancedenergy.com Rev. 02.06.25_#1.0...
