Johannus Opus C 280 Quick Reference Manual

JOHANNUS Opus C 280
INSTALLATION MUSIC DESK
- Turn countersunk brass screws into music desk slat by hand till screws stick out 2 mm.
- Place music desk at the right position, with screw points into the pre drilled holes.
- Tight music desk with screw driver. Electric screw driver is not recommended.
OVERVIEW OF CONTROLS
A Pedal stops
B Swell stops
C Great stops
D PANFL.: Pan Flute,
TRUMP.: Trumpet
E Capture memory locations - Generals
F Capture memory locations Swell
G T: Tutti
H RO: Reeds Off
I Gen Expr. (Gereral Expression)
J CR: Crescendo
K REC: Recall
L Headphones
M SET (save registration)
N STYLE: Organ style selection
SWITCH ON
Switch on the organ with the on/off piston at the right, next to the manuals.
Wait several seconds. Starting the control functions and the settings will take some time.
The organ is ready when the lights of the 0 piston and standard functions light up and the
display shows the settings.
O Capture memory locations Pedal
P Capture memory locations Great
Q MB: Manual Bass
R CF: Cantus Firmus
S VOL: Volume control Organ
T REV: Volume control Reverb
U TRANS: Transposer
V - and + pistons
W ENTER
X MENU
Y CAN: Cancel
Z On/Off piston
AA Display
AB Great Manual
AC Swell Manual
ACCESSORIES
RO: Reeds Off
Reeds Off is a function to switch off all reed stops simultaneously.
GEN. EXPR.: General Expression (All Swells to Swell)
General Expression transforms the swell pedal for the Swell to a swell pedal for the entire organ.
If no expression pedal is configured as a swell pedal for the Swell, this piston cannot be activated.
REC.: Recall
The last registration change is cancelled.
CR: Crescendo
Crescendo is a piston to activate the crescendo pedal.
If no expression pedal is configured as a crescendo pedal, the CR piston cannot be activated.
MB: Manual Bass
Couples the Pedal monophonic to the Great. Only the lowest key that is played on the Great is
coupled from the Pedal to the Great.
CF: Cantus Firmus
Couples the Swell monophonic to the Great. Only the highest key that is played on the Great is
coupled from the Swell to the Great.
TRANS.: Transposer
The Transposer function shifts the pitch by half-tone increments (from -8 to +8). The set pitch can be
read on the display (Tr:..).

Press the TRANS. piston.

Use the - and + pistons to set the pitch.
CAN.: Cancel
All registrations are cancelled.
MENU: Johannus Menu
In the Johannus Menu several functions of the organ can be set.

Press the MENU piston to activate the Johannus Menu.

Use the - and + pistons to navigate through the menu.

Use the ENTER piston to confirm.

Use the MENU piston Cancel or step back in the menu.
VOLUME CONTROLS
VOL.: With the volume button VOL. (Volume) the total volume of the organ can be set.
Press the VOL. button so that it lights up, then use the + or – button to increase or decrease
the volume. The volume level can be read from the display, behind the symbol.
Quick Reference Guide
